ABB SPAS011 Analog Output Slave Module

Product Name: Analog Output Slave Module

Brand Name: ABB

Model Number: SPAS011

Place of Origin: Sweden

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Overview
Specifications
Commercial Terms
Description
Features
FAQ
Other Brand
Why Choose Us
Recommended Products

Contact Info

Sales	Email	Phone/Whatsapp
Jim Pei	[email protected]	+86 18020776782

Specifications

Product Name	ABB SPAS011 Analog Output Slave Module
Manufacturer	ABB
Product Type	Analog Output Slave Module
Part Number	SPAS011
Place of shipment	Xiamen, China
Country of origin	Sweden
Product Family	ABB Ability™ Symphony® Plus
Series	HR Series I/O Modules
Product Type	Analog Output Module
Number of Analog Output Channels	14
Channel Configuration	14 Independently Configured Channels
Resolution	10-bit per Channel
Current Output Range	4–20 mA
Voltage Output Range	1–5 VDC
Maximum Current Output Load	750 Ω
Minimum Voltage Output Load	22 Ω
+5 VDC Power Requirement	+5 VDC ±5%, 250 mA Typical
+15 VDC Power Requirement	+15 VDC ±5%, 100 mA Typical
-15 VDC Power Requirement	-15 VDC ±5%, 90 mA Typical
+24 VDC Power Requirement	+24 VDC ±10%, 310 mA Typical
Ambient Temperature	0°C to 70°C (32°F to 158°F)
Output Readback	Each output reads back the field signal
Output Calibration	Readback functionality eliminates the need to calibrate outputs
Channel Programming	Each channel can be individually programmed

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Description

The ABB SPAS011 is a 14-channel Analog Output Slave Module designed for ABB Ability™ Symphony® Plus and HR Series I/O applications. It provides 14 independently configurable analog output channels supporting standard 4–20 mA current and 1–5 VDC voltage signals with 10-bit resolution per channel. Each output includes field-signal readback functionality, helping verify actual output conditions and reducing the need for manual output calibration. With flexible channel programming and support for common industrial analog signals, the module is well suited for process control, plant automation, instrumentation, and distributed control system applications.

Features

Provides 14 analog output channels in a single module for high-density control of industrial field devices.
Each channel can be independently configured, providing flexibility for different process and instrumentation requirements.
Supports both 4–20 mA current and 1–5 VDC voltage outputs for compatibility with common industrial actuators and instruments.
10-bit resolution per channel provides consistent analog signal control for process automation applications.
Each output reads back the actual field signal, allowing the control system to verify output conditions during operation.
Integrated readback functionality eliminates the need for routine output calibration, helping simplify commissioning and maintenance.
Supports current output loads up to 750 Ω, providing flexibility for a range of connected field devices.
Independent channel programming allows different output requirements to be handled within the same module.
Designed for ABB Ability™ Symphony® Plus and HR Series I/O architectures for straightforward integration into compatible control systems.
Wide 0°C to 70°C ambient operating range supports reliable performance in demanding industrial control environments.

FAQ

Q1: What is the ABB SPAS011?
The SPAS011 is a 14-channel analog output slave module designed for compatible ABB Ability™ Symphony® Plus and HR Series I/O control systems.

Q2: How many analog output channels does the SPAS011 provide?
It provides 14 independently configurable analog output channels.

Q3: What output signal ranges does the SPAS011 support?
It supports standard 4–20 mA current outputs and 1–5 VDC voltage outputs.

Q4: Can the channels of the SPAS011 be configured individually?
Yes. Each channel of the SPAS011 can be programmed independently, allowing the module to accommodate different analog output requirements.

Q5: What is the output resolution of the SPAS011?
Each analog output channel provides 10-bit resolution.

Q6: Does the SPAS011 provide output readback?
Yes. The SPAS011 reads back the field signal for each output, allowing actual output conditions to be monitored.
