Product Name:3300 XL 8 mm Proximity Probes
Brand Name:Bently Nevada
Model Number:330103-00-25-50-02-02
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330103-00-25-50-02-02 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Details |
|
Model |
330103-00-25-50-02-02 |
|
Product Type |
8 mm Proximity Probe |
|
Thread Type |
M10 x 1 metric |
|
Total System Length |
0.5 m – 9.0 m options |
|
Linear Range |
2 mm (approx.) |
|
Operating Temperature |
-52°C to +177°C |
|
Cable Type |
75Ω triaxial (FEP/PFA) |
|
Connector Type |
ClickLoc gold-plated |
|
Weight |
0.26kg |
|
Probe Tip Material |
PPS (Polyphenylene sulfide) |
|
Dimensions |
26x18x2cm |
330103-00-25-50-02-02 is a high-precision non-contact sensor designed for vibration and position measurement in rotating machinery. As part of the Bently Nevada 3300 XL series, it integrates advanced eddy current technology to deliver stable and accurate gap voltage output proportional to target surface distance.
Built with an M10 x 1 threaded configuration, this probe supports both static and dynamic monitoring in industrial environments. It is compatible with the 3300 XL extension cable and Proximitor sensor, ensuring fully interchangeable system architecture without individual calibration requirements.
Widely used in turbine and compressor monitoring, the system ensures reliable performance under harsh operating conditions, meeting API 670 standards for mechanical stability, accuracy, and thermal consistency.
Q1: What is the 330103-00-25-50-02-02 used for?
A1: It is used for non-contact vibration and position measurement in rotating machinery such as turbines, compressors, and motors.
Q2: Is the 3300 XL 8 mm probe interchangeable with other components?
A2: Yes, it is fully interchangeable with 3300 XL extension cables and Proximitor sensors without recalibration.
Q3: What temperature range can it operate in?
A3: The probe operates reliably from -52°C to +177°C in industrial environments.
Q4: Does it support hazardous area applications?
A4: Yes, it supports certified configurations for Class I Div 2 and IECEx/ATEX environments depending on setup.
Q5: What industries commonly use this probe?
A5: It is widely used in power generation, petrochemical plants, metallurgy, and industrial automation systems.
| Number | Description |
|---|---|
| 04310310 | 3300 XL Proximitor Sensor panel-mount screw, 6-32 UNC thread-forming mounting screw; four screws required per sensor, supplied with panel-mount housings. |
| 03200006 | Silicone self-fusing tape, 9.1 m roll, used for connector protection, provides electrical insulation and environmental sealing. |
| 40113-02 | Connector Protector Kit for 3300 XL 8 mm probes and extension cables, includes protectors and installation tools. |
| 136536-01 | Connector protector adapter, allows use of pre-1998 installation tools with 75Ω ClickLoc connectors. |
| 40180-02 | Connector protectors package, includes 10 pairs for 3300 XL 8 mm probes and extension cables. |
| 03839410 | 75Ω triaxial male connector protector, provides environmental protection for extension cable connections. |
| 03839420 | 75Ω triaxial female connector protector, protects probe and extension cable connections from environmental exposure. |
| 04301007 | 3/8-24 probe lock nut with safety wire holes, designed to secure probe installation with safety wire. |
| 04301008 | M10 x 1 probe lock nut with safety wire holes, used to secure probe installation in industrial applications. |
| 330153-01 | 3300 XL connector kit including male/female ClickLoc connectors, sleeves, slit FEP tubing, and silicone tape. |
| 330153-09 | 3300 XL ETR connector kit for high-temperature applications, includes connectors, high-temp tubing, and silicone tape. |
| 163356 | Connector Crimp Tool Kit with multi-connector inserts and installation instructions, compatible with 330153 kits. |
