ABB NKTU01-10 I/O Module to Termination Unit Cable

ABB NKTU01-10 I/O Module to Termination Unit Cable

Product Name: I/O Module to Termination Unit Cable

Brand Name: ABB

Model Number: NKTU01-10

Place of Origin: Sweden

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

Overview
Contact Info
Parameter
Introduction
Features
Function
FAQ
Product Recommendations
Recommended Products

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Contact Info

Sales	Email	Whatsapp
Jim Pei	[email protected]	+86 18020776782

Parameter

Product Name	ABB NKTU01-10 I/O Module to Termination Unit Cable
Manufacturer	ABB
Product Type	I/O Module to Termination Unit Cable
Part Number	NKTU01-10
Estimated shipping dimensions	34.5x31x5cm
Weight	0.8 kg
Place of shipment	Xiamen, China
Country of origin	Sweden
Cable Length	10 feet (3.05 meters)
Jacket Material	PVC (Polyvinyl Chloride)
Conductor Material	Tinned Copper
Shielding Type	Braided + Foil (EMI/RFI protection)
Connector Type	Factory-molded, keyed multipin
Rated Temperature	-40°C to +85°C
Insulation Resistance	>100 MΩ at 500 VDC
Dielectric Test Voltage	1500 VAC for 1 minute

Introduction

The ABB NKTU01-10 is a factory-terminated interconnection cable designed for reliable signal transmission between I/O modules and Termination Units (TUs) in ABB Symphony Plus and INFI 90 control systems. With a fixed length of 10 feet (3.05 m), it provides a standardized and error-free wiring solution for distributed control system (DCS) installations.

This cable replaces field-terminated wiring by providing a pre-engineered and fully tested assembly, reducing installation time and eliminating common wiring issues such as incorrect pinouts, loose connections, and poor shielding performance. It is widely used in industrial automation environments where high reliability and signal integrity are required.

Features

Designed for ABB Symphony Plus and INFI 90 distributed control systems
Fixed 10 ft (3.05 m) cable length for standardized cabinet installation
Pre-assembled and factory-tested to eliminate field wiring errors
100% continuity and hipot tested before shipment for guaranteed reliability
Dual-layer shielding (foil + braided) for strong EMI/RFI suppression
High shielding coverage (>90%) ensures stable signal integrity in noisy environments
Suitable for installation near VFDs, switchgear, and high-voltage equipment
PVC outer jacket for durability, flexibility, and chemical resistance
Resistant to oils, mild acids, abrasion, and UV exposure
Tinned copper conductors for consistent electrical performance
Wide operating temperature range from -40°C to +85°C
High insulation resistance (>100 MΩ at 500 VDC)
Dielectric strength tested at 1500 VAC for 1 minute
Factory-molded, keyed multipin connectors prevent misconnection
Reduces commissioning time and maintenance effort in DCS installations
Compatible with legacy Bailey INFI 90 and Network 90 systems
Improves system reliability by minimizing loose contacts and wiring faults

Function

The primary function of the ABB NKTU01-10 is to provide a reliable and standardized electrical connection between I/O modules and termination units within ABB distributed control systems.

It ensures accurate signal transmission for analog and digital I/O signals while maintaining high immunity to electromagnetic interference. By replacing manually terminated field wiring, the NKTU01-10 reduces installation errors and improves system reliability.

The cable is designed to maintain signal integrity even in electrically noisy environments, such as near motor drives, switchgear, and industrial power systems.

FAQ

1. What is the ABB NKTU01-10 used for?

The ABB NKTU01-10 is used to connect I/O modules to termination units in ABB Symphony Plus and INFI 90 control systems.

2. What is the length of the ABB NKTU01-10?

The ABB NKTU01-10 has a fixed length of 10 feet (3.05 meters).

3. Which systems are compatible with the ABB NKTU01-10?

The ABB NKTU01-10 is compatible with ABB Symphony Plus and legacy INFI 90 DCS systems.

4. What type of shielding does the ABB NKTU01-10 use?

The ABB NKTU01-10 uses dual foil and braided shielding for strong EMI/RFI protection.

5. What is the temperature range of the ABB NKTU01-10?

The ABB NKTU01-10 operates in a wide temperature range from -40°C to +85°C.

6. Does the ABB NKTU01-10 require field wiring?

No, the ABB NKTU01-10 is factory-terminated, eliminating the need for field wiring.
