Allen-Bradley 1746-IV32 high-density digital DC sourcing input module In stock

Allen-Bradley 1746-IV32 high-density digital DC sourcing input module In stock

Product Name:digital DC sourcing input module

Brand Name:Allen-Bradley

Model Number:1746-IV32

Country of Origin:USA

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

allen bradley 1746 iv32 high density digital dc sourcing input module in stock-1

Overview
Get your discount today
Specifications
Description
Technical Data Summary
Applications
Features and Benefits
FAQ
Spares
Recommended Products

Overview

Brand Name:	Allen-Bradley
Model Number:	1746-IV32
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Get your discount today

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Manufacturer	Allen-Bradley by Rockwell Automation
Product Model	1746-IV32 Digital DC Sourcing Input Module
Product Series	SLC 500 Modular I/O
Module Type	32-channel Digital Input Module
Number of Inputs	32 sourcing digital input channels
Input Voltage	15…30 VDC (source input, sink load)
Digital Input Type	24 VDC sourcing input
Backplane Current	106 mA @ 5V DC, 0 mA @ 24V DC
Operating Temperature	0°C to 60°C
Storage Temperature	-40°C to 85°C
Relative Humidity	5–95% RH, non-condensing
Compatibility	Compatible with SLC 500 controllers and 1747-AENTR EtherNet/IP adapter
Mounting Method	Standard 1746 SLC chassis installation
Dimensions	Approx. 145 × 35 × 142 mm (5.7 × 1.4 × 5.6 in.)
Weight	Approx. 0.24 kg (0.53 lb)

Description

The Allen-Bradley 1746-IV32 is a high-density digital DC sourcing input module designed for the SLC 500 programmable controller platform. Featuring 32 input channels, the 1746-IV32 efficiently collects field signals from sensors, switches, and industrial devices, making it well suited for large-scale automation systems requiring dependable digital input performance and simplified wiring.

Designed for compatibility with SLC 5/03, SLC 5/04, and SLC 5/05 processors, the 1746-IV32 operates with 15–30 VDC sourcing inputs and integrates seamlessly with other SLC modules including 1746-IV16, 1746-IB32, and 1746-ITV16. Its modular architecture supports flexible system expansion while maintaining reliable communication across the SLC backplane.

Built for continuous industrial operation, the 1746-IV32 offers stable signal processing, compact installation, and excellent reliability in demanding environments. It is widely used in manufacturing, material handling, process automation, packaging machinery, and OEM control systems where high-density digital input capability improves system efficiency and reduces cabinet space.

Technical Data Summary

Module Type: High-density 32-channel digital DC sourcing input module for SLC 500 PLC systems.
Input Capacity: Supports 32 independent digital sourcing input points for centralized signal acquisition.
Operating Voltage: Accepts 15–30 VDC input signals from industrial field devices.
Backplane Interface: Consumes 106 mA at 5V DC with no 24V backplane current requirement.
Environmental Rating: Designed for operation from 0°C to 60°C with storage down to -40°C.
Humidity Tolerance: Supports up to 95% non-condensing relative humidity.
Expansion Capability: Compatible with distributed I/O solutions using the 1747-AENTR EtherNet/IP adapter.

Applications

Power plants: Acquire digital status signals from generators, breakers, and auxiliary equipment for centralized PLC monitoring.
Substations: Monitor switchgear, relay contacts, and protection devices for reliable substation automation.
Chemical plants: Collect process signals from valves, pumps, sensors, and safety interlock systems.
Steel mills: Support high-density digital monitoring in rolling mills, furnaces, and heavy industrial equipment.
Machinery manufacturing plants: Integrate with automated production lines, robotic stations, packaging machines, and CNC equipment.
Water treatment facilities: Monitor pumps, level switches, and field instrumentation for process automation.

Features and Benefits

Provides 32 high-density sourcing digital inputs to reduce cabinet space and wiring complexity.
Improves PLC system scalability with seamless integration into existing SLC 500 architectures.
Supports rapid installation through modular plug-in design and standardized SLC chassis.
Delivers dependable signal acquisition for industrial sensors, switches, and control devices.
Compatible with multiple SLC processors and a wide range of Allen-Bradley digital I/O modules.
Designed for continuous operation in demanding industrial environments.
Simplifies future upgrades through support for EtherNet/IP distributed I/O migration.

FAQ

Q1: What is the 1746-IV32 used for?
A1: The 1746-IV32 is a 32-channel digital DC sourcing input module used to collect field signals in Allen-Bradley SLC 500 PLC systems.

Q2: How many input channels does the 1746-IV32 provide?
A2: It provides 32 digital sourcing input channels for high-density industrial automation applications.

Q3: What input voltage does the 1746-IV32 support?
A3: The module operates with 15–30 VDC sourcing input signals using sink-load field devices.

Q4: Which PLC systems are compatible with the 1746-IV32?
A4: It is compatible with the Allen-Bradley SLC 500 family, including SLC 5/03, SLC 5/04, and SLC 5/05 controllers.

Q5: Can the 1746-IV32 be used in distributed I/O systems?
A5: Yes. It can be integrated into distributed architectures through the 1747-AENTR EtherNet/IP adapter for flexible system expansion.
