Bently Nevada 3300/16-15-01-03-00-00-02 XY/GAP Dual Vibration Monitor

Bently Nevada 3300/16-15-01-03-00-00-02 XY/GAP Dual Vibration Monitor

Product Name: XY/GAP Dual Vibration Monitor

Brand Name: Bently Nevada

Model Number: 3300/16-15-01-03-00-00-02

Place of Origin: USA

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

Overview
Commercial Terms
Description
Functions
Specifications
Advantage
Applications & Use Cases
Product Recommendations
Recommended Products

Contact Info

Sales	Email	Whatsapp
Jim Pei	[email protected]	+86 18020776782

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Description

The Bently Nevada 3300/16-15-01-03-00-00-02 XY/Gap Dual Vibration Monitor is a high-performance machinery protection module designed for the Bently Nevada 3300 System. It continuously measures and monitors two independent radial vibration channels (X and Y) along with average shaft position (gap), providing a comprehensive assessment of rotating equipment condition in real time. This integrated monitoring capability makes it particularly effective for turbines, compressors, pumps, and other critical rotating assets.

Compatible with 3300 8 mm, 3300 XL 8 mm, and 7200 series proximity probe systems, the monitor offers a full-scale range of 0–500 µm peak-to-peak and user-programmable sensitivity options. By combining vibration and shaft position monitoring within a single module, it simplifies system architecture, enhances diagnostic capabilities, and supports predictive maintenance programs aimed at maximizing equipment reliability and availability.

Functions

Monitors two independent radial vibration channels (X and Y).
Measures average shaft position (gap) simultaneously.
Processes signals from compatible proximity probe systems.
Provides continuous real-time machinery condition monitoring.
Supports user-programmable sensitivity settings.
Detects vibration-related issues such as imbalance and misalignment.
Monitors shaft movement and position changes.
Integrates into Bently Nevada 3300 monitoring system racks.
Supports machinery protection and predictive maintenance strategies.
Provides vibration and position data for plant monitoring systems.

Specifications

Product Name	Bently Nevada 3300/16-15-01-03-00-00-02 XY/GAP Dual Vibration Monitor
Manufacturer	Bently Nevada
Product Type	XY/GAP Dual Vibration Monitor
Part Number	3300/16-15-01-03-00-00-02
Weight	1.2 kg
Estimated shipping dimensions	5.1 cm x 22.9 cm x 33.0 cm
Place of shipment	Xiamen, China
Country of origin	USA
Product Family	3300 System
Full-scale Range Option	0-500 µm pp
Transducer Input Option	3300 8 mm, 3300 XL 8mm or7200 5 mm and 8 mmProximitor Sensor, 200 mV/mil
Sensitivity	100 mV/mil (4 V/mm) or200 mV/mil (8 V/mm)userprogrammable
Alarm Relay Option	7200 11 mm Proximitor庐Sensor(not XL), 100 mV/mil
Agency Approval Option	No Relays
Safety Barrier Option	Internal
Trip Multiply Option	2X

Advantage

The Bently Nevada 3300/16-15-01-03-00-00-02 combines dual-channel vibration monitoring and shaft position measurement in a single module. Compared with traditional vibration-only monitors, it delivers more comprehensive machinery diagnostics while reducing system complexity and installation requirements.

Dual XY/Gap Monitoring in One Module
Simultaneously measures radial vibration in two axes and average shaft position, providing a complete machinery condition profile.

Comprehensive Machinery Protection
Combines vibration and gap monitoring functions that would otherwise require multiple devices, simplifying system design.

High Measurement Accuracy
Supports precise vibration and shaft position monitoring for early fault detection and improved asset protection.

Flexible Probe Compatibility
Works with 3300, 3300 XL, and 7200 proximity probe systems, allowing easy integration into existing installations.

User-Programmable Sensitivity
Configurable sensitivity settings provide flexibility for different machinery types and operating conditions.

Improved Predictive Maintenance
Helps identify imbalance, misalignment, looseness, and shaft movement issues before they develop into critical failures.

Reduced Installation Complexity
Integrated monitoring functionality minimizes hardware requirements and reduces control cabinet space usage.

Applications & Use Cases

Steam and gas turbine monitoring
Centrifugal compressor protection systems
Industrial pump vibration and shaft position monitoring
Generator and motor condition monitoring
Oil and gas rotating equipment protection
Power generation machinery diagnostics
Petrochemical and refinery process equipment monitoring
Critical asset predictive maintenance programs
Machinery protection systems requiring XY vibration analysis
Industrial facilities utilizing Bently Nevada 3300 monitoring systems

The 3300/16 XY/Gap Dual Vibration Monitor is ideal for applications where both radial vibration and shaft position must be continuously monitored. Its integrated design enhances machinery protection, improves fault detection capabilities, and supports reliable operation of critical rotating equipment in demanding industrial environments.
