ABB TPS02 Turbine Protection Slave Module

ABB TPS02 Turbine Protection Slave Module

Product Name: Turbine Protection Slave Module

Brand Name: ABB

Model Number: TPS02

Place of Origin: SWEDEN

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

abb tps02 turbine protection slave module-1

Overview
Commercial Terms
Description
Functions
Specifications
Advantage
Performance & Efficiency
Installation & Integration
Recommended Products

Contact Info

Sales	Email	Whatsapp
Jim Pei	[email protected]	+86 18020776782

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Description

The ABB TPS02 Turbine Protection Slave Module is an industrial-grade safety and monitoring module designed for turbine protection systems within ABB control architectures. Manufactured by ABB in Sweden, it is engineered to provide reliable acquisition of critical turbine process signals, supporting safe and stable operation of rotating machinery in power generation and heavy industrial environments. With a compact form factor and rack-mounted design, the TPS02 integrates seamlessly into turbine protection systems where fast response and high reliability are essential.

The module operates on a 24 V DC power supply with ±20% tolerance and features strong electrical isolation of up to 1.5 kV DC, ensuring robust protection against electrical disturbances. It is designed to operate reliably under harsh environmental conditions, with a temperature range from -25°C to +70°C and humidity tolerance from 5% to 95% non-condensing, making it suitable for continuous operation in critical industrial applications.

Functions

Acquires digital and analog input signals for turbine protection systems.
Processes 8 × 24 V DC digital input signals for status and safety monitoring.
Supports 5 × 4–20 mA analog input channels for process measurement.
Transmits critical turbine operating data to protection and control systems.
Enables real-time monitoring of turbine operating conditions.
Supports safety interlocking and shutdown logic in turbine protection applications.
Provides electrical isolation between field signals and control systems.
Acts as a slave module within ABB turbine protection system architecture.

Specifications

Product Name	ABB TPS02 Turbine Protection Slave Module
Manufacturer	ABB
Product Type	Turbine Protection Slave Module
Part Number	TPS02
Weight	0.38kg
Estimated shipping dimensions	3.5x31x17.7cm
Place of shipment	Xiamen, China
Country of origin	SWEDEN
Digital Inputs	8 × 24 V DC
Analogue Inputs	5 × 4-20 mA
Power Supply	24 V DC ±20 %
Isolation	1.5 kV DC
Operating Temp	-25 … +70 °C (rack air)
Storage	-40 … +85 °C
Humidity	5 … 95 % RH non-condensing

Advantage

High reliability design for mission-critical turbine protection applications.
Strong electrical isolation (1.5 kV DC) enhances system safety and noise immunity.
Supports both digital and analog signal acquisition for flexible monitoring.
Compact rack-mounted design simplifies system integration.
Wide operating temperature range ensures performance in harsh environments.
High humidity tolerance supports deployment in demanding industrial conditions.
ABB engineering quality ensures long-term operational stability.
Suitable for continuous operation in power generation and heavy industry.
Enhances turbine safety through accurate real-time monitoring.
Reduces risk of equipment damage through fast protection response capability.

Performance & Efficiency

Provides reliable acquisition of multiple input signals for turbine monitoring.
Ensures fast and accurate transmission of critical safety data.
Maintains stable operation under wide environmental conditions.
Enhances turbine protection system responsiveness and reliability.
Supports continuous monitoring of key process variables.
Improves system safety efficiency through real-time signal processing.
Reduces downtime by enabling early fault detection and protective actions.
Optimized for high-reliability industrial protection environments.

Installation & Integration

The ABB TPS02 Turbine Protection Slave Module is designed for integration into ABB turbine protection and control rack systems. It connects directly to 24 V DC power and field wiring interfaces, supporting both digital and analog signal inputs from turbine instrumentation. Its rack-mounted configuration allows efficient installation alongside other protection modules, ensuring structured system architecture and simplified maintenance. With strong electrical isolation and wide environmental tolerance, the TPS02 integrates reliably into turbine control systems used in power plants and heavy industrial applications, supporting safe and coordinated turbine operation.
