Bently Nevada 990-05-XX-03-CN 104M1359-01 990 Vibration Transmitter

Bently Nevada 990-05-XX-03-CN 104M1359-01 990 Vibration Transmitter

Product Name: 990 Vibration Transmitter

Brand Name: Bently Nevada

Model Number: 990-05-XX-03-CN 104M1359-01

Place of Origin: United States

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

bently nevada 990 05 xx 03 cn 104m1359 01 990 vibration transmitter-1

Overview
Get in Touch
Description
Specifications
Functions
Features
Application Scenarios
Operating Environment
Recommended Products

overview

Product Name	990 Vibration Transmitter
Brand Name	Bently Nevada
Model Number	990-05-XX-03-CN 104M1359-01
Place of Origin	USA
Warranty	12 months
Payment Methods	T/T
Shipment	DHL/UPS/EMS/Fedex...

Get in Touch

Sales	Email	Whatsapp
Jim Pei	[email protected]	+86 18020776782

Description

The Bently Nevada 990-05-XX-03-CN 104M1359-01 Vibration Transmitter is an industrial-grade monitoring device designed to convert vibration measurements from a proximity probe system into a standard 4–20 mA output signal. It is intended for OEM applications such as centrifugal compressors, small pumps, motors, and fans. The unit accepts input from a single 3300 NSv proximity probe and extension cable, providing reliable vibration measurement within a full-scale range of 0–5 mils peak-to-peak (0–125 μm pp). Its compact design and flexible mounting options make it suitable for easy integration into machinery control systems.

Specifications

Product Name	Bently Nevada 990-05-XX-03-CN 104M1359-01 990 Vibration Transmitter
Manufacturer	Bently Nevada
Product Type	990 Vibration Transmitter
Part Number	990-05-XX-03-CN 104M1359-01
Dimensions	9.8x7.3x6cm
Weight	0.46kg
Place of shipment	Xiamen, China
Country of origin	USA
Full-scale Option	05=0-5 mils pp (0-125 μm pp)
Mounting Option	03=DIN clips and screws
Input	Accepts 1 non-contacting 3300 NSv Proximity Probe and extension cable
4 to 20 mA signal output	4 to 20 mAdc over specified fullscale range in 2-wire configuration
4 to 20 mA loop accuracy	Accuracy is ±1.5% of full scale, measured from TEST input across a 250 Ω loop, excluding Prox Out scale factor
Maximum loop resistance	1,000 Ω including cable at 35 Vdc

Functions

Converts non-contact vibration signals from a 3300 NSv proximity probe into a 4–20 mA output signal
Provides continuous machinery vibration monitoring for control and diagnostic systems
Enables real-time condition assessment of rotating equipment
Supplies proportional vibration data for PLCs and industrial controllers
Supports machine protection through vibration-based monitoring

Features

Accepts input from one 3300 NSv proximity probe system
4–20 mA DC output in 2-wire configuration
Full-scale range: 0–5 mils pp (0–125 μm pp)
Loop accuracy: ±1.5% of full scale
Maximum loop resistance: 1,000 Ω (including cable at 35 Vdc)
DIN rail or bulkhead mounting options for installation flexibility
Integrated zero and span adjustment potentiometers for easy calibration
Compact and robust industrial design
High compatibility with standard industrial control systems
Stable and reliable signal conversion for vibration monitoring

Application Scenarios

Centrifugal compressors condition monitoring
Small pumps and motor vibration monitoring
Industrial fan and blower systems
OEM machinery protection systems
Process industry equipment monitoring
Industrial automation and control systems requiring analog vibration signals

Operating Environment

The 990-05-XX-03-CN 104M1359-01 990 Vibration Transmitter is designed for industrial environments with robust performance under varying temperature conditions. It operates reliably in typical machinery enclosures and control cabinet installations, supporting continuous monitoring applications. Its rugged construction ensures stable operation in industrial settings such as manufacturing plants, power systems, and process industries where vibration monitoring is critical for equipment reliability and protection.
