Product Name:DeviceNet Adapter Module
Brand Name:ABB
Model Number:RDNA-01
Country of Origin:SWEDEN
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
ABB |
Model Number: |
RDNA-01 |
Country of Origin: |
SWEDEN |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Parameter | Specification |
|---|---|
| Product Model | RDNA-01 |
| Product Type | DeviceNet Adapter Module |
| Manufacturer | ABB |
| Communication Protocol | DeviceNet (ODVA Compliant) |
| Device Role | Class 2 Slave Device |
| Supported Services | Explicit Messaging, Poll Response, Change of State, Cyclic I/O |
| Network Topology | Linear Bus Topology |
| Bus Termination | 121 Ω Metal Film Resistor |
| Node Address Setting | DIP Switch Configurable |
| Status Indication | Integrated LED Diagnostics |
| Mounting Method | Internal Drive Option Slot |
| Connector Type | DeviceNet Terminal Block |
| Dimensions (Approx.) | 120 × 75 × 25 mm |
| Weight (Approx.) | 0.15 kg |
| Compatible Drives | ABB ACS800, ACS550 and selected ABB drive series |
The RDNA-01 DeviceNet Adapter Module is a communication interface developed for ABB industrial drives, enabling seamless integration between drive systems and DeviceNet industrial networks. Designed for reliable field-level connectivity, the module allows controllers and PLCs to exchange operational data with ABB drives through a standardized DeviceNet protocol architecture.
As a dedicated DeviceNet slave interface, RDNA-01 supports drive control functions such as start/stop commands, speed reference transmission, torque regulation, parameter access, and real-time status monitoring. It also facilitates efficient fault diagnostics and remote parameter configuration, helping reduce maintenance time and improve operational visibility.
Compatible with a wide range of ABB drive platforms including ACS800, ACS550, and other supported systems, the RDNA-01 enhances automation flexibility in manufacturing, energy, process industries, and machine control applications where dependable industrial communication is essential.
Power Plants: Used for drive communication, generator auxiliary system control, and motor status monitoring.
Substations: Enables communication between motor drives and supervisory control systems.
Chemical Plants: Integrates process automation systems with ABB variable speed drives.
Steel Mills: Provides stable communication for rolling mills, conveyors, pumps, and heavy-duty motors.
Machinery Manufacturing Plants: Used in robotic systems, automated assembly lines, packaging machinery, and material handling equipment.
Water & Wastewater Facilities: Facilitates communication between drives, PLCs, and SCADA systems.
Reliable DeviceNet Connectivity: Fully compliant with DeviceNet communication standards for stable industrial networking.
Flexible Drive Control: Supports remote start, stop, speed reference, and torque control functions.
Advanced Diagnostics: Built-in LED indicators enable rapid fault identification and troubleshooting.
Easy Configuration: DIP switch settings simplify node address and communication speed setup.
Broad Compatibility: Compatible with ABB drives and DeviceNet master scanners from multiple manufacturers.
Drive Command Transmission: Sends operational commands such as Start, Stop, and Run Enable.
Reference Value Handling: Transfers speed, torque, and process reference signals to the drive.
Parameter Access: Allows remote reading and writing of drive parameters.
Status Monitoring: Provides real-time operational status and diagnostic information.
Fault Management: Supports fault detection, reporting, and remote reset operations.
Network Communication: Enables seamless data exchange between DeviceNet masters and ABB drives.
Q1: What is the primary function of the RDNA-01 module?
A1: It enables ABB drives to communicate with DeviceNet networks for monitoring, control, and parameter management.
Q2: Which communication protocol does the RDNA-01 support?
A2: The module supports the DeviceNet protocol in compliance with ODVA specifications.
Q3: Can the RDNA-01 remotely control an ABB drive?
A3: Yes, it supports remote start/stop, speed reference, torque control, parameter access, and fault reset functions.
Q4: How is the RDNA-01 installed?
A4: The module is mounted into the designated option slot inside a compatible ABB drive.
Q5: What industries commonly use the RDNA-01?
A5: It is widely used in power generation, substations, water treatment, chemical processing, steel manufacturing, and industrial automation systems.
