Product Name:3300 XL 8 mm Proximity Probes
Brand Name:Bently Nevada
Model Number:330103-12-25-10-02-00
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330103-12-25-10-02-00 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Parameter |
Specification |
|
Product Model |
330103-12-25-10-02-00 |
|
Product Series |
3300 XL 8 mm |
|
Product Type |
Proximity Probe |
|
Thread Type |
M10 × 1 Metric |
|
Armor Option |
Without Armor |
|
Unthreaded Length |
120 mm |
|
Overall Case Length |
250 mm |
|
Cable Length |
1.0 meter |
|
Connector Type |
Miniature Coaxial ClickLoc |
|
Cable Type |
Standard Cable |
|
Linear Range |
2 mm (80 mils) |
|
Output Sensitivity |
7.87 V/mm |
|
Frequency Response |
0 to 10 kHz |
|
Probe Material |
PPS Tip + Stainless Steel Housing |
|
Operating Temperature |
-52°C to +177°C |
|
Dimension |
104x2x1.6cm |
|
Weight |
0.12kg |
330103-12-25-10-02-00 is a high-performance proximity probe from the Bently Nevada 3300 XL 8 mm Proximity Transducer System, designed for precise shaft vibration and axial position monitoring in rotating machinery. The probe features an M10 × 1 metric thread structure and delivers stable non-contact measurement performance for turbines, compressors, motors, and industrial pumps.
As part of the advanced 3300 XL series, models such as 330103 and 330104 provide excellent interchangeability, strong EMI/RFI resistance, and API 670 compliant performance. The system supports reliable vibration analysis, Keyphasor reference generation, and speed monitoring in demanding industrial environments.
With patented TipLoc and CableLoc technologies, the 330103-12-25-10-02-00 offers enhanced mechanical durability, secure cable retention, and long-term operational reliability. Its gold-plated ClickLoc connectors simplify installation and maintenance while improving environmental protection for critical machinery applications.
Power Plants:Used for steam turbine vibration monitoring and generator protection systems.
Substations:Supports auxiliary equipment monitoring and predictive maintenance applications.
Chemical Plants:Integrates with compressors, pumps, and process automation systems.
Steel Mills:Provides reliable machinery monitoring in high-temperature industrial environments.
Machinery Manufacturing Plants:Applied in automated production lines and spindle monitoring systems.
Oil & Gas Facilities:Used for compressor monitoring and turbine protection applications.
Marine & Offshore Platforms:Supports rotating machinery condition monitoring in offshore systems.
Q1: What is the main function of the 330103-12-25-10-02-00?
A1: It is used for non-contact shaft vibration and position measurement in rotating machinery.
Q2: Is the 330103-12-25-10-02-00 API 670 compliant?
A2: Yes, the 3300 XL 8 mm system fully supports API 670 standards.
Q3: What connector does this probe use?
A3: It uses a miniature coaxial ClickLoc connector for secure installation.
Q4: Can this probe operate in harsh industrial environments?
A4: Yes, it is designed for high-temperature and high-EMI industrial applications.
Q5: Does the probe support speed monitoring functions?
A5: Yes, it can be used for Keyphasor reference and rotational speed measurement.
| Number | Describe |
|---|---|
| 141078 | 3300 XL 8 mm and 3300 5 mm Proximity Transducer System Manual |
| 175751 | Multi-purpose stainless steel housing, 12”×12”×6”, supports up to 8 DIN-mount or 6 panel-mount Proximitor Sensors, ATEX Zone 0/1 certified |
| 176467 | Multi-purpose stainless steel housing, 12”×8”×6”, supports up to 4 Proximitor Sensors in DIN or panel-mount configurations |
| 330181 | Stainless steel hazardous-area housing, 13”×9.5”×7”, supports up to 8 DIN-mount or 6 panel-mount Proximitor Sensors |
| 02120015 | Bulk field wire, 1.0 mm² (18 AWG), 3-conductor twisted shielded cable with drain wire |
| 138492-01 | Replacement panel-mount mounting pad for 3300 XL Proximitor Sensor |
| 138493-01 | Replacement DIN-mount mounting pad for 3300 XL Proximitor Sensor |
| 148722-01 | 3300 XL test plug for Proximitor Sensor performance verification without removing field wiring |
| 04310310 | Panel-mount screw for 3300 XL Proximitor Sensor installation |
| 03200006 | Silicone self-fusing tape for connector insulation and environmental protection |
| 40113-02 | Connector Protector Kit for 3300 XL 8 mm probes and extension cables |
| 136536-01 | Connector protector adapter for pre-1998 installation tools with 75Ω ClickLoc connectors |
| 40180-02 | Package of connector protectors for 3300 XL 8 mm probes and extension cables |
| 03839410 | 75Ω triaxial male connector protector for extension cable environmental protection |
