Bently Nevada 330104-06-14-50-02-00 3300 XL 8 mm Proximity Probes In stock, China Bently Nevada 330104-06-14-50-02-00 3300 XL 8 mm Proximity Probes In stock Manufacturers, Suppliers, Factory

Overview

Brand Name:	Bently Nevada
Model Number:	330104-06-14-50-02-00
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Item	Description
Model	330104-06-14-50-02-00
Product Type	3300 XL 8 mm Armored Proximity Probe
Thread Type	M10 x 1
Case Length Option	140 mm (configurable range per series)
Unthreaded Length	60 mm (configurable option)
Total Cable Length	5.0 m
Connector Type	Miniature coaxial ClickLoc connector
Cable Type	Armored triaxial cable (FEP/PFA insulated)
Material	Stainless steel probe housing
Weight	0.54kg
Dimension	27x27x3cm

Description

The 330104-06-14-50-02-00 is a 3300 XL 8 mm armored proximity probe designed for high-reliability vibration and position monitoring in industrial rotating machinery. As part of the 3300 XL series, it delivers stable signal output and high measurement accuracy for critical asset protection systems in harsh environments.

Built on the 330104 probe platform, this model features an M10 x 1 threaded design with armored cable protection, ensuring enhanced mechanical durability and resistance to vibration, oil exposure, and mechanical stress. It is commonly used with Bently Nevada Proximitor sensors and extension cables for complete transducer systems.

With its advanced eddy current sensing technology, the 330104-06-14-50-02-00 supports precise shaft displacement measurement in turbines, compressors, and motors, making it suitable for predictive maintenance and condition monitoring applications across heavy industries.

Applications

Power plants: Generator set vibration monitoring and protection systems
Substations: Switchgear control, relay protection, and signal acquisition
Chemical plants: Process automation and intrinsically safe monitoring environments
Steel mills: High-temperature equipment control under strong EMI conditions
Machinery manufacturing: Automated production lines, robotics, and packaging systems

Features

Armored cable design for enhanced mechanical protection
High accuracy eddy current sensing technology
Compatible with 3300 XL Proximitor sensor systems
ClickLoc connector for fast and secure installation
Strong resistance to industrial vibration and EMI noise

Functions

Measures shaft vibration and radial displacement
Supports condition monitoring and predictive maintenance
Provides real-time machinery health feedback
Enables early fault detection in rotating equipment
Integrates with DCS and PLC monitoring systems

FAQ

Q1: What is the 330104-06-14-50-02-00 used for?
A1: It is used for vibration and shaft position monitoring in rotating machinery such as turbines, compressors, and motors.

Q2: Is the 330104 probe compatible with other 3300 XL systems?
A2: Yes, it is fully compatible with 3300 XL Proximitor sensors and extension cables.

Q3: What is the benefit of the armored cable version?
A3: The armored design improves resistance to mechanical damage, oil exposure, and harsh industrial conditions.

Q4: Can this probe be used in high-temperature environments?
A4: Yes, it supports industrial temperature ranges suitable for power and heavy industrial applications.

Q5: Does it require calibration after installation?
A5: No additional calibration is required when used within standard 3300 XL system components.

Spares

Number	Description
148722-01	3300 XL test plug with 3 test pins attached to color-coded 1-meter wires terminated in banana plugs. Used for checking Proximitor sensor performance via test pin holes without removing field wiring.
04310310	3300 XL Proximitor sensor panel-mount screw, 6-32 UNC thread-forming type. Four screws are required per Proximitor sensor assembly.
03200006	Silicone self-fusing tape, 9.1-meter roll used for connector protection, electrical insulation, and environmental sealing. Not recommended for use inside machine casing.
40113-02	Connector Protector Kit for 3300 XL 8 mm probes and extension cables, including connector protectors and installation tools.
136536-01	Connector protector adapter allowing compatibility with pre-1998 installation tools for 75Ω ClickLoc connector systems.
40180-02	Connector protectors package containing 10 pairs for 3300 XL 8 mm probes and extension cables, providing environmental connector protection.
03839410	75Ω triaxial male connector protector installed on extension cables to protect probe-to-cable connections from environmental exposure.
03839420	75Ω triaxial female connector protector installed on probe leads or extension cables to protect system connections and improve sealing reliability.
04301007	3/8-24 probe lock nut with safety wire holes for secure mechanical locking and vibration-resistant probe installation.
04301008	M10 x 1 probe lock nut with safety wire holes designed for secure fixation of proximity probes in industrial applications.
330153-01	3300 XL connector kit for 8 mm probes and extension cables. Includes male/female ClickLoc connectors, color-coded sleeves, slit FEP tubing, and silicone tape.
