Bently Nevada 330104-10-20-05-02-00 3300 XL 8 mm Probe

Bently Nevada 330104-10-20-05-02-00 3300 XL 8 mm Probe

Product Name: 3300 XL 8 mm Probe

Brand Name: Bently Nevada

Model Number: 330104-10-20-05-02-00

Place of Origin: USA

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

bently nevada 330104 10 20 05 02 00 3300 xl 8 mm probe-1

Overview
Commercial Terms
Description
Functions
Specifications
Advantage
Performance & Efficiency
Installation & Integration
Recommended Products

Contact Info

Sales	Email	Whatsapp
Jim Pei	[email protected]	+86 18020776782

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Description

The Bently Nevada 330104-10-20-05-02-00 is a 3300 XL 8 mm proximity probe designed for high-reliability vibration and position monitoring in rotating machinery. Built with an M10 × 1 threaded armored construction, it delivers stable and repeatable displacement measurements even in confined or mechanically demanding installation environments. With an unthreaded length of 100 mm, an overall case length of 200 mm, and a 0.5 meter (1.6 feet) standard cable, the probe is engineered for robust performance and flexible integration in industrial monitoring systems.

As a core component of the Bently Nevada 3300 XL system, this probe is fully compliant with API 670 requirements, ensuring consistent mechanical integrity, linear response, and temperature stability. It features a miniature coaxial ClickLoc connector for secure and reliable signal transmission and supports full interchangeability with other 3300 XL system components, eliminating the need for individual calibration or matching. Designed for harsh environments, it maintains measurement stability under high humidity conditions and incorporates Viton® O-ring sealing to prevent ingress and maintain pressure integrity at the probe interface.

Functions

Measures shaft vibration in rotating and fluid-film bearing machinery.
Monitors shaft position and dynamic displacement in real time.
Converts proximity variations into proportional electrical signals for analysis.
Supports machinery protection and condition monitoring systems.
Enables early detection of mechanical issues such as imbalance, misalignment, and looseness.
Provides input for predictive maintenance and diagnostic analysis.
Supports API 670-compliant machinery protection applications.
Ensures reliable operation under high humidity and pressure differential conditions.
Integrates into the standardized 3300 XL proximity measurement system.

Specifications

Product Name	Bently Nevada 330104-10-20-05-02-00 3300 XL 8 mm Probe
Manufacturer	Bently Nevada
Product Type	3300 XL 8 mm Probe
Part Number	330104-10-20-05-02-00
Weight	0.12kg
Estimated shipping dimensions	1.8x1.5x58cm
Place of shipment	Xiamen, China
Country of origin	USA
Unthreaded Length Option	100 mm
Overall Case Length Option	200 mm
Total Length Option	0.5 meter (1.6 feet)
Connector and Cable-Type Option	Miniature coaxial ClickLoc connector, standard cable
Agency Approval Option	Not required
Nominal Probe DC Resistance	7.45 ± 0.50 Ω
Probe Relative Humidity	Less than a 3% change in Average Scale Factor (ASF) when tested in 93% humidity in accordance with IEC standard 68 2 3 for up to 56 days.
Probe Pressure	3300 XL 8 mm probes are designed to seal differential pressure between the probe tip and case.
Probe sealing material	Viton® O ring.

Advantage

API 670 compliant design ensures high reliability and industry-standard performance.
Rugged armored M10 × 1 threaded construction for secure installation.
Excellent environmental resistance, including <3% ASF variation in 93% humidity testing.
Viton® O-ring sealing prevents contamination and enhances durability.
Fully interchangeable 3300 XL system components reduce maintenance complexity.
High mechanical stability suitable for confined and harsh industrial environments.
Reliable ClickLoc connector ensures secure and stable electrical connection.
Optional FluidLoc cable enhances protection against oil and fluid ingress.
Consistent measurement accuracy across demanding operating conditions.
Designed for long-term continuous operation in critical machinery systems.

Performance & Efficiency

Delivers precise vibration and displacement measurements for rotating equipment monitoring.
Maintains stable average scale factor with less than 3% variation under high humidity conditions (IEC 68-2-3, 56 days).
Ensures consistent signal integrity through standardized system architecture.
Supports accurate real-time machinery diagnostics and condition assessment.
Provides reliable performance under differential pressure conditions at the probe interface.
Enhances predictive maintenance efficiency by enabling early fault detection.
Reduces system downtime through interchangeable and non-calibrated replacement capability.
Optimized for continuous operation in high-demand industrial environments.

Installation & Integration

The Bently Nevada 330104-10-20-05-02-00 probe is designed for straightforward installation using its M10 × 1 threaded interface, allowing secure mounting in rotating machinery even in confined spaces. Its armored construction and 200 mm overall case length provide mechanical robustness, while the 0.5 meter cable with a miniature coaxial ClickLoc connector ensures quick, reliable electrical connection. As part of the 3300 XL system, it integrates seamlessly with extension cables and Proximitor sensors, supporting full component interchangeability without recalibration. Optional FluidLoc cable protection and Viton® sealing further enhance installation reliability in harsh industrial environments involving humidity, pressure differentials, or oil exposure.
