Product Name: FLEX I/O-XT Digital DC Output Module
Brand Name: Allen-Bradley
Model Number: 1794-OB16PXT
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Minimum Order Quantity |
1 Piece |
Price |
Contact for Jim |
Packaging Details |
Original new Factory Sealed |
Delivery Time |
3–7 Days |
Payment Terms |
T/T |
Shipping Method |
DHL / FedEx / UPS / TNT |
Supply Ability |
In stock |
|
Sales: |
Email: |
Whatsapp: |
|
Jim Pei |
| Product Name | Allen-Bradley 1794-OB16PXT FLEX I/O-XT Digital DC Output Module |
| Manufacturer | Allen-Bradley |
| Product Type | FLEX I/O-XT Digital DC Output Module |
| Part Number | 1794-OB16PXT |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Number of Outputs | 16 sourcing (positive logic) |
| Output Voltage Range | 10-31.2V DC |
| Maximum Current per Point | 2A |
| Pilot Duty Rating | 2A |
| Power Dissipation (max) | 6.0W @ 31.2V DC |
| Thermal Dissipation (max) | 20.3 BTU/hr @ 31.2V DC |
| Status Indicators | 16 yellow (field side, logic driven) |
| Keyswitch Position | 2 |
| Operating Temperature | -20°C to +70°C (-4°F to +158°F) |
| Storage Temperature | -40°C to +85°C (-40°F to +185°F) |
| Relative Humidity | 5-95% noncondensing |
| Vibration | 5g @ 10-500 Hz |
The Allen-Bradley 1794-OB16PXT is a 16-channel digital DC output module designed for distributed industrial automation applications in demanding environments. It provides sourcing (positive logic) DC outputs with a wide voltage range of 10–31.2 VDC, allowing reliable control of actuators, valves, relays, and other field devices. As part of the FLEX I/O-XT platform, the module is designed for extended environmental conditions, supporting a wide operating temperature range and robust vibration resistance for use in harsh industrial applications.
Provides 16 digital DC output channels for controlling field devices.
Converts controller commands into 24 VDC switching signals for external loads.
Supports sourcing output operation for positive logic control applications.
Controls actuators, solenoids, indicators, relays, and other DC-powered equipment.
Provides individual output status indication through integrated LEDs.
Enables distributed I/O installation to reduce field wiring complexity.
Supports operation in extended temperature and industrial environments.
Compared with standard digital output modules, the Allen-Bradley 1794-OB16PXT offers higher environmental durability, greater output capacity, and flexible distributed I/O installation, making it suitable for industrial applications requiring reliable operation under challenging conditions.
