Product Name: PanelView Standard 600 Operator Interface Terminal（HMI）
Brand Name: Allen-Bradley
Model Number: 2711-K6C1
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales |
Phone/Whatsapp |
|
Jim Pei |
| Product Name | Allen-Bradley 2711-K6C1 PanelView Standard 600 Operator Interface Terminal（HMI） |
| Manufacturer | Allen-Bradley |
| Product Type | PanelView Standard 600 Operator Interface Terminal（HMI） |
| Part Number | 2711-K6C1 |
| Weight | 1.96kg |
| Estimated shipping dimensions | 29x19.1x11.5cm |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Product Series | PanelView Standard 600 |
| Product Type | Operator Interface Terminal |
| Display Type | Color Active Matrix TFT |
| Operator Input | Keypad |
| Display Area (W × H) | 115 × 86 mm (4.54 × 3.4 in.) |
| Display Resolution | 320 × 234 |
| Backlight | Field Replaceable |
| Backlight Life | 50,000 hr, 1/2 life at 25°C (77°F) |
| Keypad Type | Stainless Steel Domed Membrane |
| Keypad Keys | Keypad, Navigation and Function Keys |
| Keypad Life | 2 Million Presses |
| Function Keys | 10 (F1–F10) |
| Real-Time Clock | Battery-Backed; Timestamps Critical Data |
| Battery | Field Replaceable |
| Application Runtime Memory | 190 KB |
| Nonvolatile Memory | 240 KB |
| ATA Memory Card | Not Supported |
| Configuration Software | PanelBuilder32 |
| RS-232 Printer Port Speeds | 1200, 2400, 9600, 19,200 bps |
| DC Input Voltage | 18–32 VDC (24 VDC Nominal) |
| Maximum DC Power Consumption | 34 W (1.9 A at 24 VDC) |
| AC Input Voltage | 85–264 VAC, 47–63 Hz |
| Maximum AC Power Consumption | 60 VA |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
The Allen-Bradley 2711-K6C1 PanelView Standard 600 Operator Interface Terminal is an industrial HMI designed for machine control, process monitoring, and SLC/PLC automation applications. It features a color Active Matrix TFT display with 320 × 234 resolution, durable keypad operation, and a battery-backed real-time clock for critical data timestamps. Designed for reliable operator interaction in industrial environments, the Allen-Bradley 2711-K6C1 is well suited for manufacturing machinery, production lines, process control, equipment maintenance, and replacement of existing PanelView Standard 600 HMI terminals.
Q1: What is the Allen-Bradley 2711-K6C1 PanelView Standard 600 HMI?
The 2711-K6C1 is an industrial operator interface terminal from the PanelView Standard 600 series, designed for machine operation, process visualization, alarm monitoring, and interaction with compatible Allen-Bradley automation systems.
Q2: What type of display does the 2711-K6C1 use?
It features a color Active Matrix TFT display with a 320 × 234 resolution and a viewing area of approximately 115 × 86 mm.
Q3: How do operators control the PanelView 600 2711-K6C1?
The Allen-Bradley HMI uses a keypad with navigation controls and 10 function keys, providing durable physical operator input for industrial machinery and process applications.
Q4: What software is used to configure the 2711-K6C1 HMI?
The 2711-K6C1 uses PanelBuilder32 software for developing and maintaining compatible PanelView Standard operator interface applications.
Q5: Where is the Allen-Bradley 2711-K6C1 commonly used?
It is commonly used as an industrial HMI for manufacturing equipment, production lines, material handling, machine control, process monitoring, and established Allen-Bradley PLC automation systems.
Q6: Is the 2711-K6C1 suitable for PanelView Standard 600 replacement applications?
The 2711-K6C1 is particularly useful for maintenance and replacement in compatible existing PanelView Standard 600 installations where retaining the established HMI application and automation architecture is important.
