Product Name:3300 XL 8 mm Proximity Probes
Brand Name:Bently Nevada
Model Number:330103-03-12-05-02-00
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330103-03-12-05-02-00 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Description |
|
Model |
330103-03-12-05-02-00 |
|
Series |
Bently Nevada 3300 XL 8 mm |
|
Probe Type |
Eddy current proximity probe |
|
Thread Type |
M10 x 1 metric |
|
Probe Diameter |
8 mm |
|
Unthreaded Length |
Configurable (10 mm increments) |
|
Cable Length |
5.0 m (standard option) |
|
Connector Type |
ClickLoc coaxial connector |
|
Material |
Stainless steel probe body |
|
Weight |
0.06kg |
|
Operating Temp |
-52°C to +177°C |
|
Dimension (Probe) |
1.8x1.5x52cm |
The 330103-03-12-05-02-00 is part of the Bently Nevada 3300 XL 8 mm Proximity Probe series, designed for high-precision vibration and position monitoring in rotating machinery. Built on advanced eddy-current sensing technology, it delivers stable and accurate non-contact measurement for fluid-film bearing systems, ensuring reliable condition monitoring in demanding industrial environments.
Compatible with 3300 XL extension cables and Proximitor sensors, including models such as 330103 and 330104, this probe system supports fully interchangeable components without the need for individual calibration. Its M10 x 1 threaded design and optional armored cable construction enhance mechanical durability and installation flexibility.
Engineered for API 670 compliance, the 330103-03-12-05-02-00 provides excellent linearity, temperature stability, and EMI resistance, making it suitable for turbines, compressors, and other critical rotating assets requiring continuous protection and performance monitoring.
Q1: What is the 330103-03-12-05-02-00 used for?
A1: It is used for non-contact vibration and shaft position measurement in rotating machinery.
Q2: Is it compatible with other 3300 XL components?
A2: Yes, it is fully compatible with 3300 XL Proximitor sensors and extension cables.
Q3: Can it operate in high-temperature environments?
A3: Yes, it supports operation up to +177°C depending on configuration.
Q4: Does it require calibration after replacement?
A4: No, all 3300 XL components are interchangeable without bench calibration.
Q5: What industries commonly use this probe?
A5: It is widely used in power generation, petrochemical, steel, and machinery industries.
| Number | Description |
|---|---|
| 141078 | 3300 XL 8 mm and 3300 5 mm Proximity Transducer System Manual |
| 175751 | 3300 XL Multi-Purpose Stainless Steel Housing, 12”×12”×6”, supports up to 8 DIN-mount or 6 panel-mount Proximitor Sensors, ATEX Zone 0/1 certified |
| 176467 | 3300 XL Multi-Purpose Stainless Steel Housing, 12”×8”×6”, supports up to 4 Proximitor Sensors in DIN or panel mount configuration, ATEX certified |
| 330181 | 3300 XL Multi-Purpose Stainless Steel Housing, 13”×9.5”×7”, supports up to 8 DIN-mount or 6 panel-mount sensors, hazardous area approvals including ATEX Zone 0/1 and North American Division 1/2 |
| 02120015 | Bulk field wire, 1.0 mm² (18 AWG), 3-conductor twisted shielded cable with drain wire, length specified in feet |
| 138492-01 | Replacement panel-mount mounting pad for Proximitor sensor installation |
| 138493-01 | Replacement DIN-mount mounting pad for Proximitor sensor installation |
| 148722-01 | 3300 XL test plug with 3-pin adapter and color-coded wires for Proximitor sensor testing without removing field wiring |
| 04310310 | Panel-mount screw (6-32 UNC), required 4 pieces per Proximitor sensor, used for secure mounting |
| 03200006 | Silicone self-fusing tape, 9.1 m roll, provides insulation and environmental protection for connectors |
| 40113-02 | Connector Protector Kit for 3300 XL 8 mm probes and extension cables, includes tools and protectors |
| 136536-01 | Connector protector adapter for compatibility with pre-1998 installation tools and 75Ω ClickLoc connectors |
| 40180-02 | Connector protectors package, includes 10 pairs for environmental protection of probe and extension cable connectors |
| 03839410 | 75Ω triaxial male connector protector for extension cable-side connection protection |
| 03839420 | 75Ω triaxial female connector protector for probe and Proximitor sensor connection protection |
