Brand: Bently Nevada
Series: 3300 XL 8 mm
Model: 330101-65-96-10-02-00
Official description: 3300 XL 8 mm Probe, 3/8-24 UNF Thread, Without Armor
Official source: Baker Hughes Bently Nevada datasheet 141194 Rev. AM.
Configuration note: Match the 1.0 m probe with the correct 3300 XL system components and verify machine clearance before quotation.
Part of the 3300 XL 8 mm proximity transducer system for non-contacting static position and dynamic vibration measurement. Typical system applications include radial vibration, axial position, Keyphasor and speed measurements on fluid-film bearing machinery.
|
Probe type
|
3300 XL 8 mm standard-mount probe, 3/8-24 UNF thread, without armor
|
|
Unthreaded length option 65
|
6.5 in
|
|
Overall case length option 96
|
9.6 in
|
|
Total length option 10
|
1.0 m (3.3 ft)
|
|
Connector option 02
|
Miniature coaxial ClickLoc connector, standard cable
|
|
Approval option 00
|
Agency approval not required
|
|
System linear range
|
2 mm (80 mils), approximately 0.25 to 2.3 mm from target
|
|
System scale factor
|
7.87 V/mm (200 mV/mil) ±5% for a standard 1 m system
|
|
Recommended radial gap
|
-9 Vdc, approximately 1.27 mm (50 mils)
|
|
System frequency response
|
0 to 10 kHz, +0/-3 dB
|
The unarmored standard-mount probe uses a 3/8-24 UNF case, PPS tip, AISI 303 or 304 stainless-steel case and 75 ohm FEP-insulated triaxial cable. Option 02 provides a miniature coaxial ClickLoc connector without a connector protector.
|
Probe operating and storage
|
-52°C to +177°C (-62°F to +351°F)
|
|
Cable construction
|
Standard FEP-insulated cable; no armor
|
|
Approval option
|
00 means agency approval is not required
|
|
Target basis
|
Published system performance uses an AISI 4140 steel target
|
|
Pressure sealing
|
Probe pressure-seal suitability and any required pressure test must be confirmed for the application
|
Confirm that the 6.5 in unthreaded length and 9.6 in case length fit the mounting geometry. Match the 1.0 m probe only with the correct 1.0 m 3300 XL Proximitor Sensor configuration; no extension cable is normally required for a complete 1.0 m system. Verify target material, thread engagement, probe spacing and the -9 Vdc gap setting.
|
Physical stock
|
Confirm before quotation
|
|
Condition: New, Used or Refurbished
|
Subject to verification for the quoted unit
|
|
Current product and nameplate photos
|
Available on request
|
|
Warranty period
|
Available on request and confirmed in the quotation
|
|
Dispatch time
|
Confirm before quotation
|
|
Testing status and scope
|
Subject to verification; available records can be requested
|
|
Payment methods
|
Available on request and stated on the proforma invoice
|
|
Quotation response time
|
Available on request
|
|
Transaction confidence
|
Itemized quotation, company details, invoice, pre-shipment verification and shipment records are provided as applicable
|
Is this actual stock?
Confirm before quotation for the requested quantity.
Is the unit new, used or refurbished?
Subject to verification for the specific unit offered.
Can current product and nameplate photos be provided?
Available on request before order confirmation.
What is the warranty?
Available on request and confirmed in the written quotation.
When can it ship?
Confirm before quotation after quantity and destination are known.
Has it been tested?
Subject to verification. Request the applicable test scope and available records.
Which payment methods are supported?
Available on request and listed on the proforma invoice.
How is the transaction verified?
Request an itemized quotation, company and banking details, current-unit verification, invoice and shipment documentation.
|
