Allen-Bradley 1746-HS IMC 110 Motion Control Module Original new

Allen-Bradley 1746-HS IMC 110 Motion Control Module Original new

Product Name:IMC 110 Motion Control Module

Brand Name:Allen-Bradley

Model Number:1746-HS

Country of Origin:USA

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

allen bradley 1746 hs imc 110 motion control module original new-1

Overview
How to get price
Specifications
Description
Applications
Environment and Certification
Features and Benefits
FAQ
Spares
Recommended Products

Overview

Brand Name:	Allen-Bradley
Model Number:	1746-HS
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

How to get price

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Manufacturer	Rockwell Automation
Brand	Allen-Bradley
Catalog Number	1746-HS
Product Series	SLC 500
Module Type	IMC 110 Motion Control Module
Controlled Axes	1 Axis
Encoder Feedback	Differential incremental encoder, up to 300 kHz
Analog Output	±10 VDC, 12-bit DAC
Fast Inputs	3 high-speed inputs
Fast Outputs	1 high-speed output
Input Voltage	24 VDC
Output Voltage	24 VDC
Backplane Current (5V)	300 mA
Backplane Current (24V)	104 mA
Update Time	4.8 ms
Motion Programming	Motion Management Language (MML)
Communication	RS-485
Memory	128 KB EPROM, 32 KB SRAM
Operating Temperature	0°C to 60°C
Storage Temperature	-40°C to 85°C
Relative Humidity	5–95% RH, non-condensing
Dimensions (H × W × D)	Approx. 145 × 35 × 145 mm (5.7 × 1.4 × 5.7 in.)
Weight	Approx. 0.45 kg

Description

The Allen-Bradley 1746-HS is a dedicated IMC 110 motion control module designed for the SLC 500 automation platform, delivering reliable single-axis motion management for demanding industrial applications. Supporting encoder feedback up to 300 kHz, the module provides accurate positioning, high-speed response, and seamless integration with SLC controllers. It is an ideal solution for servo-driven machinery requiring precise synchronization and repeatable motion performance.

As part of the Rockwell Automation motion control family, the 1746-HS, 1746-HT termination panel, and 1746-HCA connection cable create a complete motion control architecture. The system incorporates high-speed digital I/O, analog velocity output, encoder feedback processing, and emergency stop monitoring to improve machine safety and operational efficiency.

Powered by the Motion Management Language (MML), the 1746-HS simplifies complex motion programming while supporting flexible parameter configuration, online diagnostics, and offline development tools. Its modular design, dependable communication, and advanced motion capabilities make it an excellent choice for packaging systems, CNC equipment, material handling, and automated manufacturing lines requiring accurate motion control.

Applications

Power plants: Controls positioning systems for valve actuators, turbine auxiliary equipment, and high-speed servo mechanisms, improving operational precision.
Substations: Supports automated positioning devices, auxiliary motion systems, and intelligent equipment requiring synchronized motion control.
Chemical plants: Provides precise servo motion for dosing machines, filling systems, and continuous process equipment operating under demanding conditions.
Steel mills: Performs accurate motion control for rolling lines, feeding mechanisms, and heavy-duty material handling equipment exposed to vibration and heat.
Machinery manufacturing plants: Integrates with CNC machines, robotic cells, indexing tables, packaging equipment, and automated assembly systems requiring high positioning accuracy.
Material handling systems: Controls conveyors, transfer units, and positioning mechanisms to improve throughput and repeatability.
Packaging industry: Delivers synchronized axis control for labeling, cutting, sealing, and high-speed packaging machinery.

Environment and Certification

Industrial operating temperature: Supports continuous operation from 0°C to 60°C for demanding factory environments.
Wide storage capability: Withstands storage temperatures from -40°C to 85°C for transportation and long-term inventory.
Humidity resistance: Operates reliably in environments with 5–95% non-condensing humidity.
Industrial communication: Uses an RS-485 interface for dependable communication with handheld pendants and offline development systems.
Reliable emergency protection: Features hardware and software E-Stop monitoring for enhanced machine safety.
Modular installation: Compatible with SLC 500 modular racks for convenient expansion and maintenance.

Features and Benefits

Single-axis motion control: Delivers precise positioning and velocity control for servo-driven industrial equipment.
300 kHz encoder capability: Supports high-speed encoder feedback for accurate motion tracking.
Integrated Motion Management Language: Simplifies complex motion programming with structured commands and reusable routines.
High-speed digital I/O: Includes three fast inputs and one fast output for rapid machine response.
Analog servo command output: Provides ±10 V analog control signals for compatible servo drives.
Flexible programming tools: Supports Offline Development System (ODS), Syntax-Directed Editor (SDE), and handheld pendant debugging.
Built-in diagnostics: Continuously monitors encoder status, following error, communication, and emergency stop conditions.
Expandable architecture: Integrates seamlessly with 1746-HT, 1746-HCA, and SLC 500 controllers to build complete motion control solutions.

FAQ

Q1: What is the Allen-Bradley 1746-HS used for?
A1: The 1746-HS is an IMC 110 motion control module designed to provide precise single-axis motion control within SLC 500 automation systems.

Q2: How many motion axes can the 1746-HS control?
A2: The module controls one independent motion axis while supporting high-speed encoder feedback and servo drive integration.

Q3: Which programming language does the 1746-HS support?
A3: It uses Motion Management Language (MML), enabling advanced motion programming, diagnostics, and parameter management.

Q4: What encoder frequency is supported by the 1746-HS?
A4: The module supports differential incremental encoder feedback up to 300 kHz for accurate position monitoring.

Q5: Which accessories are commonly used with the 1746-HS?
A5: The module is commonly installed with the 1746-HT termination panel, 1746-HCA cable, handheld pendant, and compatible SLC 500 controller hardware.
