Product Name: 3300 XL 8 mm Reverse Mount Probes
Brand Name: Bently Nevada
Model Number: 330105-02-12-15-02-CN
Place of Origin: United States
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Alternative Name
Bently Nevada 3300 XL 8 mm Reverse Mount Probe
3300 XL Reverse Mount Eddy Current Probe
3300 XL 8 mm Proximity Probe
Reverse Mount Shaft Vibration Probe
Industrial Eddy Current Displacement Sensor
8 mm Non-Contact Proximity Probe
Reverse Mount Machinery Monitoring Probe
Shaft Position Monitoring Probe
Rotating Machinery Vibration Sensor
3300 Series Reverse Mount Transducer Probe
The 330105-02-12-15-02-CN is a high-performance 3300 XL 8 mm reverse mount proximity probe designed for precise vibration and shaft position monitoring in rotating machinery. As part of the 3300 XL 8 mm Proximity Transducer System, the probe works together with a 3300 XL extension cable and Proximitor sensor to provide accurate non-contact eddy current measurements.
The system outputs a voltage proportional to the distance between the probe tip and the conductive target surface, enabling reliable monitoring of both static shaft position and dynamic vibration. Designed for fluid-film bearing machines, the probe also supports Keyphasor reference and rotational speed measurements for advanced machinery diagnostics.
The 330105-02-12-15-02-CN features a reverse mount configuration with 3/8-24 UNF threads, making it ideal for installations where standard probe mounting is limited by space constraints. Its Polyphenylene Sulfide (PPS) probe tip, miniature ClickLoc coaxial connector, and interchangeable 3300 XL design ensure durability, simplified maintenance, and full backward compatibility with previous 3300 series systems.
|
Sales |
|
|
|
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Winnie |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
| Product Name | Bently Nevada 330105-02-12-15-02-CN 3300 XL 8 mm Reverse Mount Probes |
| Manufacturer | Bently Nevada |
| Product Type | 3300 XL 8 mm Reverse Mount Probes |
| Part Number | 330105-02-12-15-02-CN |
| Dimensions | 20x20x2cm |
| Weight | 0.06kg |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Maximum Altitude | 2000 meters |
| Probe Tip Material | Polyphenylene sulfide (PPS). |
| Nominal Probe DC Resistance | 7.73 ± 0.50 Ω |
| Total Length Option | 1.5 meter (4.9 feet) |
| Connector and Cable-Type Option | Miniature ClickLoc coaxial connector |
Q1: Does 330105-02-12-15-02-CN support Keyphasor measurements?
A1: Yes, the 330105-02-12-15-02-CN supports Keyphasor reference and rotational speed monitoring applications.
Q2: What type of mounting does 330105-02-12-15-02-CN use?
A2: The 330105-02-12-15-02-CN uses a reverse mount configuration with 3/8-24 UNF threads.
Q3: What is the cable length of 330105-02-12-15-02-CN?
A3: The 330105-02-12-15-02-CN includes a total cable length of 1.5 meters (4.9 feet).
Q4: What material is used for the probe tip of 330105-02-12-15-02-CN?
A4: The 330105-02-12-15-02-CN uses a Polyphenylene Sulfide (PPS) probe tip.
Q5: Is 330105-02-12-15-02-CN compatible with older 3300 systems?
A5: Yes, the 330105-02-12-15-02-CN is fully backward compatible with non-XL 3300 series 5 mm and 8 mm systems.
Q6: What connector type is used by 330105-02-12-15-02-CN?
A6: The 330105-02-12-15-02-CN uses a miniature ClickLoc coaxial connector.
Q7: What applications is 330105-02-12-15-02-CN suitable for?
A7: The 330105-02-12-15-02-CN is suitable for turbines, compressors, motors, and other fluid-film bearing machinery.
