Product Name:3300 XL Standard Extension Cable
Brand Name: BENTLY NEVADA
Model Number:330130-080-01-CN
Country of Origin:USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
BENTLY NEVADA |
Model Number: |
330130-080-01-CN |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
Delivery time in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Parameter |
Specification |
|
Model |
330130-080-01-CN |
|
Manufacturer |
Bently Nevada (Baker Hughes) |
|
Product Family |
3300 XL Standard Extension Cable |
|
Cable Length (Option 080) |
|
|
Cable Type (Option 01) |
|
|
Agency Approval (Option CN) |
|
|
Cable Diameter |
|
|
Conductor Material |
|
|
Shielding Type |
|
|
Core Resistance |
|
|
Jacket Resistance |
|
|
Cable Capacitance |
|
|
Maximum Rated Voltage |
|
|
Pull Strength |
|
|
Humidity Resistance |
|
|
Operating Temperature |
|
|
Weight |
|
|
Connector Type |
Gold-plated contacts |
|
System Compatibility |
3300 XL Proximity Transducer System |
|
Compliance Standards |
|
|
Country of Origin |
U.S.A. |
The 330130-080-01-CN is an 8.0-metre armored extension cable from Bently Nevada's 3300 XL series, engineered to interconnect 3300 XL proximity probes with Proximitor Sensors in critical machinery monitoring applications. The 330130-080-01-CN features 75Ω triaxial construction with foil-and-braid shielding, tinned copper conductors, and rugged stainless steel armor for superior durability. Terminated with corrosion-resistant gold-plated connectors, the 330130-080-01-CN ensures stable signal transmission across a wide –40°C to +100°C temperature range. The 330130-080-01-CN is purpose-built for steam turbine vibration monitoring and integrates seamlessly with Bently Nevada 3500 system infrastructures.
Steam Turbine Vibration Monitoring: Provides reliable signal extension for critical turbine protection systems
Centrifugal Compressor Protection: Extends sensor connectivity in high-vibration environments
Power Generation Equipment: Supports generator bearing and shaft monitoring applications
Pump and Motor Condition Monitoring: Enables remote sensor placement for predictive maintenance
Keyphasor and Speed Measurement: Connects probes for phase reference and tachometer systems
API 670 Compliant Systems: Fully supports mechanical configuration standards for proximity monitoring
Extended Reach: 8.0-metre length provides flexible routing options in large machinery installations
Superior Signal Integrity: Low-capacitance 69.9 pF/m design with foil-and-braid shielding ensures lossless transmission over extended distances
Rugged Armor Protection: Stainless steel armor delivers exceptional durability against mechanical abuse and environmental stress
Corrosion-Resistant Connectivity: Gold-plated connectors enhance conductivity, reduce signal degradation, and resist corrosion in harsh environments
Wide Temperature Tolerance: Operates reliably from –40°C to +100°C, suitable for extreme industrial conditions
Tool-Free Installation: Finger-tight ClickLoc connectors require no special tools for installation or removal
Full System Interchangeability: Eliminates the need for individual component matching or bench calibration
Parameter Specification
Operating Temperature :–40°C to +100°C (–40°F to +212°F)
Humidity Resistance :93% RH
Cable Diameter :6.2 mm (0.244 in)
Pull Strength :330 N (75 lbf)
|
141078 |
3300 XL 8 mm and 3300 5 mm Proximity Transducer System Manual. |
|
175751 |
3300 XL Multi-Purpose Stainless Steel Housing. 12”x12”x6”. Can hold up to 8 Proximitor Sensors in a DIN-mount configuration or 6 Proximitor Sensors in a panelmount configuration. (Available with ATEX Zone 0 and Zone 1 certifications.) |
|
176467 |
3300 XL Multi-Purpose Stainless Steel Housing. 12”x8”x6”. Can hold up to 4 3300XL Proximitor Sensors in both DIN-mount and panel-mount configurations. (Available with ATEX Zone 0 and Zone 1 certifications.) |
|
330181 |
3300 XL Multi-Purpose Stainless Steel Housing. 13”x9.5”x7”. Can hold up to 8 Proximitor sensors in a DIN-mount configuration or 6 Proximitor Sensors in a panelmount configuration. Primarily used by customers requiring hazardous area approvals fro their installations. Available with ATEX Zone 0 and Zone 1 and North American Division 1 and Division 2 certifications. |
|
02120015 |
Bulk field wire. 1.0 mm2 (18 AWG), 3 conductor, twisted, shielded cable with drain wire. Specify length in feet. |
|
138492-01 |
Replacement panel-mount mounting pad. |
|
138493-01 |
Replacement DIN-mount mounting pad. |
|
148722-01 |
3300 XL test plug. The 3300 XL Test Plug contains 3 small test pins attached to 3 color-coded 1-meter wires, each terminated in a banana plug. The 3-pin adapter plugs into the test pin holes on 3300 XL-style Proximitor sensors. You can use this test plug to check the performance of the Proximitor sensor from the test pin holes in the terminal strip without removing the field wiring. |
|
04310310 |
3300 XL Proximitor Sensor panelmount screw. One 6-32 UNC thread forming mounting screw. Four screws are required for each Proximitor sensor. (Screws supplied standard with Proximitor housings [3300 XL panel-mount option]). |
|
03200006 |
Silicone self-fusing tape. A 9.1- meter (10-yard) roll of silicone tape to protect connectors. This tape is easy to install and provides excellent electrical isolation and protection from the environment. We do not recommend using this tape inside the casing of the machine. |
|
40113-02 |
Connector Protector Kit. Connector Protector Kit for 3300 XL 8 mm probes and extension cables, including connector protectors and installation tools. |
|
136536-01 |
Connector protector adapter. This allows you to use connector protector installation tools manufactured prior to 1998 with 75Ω ClickLoc connectors. |
|
40180-02 |
Connector protectors. Package contains 10 pairs of connector protectors for 3300 XL 8 mm probes and extension cables. |
|
03839410 |
75Ω triaxial male connector protector. Male connector protectors install onto the extension cable and attach to the female connector protector on the probe, providing environmental protection of connectors. |
|
03839420 |
75Ω triaxial female connector protector. Female connector protectors install onto the probe lead and attach to the male connector protector on the extension cable, providing environmental protection of connectors. You can also place the connector protector onto the extension cable to slide over the connection to the Proximitor sensor to protect that connection from the environment. |
|
04301007 |
3/8-24 probe lock nut with safety wire holes. Single probe lock nut with 2 holes drilled through the nut in order to secure the lock nut in place with safety wire. |
|
04301008 |
M10 x 1 probe lock nut with safety wire holes. Single probe lock nut with 2 holes drilled through the nut in order to secure the lock nut in place with safety wire. |
|
330153-01 |
3300 XL connector kit. Used on 3300 XL 8 mm probes and extension cables. Contains 1 pair each of male and female ClickLoc connectors, 2 colorcoded sleeves, 2 pieces of slit FEP tubing, and 1 strip of silicone tape. |
|
330153-09 |
3300 XL ETR Connector Kit. Used on ETR 3300 XL 8mm probes and 3300 ETR XL extension cables. Contains one pair of male and female ClickLoc connectors, two color-coded sleeves, two pieces of high temperature slit FEP tubing, and one strip of silicon tape. |
|
163356 |
Connector Crimp Tool Kit. Includes 1 set of multiconnector inserts and connector installation instructions. Compatible only with 330153 connector kits or with probes shipped in 2003 or later with ClickLoc connectors uninstalled. Supplied with carrying case. |
