Product Name:3300 XL 8 mm Proximity Probes
Brand Name:Bently Nevada
Model Number:330102-30-65-10-02-00
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330102-30-65-10-02-00 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Parameter | Specification |
|---|---|
| Model Number | 330102-30-65-10-02-00 |
| Product Type | 3300 XL 8 mm Armored Proximity Probe |
| Measurement Technology | Eddy Current Sensing Technology |
| Probe Diameter | 8 mm |
| Thread Type | 3/8-24 UNF |
| Unthreaded Length | 3.0 in (76.2 mm) |
| Case Length | 6.5 in (165.1 mm) |
| Total Length | 1.0 m (3.3 ft) |
| Cable Type | Standard 75Ω Triaxial Cable |
| Armor | Stainless Steel Armor |
| Connector Type | Miniature Coaxial ClickLoc Connector |
| Probe Case Material | AISI 303/304 Stainless Steel |
| Probe Tip Material | Polyphenylene Sulfide (PPS) |
| Linear Range | 2 mm (80 mils) |
| Scale Factor | 7.87 V/mm (200 mV/mil) |
| Operating Temperature | -52°C to +177°C |
| Tensile Strength | 330 N (75 lbf) |
| Weight | Approx. 0.45 kg |
| Dimension | 8 mm probe diameter, 76.2 mm unthreaded length, 165.1 mm case length, 1.0 m armored cable |
The 330102-30-65-10-02-00 is a rugged armored proximity probe from the Bently Nevada 3300 XL 8 mm series, designed to provide precise non-contact measurement of shaft vibration, axial position, and dynamic displacement in critical rotating machinery. Featuring a durable armored cable construction, this model is particularly suited for industrial environments where mechanical protection and long-term reliability are essential.
Built on advanced eddy-current sensing technology, the 330102-30-65-10-02-00 delivers stable and repeatable measurement performance across a wide operating range. The probe incorporates corrosion-resistant materials, robust connector technology, and a reinforced cable assembly to ensure dependable operation in turbines, compressors, motors, pumps, and generators.
When integrated with compatible 3300 XL Proximitor Sensors and extension system components, the 330102-30-65-10-02-00 becomes part of a complete machinery condition monitoring solution. Its high accuracy, excellent EMI/RFI immunity, and proven field performance make it ideal for predictive maintenance and equipment protection programs.
Power Plants: Generator vibration monitoring, turbine shaft position measurement, overspeed protection systems, and machinery health diagnostics.
Substations: Support critical monitoring systems, relay protection interfaces, and signal acquisition applications.
Chemical Plants: Process equipment monitoring, intrinsically safe measurement systems, and continuous machinery condition assessment.
Steel Mills: Large motor vibration monitoring, rolling mill equipment supervision, and operation in high-temperature, high-EMI environments.
Oil & Gas Facilities: Compressor vibration analysis, gas turbine condition monitoring, pump shaft displacement measurement, and rotating asset protection.
Machinery Manufacturing Plants: Automated production equipment monitoring, robotic system diagnostics, and predictive maintenance programs.
Q1: What is the primary function of the 330102-30-65-10-02-00?
A1: It provides non-contact measurement of shaft vibration, displacement, and position in rotating machinery.
Q2: Why does this model use an armored cable design?
A2: The armored cable offers additional mechanical protection in demanding industrial environments.
Q3: Is the 330102-30-65-10-02-00 compatible with 3300 XL Proximitor Sensors?
A3: Yes, it is specifically designed for integration with compatible 3300 XL system components.
Q4: Which industries commonly use this proximity probe?
A4: Power generation, oil and gas, petrochemical processing, steel manufacturing, and industrial automation industries widely deploy this model.
Q5: What are the advantages of eddy-current sensing technology?
A5: Eddy-current technology enables highly accurate, non-contact measurements with excellent reliability and long-term stability in rotating equipment applications.
| Number | Description |
|---|---|
| 148722-01 | 3300 XL Test Plug with three color-coded 1-meter leads and banana plugs for testing Proximitor Sensor performance without disconnecting field wiring. |
| 04310310 | 3300 XL Proximitor Sensor panel-mount screw, 6-32 UNC thread-forming type. Four screws required per sensor installation. |
| 03200006 | Silicone self-fusing tape, 9.1 m (10 yd) roll, providing electrical insulation and environmental protection for connectors. |
| 40113-02 | Connector Protector Kit for 3300 XL 8 mm probes and extension cables, including connector protectors and installation tools. |
| 136536-01 | Connector protector adapter for compatibility with pre-1998 installation tools used with 75Ω ClickLoc connectors. |
| 40180-02 | Package containing 10 pairs of connector protectors for 3300 XL 8 mm probes and extension cables. |
| 03839410 | 75Ω triaxial male connector protector for extension cable connections, providing environmental protection against moisture and contaminants. |
| 03839420 | 75Ω triaxial female connector protector for probe and extension cable connections, providing environmental sealing and connector protection. |
| 04301007 | 3/8-24 probe lock nut with dual safety-wire holes for secure probe mounting in vibration-prone applications. |
| 04301008 | M10 × 1 probe lock nut with dual safety-wire holes for secure installation and retention of proximity probes. |
| 330153-01 | 3300 XL Connector Kit containing male and female ClickLoc connectors, color-coded sleeves, FEP tubing, and silicone tape for cable termination and maintenance. |
