Product Name:3300 XL 8 mm Proximity Probes
Brand Name:Bently Nevada
Model Number:330102-03-20-10-02-05
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330102-03-20-10-02-05 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Item | Details |
|---|---|
| Model | 330102-03-20-10-02-05 |
| Product Type | 3300 XL 8 mm Proximity Probe |
| Thread Type | 3/8-24 UNF |
| Cable Type | 75Ω triaxial, FEP insulated |
| Total Length | 0.5 m – 9.0 m options |
| Output Signal | Eddy current proportional voltage |
| Operating Temp | -52°C to +177°C |
| Linear Range | Up to 2 mm |
| Weight | ~323 g/m (probe cable dependent) |
| Connector Type | ClickLoc coaxial connector |
The 330102-03-20-10-02-05 is a high-performance 3300 XL 8 mm proximity probe designed for precise vibration and position monitoring in industrial rotating machinery. As part of the Bently Nevada 3300 XL series, it operates within a complete eddy current measurement system including probe, extension cable, and Proximitor sensor.
Built for reliability in harsh environments, the system delivers a stable voltage output proportional to shaft displacement, enabling accurate monitoring of both static and dynamic conditions. It is widely applied in turbines, compressors, and fluid-film bearing machines where precision is critical.
With full compliance to API 670 standards, 330102-03-20-10-02-05 ensures interchangeability between components without recalibration, reducing maintenance effort and improving system flexibility across industrial installations.
Q1: What is the main function of 330102-03-20-10-02-05?
A1: It measures shaft vibration and position in rotating machinery using eddy current technology.
Q2: Is the 330102 probe compatible with other 3300 XL systems?
A2: Yes, it is fully interchangeable with other 3300 XL probes, cables, and sensors.
Q3: What industries use this proximity probe?
A3: It is widely used in power plants, petrochemical plants, steel mills, and manufacturing systems.
Q4: What temperature range does it support?
A4: It operates reliably from -52°C to +177°C in harsh industrial environments.
Q5: Does it require calibration during replacement?
A5: No, the system is designed for plug-and-play replacement without bench calibration.
| Number | Description |
|---|---|
| 141078 | 3300 XL 8 mm and 3300 5 mm Proximity Transducer System Manual |
| 175751 | 3300 XL Multi-Purpose Stainless Steel Housing, 12”×12”×6”, supports up to 8 DIN-mounted or 6 panel-mounted Proximitor Sensors, available with ATEX Zone 0/1 certification |
| 176467 | 3300 XL Multi-Purpose Stainless Steel Housing, 12”×8”×6”, supports up to 4 Proximitor Sensors in DIN or panel mount, ATEX Zone 0/1 certified |
| 330181 | 3300 XL Multi-Purpose Stainless Steel Housing, 13”×9.5”×7”, supports up to 8 DIN or 6 panel-mounted sensors, hazardous area approvals (ATEX Zone 0/1, North American Division 1/2) |
| 02120015 | Bulk field wire, 1.0 mm² (18 AWG), 3-conductor twisted shielded cable with drain wire, customizable length |
| 138492-01 | Replacement panel-mount mounting pad for Proximitor Sensor installation |
| 138493-01 | Replacement DIN-mount mounting pad for Proximitor Sensor installation |
| 148722-01 | 3300 XL test plug with 3-pin adapter and banana plugs for sensor performance testing without removing field wiring |
| 04310310 | Panel-mount screw for 3300 XL Proximitor Sensor, 6-32 UNC thread forming type, 4 screws required per sensor |
| 03200006 | Silicone self-fusing tape, 9.1 m roll, used for connector insulation and environmental protection |
| 40113-02 | Connector Protector Kit for 3300 XL 8 mm probes and extension cables, includes tools and protectors |
| 136536-01 | Connector protector adapter for compatibility with pre-1998 installation tools and 75Ω ClickLoc connectors |
| 40180-02 | Connector protectors package (10 pairs) for 3300 XL 8 mm probes and extension cables |
| 03839410 | 75Ω triaxial male connector protector for extension cable-side environmental protection |
| 03839420 | 75Ω triaxial female connector protector for probe-side or Proximitor sensor connection protection |
