Product Name: Compact Module Termination Unit
Brand Name: ABB
Model Number: TU811V1 3BSE013231R1
Place of Origin: SWEDEN
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Minimum Order Quantity |
1 Piece |
Price |
Contact for Jim |
Packaging Details |
Original new Factory Sealed |
Delivery Time |
3–7 Days |
Payment Terms |
T/T |
Shipping Method |
DHL / FedEx / UPS / TNT |
Supply Ability |
In stock |
|
Sales |
|
|
|
Jim Pei |
| Product Name | ABB TU811V1 3BSE013231R1 Compact Module Termination Unit |
| Manufacturer | ABB |
| Product Type | Compact Module Termination Unit |
| Part Number | TU811V1 3BSE013231R1 |
| Weight | 0.18 kg |
| Estimated shipping dimensions | 17x6.5x6.5cm |
| Place of shipment | Xiamen, China |
| Country of origin | SWEDEN |
| Channel Count | 8 |
| Connection Type | Terminal block |
| Operating Voltage | 250 V |
| I/O Compatibility | DI820, DI821, DO820, DO821 |
| Mounting Orientation | Horizontal and vertical |
| Operating Temperature Range | 0°C to +55°C (+32°F to +131°F) |
| Storage Temperature Range | -40°C to +70°C (-40°F to +158°F) |
| Pollution Degree | Degree 2 (IEC 60664-1) |
| Humidity | 5% to 95%, non-condensing |
| Corrosion Protection | ISA-S71.04 G3 |
| Protection Class | IP20 (IEC 60529) |
| EMC Compliance | EN 61000-6-4 (Emission), EN 61000-6-2 (Immunity) |
| Electrical Safety Standards | EN 61010-1, UL 61010-1, EN 61010-2-201, UL 61010-2-201 |
| Hazardous Location Certifications | C1 Div 2 cULus, C1 Zone 2 cULus, ATEX Zone 2 |
The ABB TU811V1 (3BSE013231R1) Compact Module Termination Unit is an interface and wiring solution designed for ABB distributed control and I/O systems. It provides a structured termination point for connecting field signals to compatible ABB I/O modules, enabling safe, organized, and reliable electrical connections within industrial automation environments. With support for 8 channels, the TU811V1 simplifies field wiring while ensuring stable signal integrity between field devices and control system modules.
Manufactured by ABB in Sweden, the TU811V1 is engineered for compact installation and high reliability in demanding industrial environments. It supports multiple ABB I/O modules such as DI820, DI821, DO820, and DO821, making it a flexible termination solution for mixed digital I/O configurations. Its compact design, robust electrical safety standards, and wide certification coverage ensure dependable operation across a broad range of process automation applications.
The TU811V1 3BSE013231R1 functions as a termination interface between field wiring and ABB I/O modules, providing a secure and organized connection point for incoming and outgoing signals. It routes electrical signals from field devices through a terminal block system to compatible digital input and output modules, ensuring accurate signal transmission and reducing wiring complexity within control cabinets.
In addition to signal termination, the module enhances system maintainability and safety by separating field wiring from electronic I/O modules. This allows for easier maintenance, faster troubleshooting, and safer replacement of I/O components without disturbing field wiring. Its support for multiple I/O module types ensures flexible integration into various control system architectures, while maintaining compliance with industrial safety and EMC standards.
The ABB TU811V1 3BSE013231R1 is designed for seamless integration within ABB automation architectures and is compatible with:
Its compact design, strong safety compliance, and flexible I/O compatibility make the TU811V1 a reliable and efficient termination solution for modern industrial automation and process control systems.
