Allen-Bradley 1746-HT dedicated termination panel In stock

Allen-Bradley 1746-HT dedicated termination panel In stock

Product Name:dedicated termination panel

Brand Name:Allen-Bradley

Model Number:1746-HT

Country of Origin:USA

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

allen bradley 1746 ht dedicated termination panel in stock-1

Overview
Contact us
Specifications
Description
Control & Communication
Applications
Environmental Strength
FAQ
Spares
Recommended Products

Overview

Brand Name:	Allen-Bradley
Model Number:	1746-HT
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact us

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Manufacturer	Rockwell Automation
Brand	Allen-Bradley
Catalog Number	1746-HT
Product Series	SLC 500
Product Type	Servo Motion Termination Panel
Compatible Modules	1746-HSRV, 1746-HS IMC 110 Motion Control Module
Compatible Cable	1746-HCA
Mounting Method	DIN Rail Mount
Encoder Interface	Differential Encoder A/B/Z Channels
Fast I/O Support	3 Fast Inputs, 1 Fast Output
Analog Drive Interface	±10 V Analog Command Output
External Power	+5 VDC, ±15 VDC, +24 VDC User Supply
Emergency Stop	Dedicated E-Stop Circuit Connections
Drive Interface	Drive Enable, Fault Reset, Drive Ready
Communication	Terminal Interface for Motion Control System
Operating Temperature	0°C to 60°C
Storage Temperature	-40°C to 85°C
Relative Humidity	5–95% RH, Non-condensing
Dimensions	Approx. 210 × 120 × 40 mm (DIN Rail Panel)*
Weight	Approx. 0.60 kg*

Description

The Allen-Bradley 1746-HT is a dedicated termination panel designed for use with the 1746-HSRV SLC Servo Module and 1746-HS IMC 110 Motion Control Module. It provides a reliable field wiring interface for servo drives, encoder feedback, emergency stop circuits, and high-speed digital I/O, simplifying installation while improving system organization and maintenance efficiency.

Working together with the 1746-HCA connection cable, the 1746-HT delivers secure signal routing between the motion controller, servo amplifier, encoder, and external power supply. Clearly identified terminals support analog command signals, drive enable, fault reset, encoder channels, and fast input/output connections, helping reduce wiring complexity and commissioning time.

Designed for industrial motion control systems, the 1746-HT supports DIN-rail installation and is suitable for high-performance positioning, indexing, packaging, material handling, and automated manufacturing applications. Its robust terminal layout improves electrical reliability and enables seamless integration into Allen-Bradley SLC 500 motion control architectures.

Control & Communication

Provides a centralized wiring interface between motion controller and servo drive.
Supports differential encoder feedback signals for precise positioning.
Integrates analog velocity command connections for compatible servo amplifiers.
Includes dedicated terminals for Drive Enable, Drive Ready, and Fault Reset.
Supports three high-speed digital inputs and one fast output channel.
Simplifies emergency stop circuit implementation through dedicated E-Stop terminals.
Works seamlessly with the 1746-HCA cable and 1746-HSRV/1746-HS motion control modules.

Applications

Power plants: Connect servo positioning systems for turbine auxiliary equipment, actuator control, and automated maintenance machinery.
Substations: Interface motion-driven switching equipment, testing platforms, and precision positioning devices.
Chemical plants: Support automated dosing systems, conveyor positioning, and hazardous-area compatible control cabinets.
Steel mills: Provide stable wiring for servo-driven feeders, rolling equipment, and material transfer systems operating under severe electrical conditions.
Machinery manufacturing plants: Integrate servo motors, encoders, emergency stop circuits, and motion controllers for CNC machines, robotic cells, packaging equipment, and automated production lines.
Material handling systems: Enable dependable connections for conveyors, palletizers, and automated storage equipment requiring accurate positioning.
Packaging industry: Simplify high-speed servo wiring for filling, labeling, sealing, and cartoning machines.

Environmental Strength

Designed for continuous industrial operation in demanding automation environments.
Operates reliably from 0°C to 60°C with stable terminal performance.
Supports storage temperatures from −40°C to 85°C.
Suitable for 5–95% non-condensing humidity conditions.
DIN-rail mounting minimizes vibration effects and simplifies panel installation.
Clearly labeled terminals reduce wiring errors during commissioning.
Industrial terminal construction helps improve long-term electrical reliability.

FAQ

Q1: What is the 1746-HT used for?
A1: It is a termination panel that simplifies wiring between Allen-Bradley motion control modules, servo drives, encoders, and external power supplies.

Q2: Which motion controllers are compatible with the 1746-HT?
A2: It is designed for use with the 1746-HSRV Servo Module and 1746-HS IMC 110 Motion Control Module.

Q3: Does the 1746-HT support encoder feedback?
A3: Yes. It provides dedicated terminals for differential encoder A, B, and Z feedback signals.

Q4: Can the 1746-HT be DIN-rail mounted?
A4: Yes. The panel is designed for convenient DIN-rail installation inside industrial control cabinets.

Q5: What external power connections are required?
A5: The panel supports user-supplied +5 VDC, ±15 VDC, and +24 VDC power required by compatible motion control systems.
