Bently Nevada 330130-045-03-05 3300 XL Standard Extension Cable Ready For Ship

Bently Nevada 330130-045-03-05 3300 XL Standard Extension Cable Ready For Ship

Product Name:3300 XL Standard Extension Cable

Brand Name:Bently Nevada

Model Number:330130-045-03-05

Country of Origin:USA

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

bently nevada 330130 045 03 05 3300 xl standard extension cable ready for ship-1

Overview
Get your discount today
Specifications
Description
Applications
Environment and Certification
Features and Benefits
FAQ
Spares
Recommended Products

Overview

Brand Name:	Bently Nevada
Model Number:	330130-045-03-05
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Get your discount today

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Product Model	330130-045-03-05, standard extension cable for 3300 XL proximity transducer system, ensures stable signal transmission between probe and Proximitor sensor
Cable Length	4.5 meters, provides optimized connection distance for medium-range industrial monitoring installations
Cable Type	Triaxial shielded cable, designed to reduce EMI/RFI interference and maintain signal accuracy
Connector Type	Gold-plated industrial connector, ensures secure click-lock connection and corrosion resistance
Insulation Material	FEP/PFA industrial insulation, supports high-temperature and chemical-resistant environments
Operating Temperature	-52°C to +177°C, suitable for harsh industrial and continuous operation environments
Weight	Approx. 0.30–0.35 kg, lightweight structure supports flexible installation and routing
Dimension	Cable outer diameter approx. 4–6 mm, compact design allows easy integration in tight spaces

Description

330130-045-03-05 is a 3300 XL Standard Extension Cable designed for use within Bently Nevada proximity transducer systems, ensuring stable signal transmission between probe and Proximitor sensor. It supports accurate vibration and position monitoring in rotating machinery applications, delivering reliable performance in critical industrial environments.

The 330130-045-03-05 extension cable is part of the 3300 XL 8 mm system, fully compatible with probes and sensors in the 3300 series. Its engineered triaxial construction helps maintain signal integrity while minimizing electrical noise and interference during continuous operation.

With robust insulation and industrial-grade connector options, 330130-045-03-05 ensures long-term durability under harsh operating conditions. It is widely used in turbine, compressor, and pump monitoring systems where measurement stability and interchangeability are essential.

Applications

Power plants: Used for generator vibration monitoring, shaft displacement detection, and turbine protection systems.
Substations: Supports electrical equipment monitoring, relay protection, and signal transmission for control systems.
Chemical plants: Enables safe process control integration and stable measurement in corrosive environments.
Steel mills: Provides reliable operation in high-temperature, high-EMI metallurgical production areas.
Machinery manufacturing: Applied in automated production lines, robotic systems, and precision equipment monitoring for continuous performance control.

Environment and Certification

Designed for harsh industrial environments with stable performance under high vibration and electrical noise conditions
Operates reliably across wide temperature ranges, suitable for continuous machinery monitoring applications
Resistant to EMI/RFI interference, ensuring accurate signal transmission in electrically dense industrial sites
Built with corrosion-resistant materials for long-term use in humid, chemical, and offshore environments
Supports safe integration in critical monitoring systems for rotating equipment protection
Complies with industrial EMC standards for electromagnetic compatibility in control and measurement systems
Supports RoHS environmental requirements for restricted hazardous substance compliance
Suitable for use in industrial safety-related monitoring architectures depending on system configuration

Features and Benefits

High-integrity signal transmission ensures stable vibration and displacement data transfer between probe and sensor
Triaxial shielded cable design reduces electrical noise and improves measurement accuracy
Secure industrial connector system provides reliable locking and fast installation without special tools
Flexible yet durable construction supports easy routing in compact or complex machine layouts
Strong mechanical design enhances resistance to pulling force and long-term operational stress
Fully compatible with 3300 XL proximity transducer systems for seamless system integration
Improves predictive maintenance capability by ensuring consistent signal quality in real-time monitoring
Supports reduced downtime by maintaining stable performance in critical rotating machinery systems

FAQ

Q1: What is the main function of 330130-045-03-05?
A1: It is an extension cable used to connect the proximity probe and Proximitor sensor for accurate vibration and position signal transmission.

Q2: Is 330130-045-03-05 compatible with all 3300 XL systems?
A2: Yes, it is fully compatible with Bently Nevada 3300 XL 8 mm proximity transducer systems.

Q3: What makes this cable reliable for industrial use?
A3: It uses triaxial shielding and industrial-grade insulation to ensure stable signal integrity and resistance to electrical noise.

Q4: Can it be used in high-temperature environments?
A4: Yes, it supports operation in harsh conditions ranging from -52°C to +177°C.

Q5: Where is this extension cable commonly applied?
A5: It is widely used in turbines, compressors, pumps, power plants, and heavy industrial monitoring systems.

Spares

Number	Description
148722-01	3300 XL Test Plug with three color-coded 1-meter leads and banana plugs for testing Proximitor Sensor performance without disconnecting field wiring.
04310310	3300 XL Proximitor Sensor panel-mount screw, 6-32 UNC thread-forming type. Four screws required per sensor installation.
03200006	Silicone self-fusing tape, 9.1 m (10 yd) roll, providing electrical insulation and environmental protection for connectors.
40113-02	Connector Protector Kit for 3300 XL 8 mm probes and extension cables, including connector protectors and installation tools.
136536-01	Connector protector adapter for compatibility with pre-1998 installation tools used with 75Ω ClickLoc connectors.
40180-02	Package containing 10 pairs of connector protectors for 3300 XL 8 mm probes and extension cables.
03839410	75Ω triaxial male connector protector for extension cable connections, providing environmental protection against moisture and contaminants.
03839420	75Ω triaxial female connector protector for probe and extension cable connections, providing environmental sealing and connector protection.
04301007	3/8-24 probe lock nut with dual safety-wire holes for secure probe mounting in vibration-prone applications.
04301008	M10 × 1 probe lock nut with dual safety-wire holes for secure installation and retention of proximity probes.
330153-01	3300 XL Connector Kit containing male and female ClickLoc connectors, color-coded sleeves, FEP tubing, and silicone tape for cable termination and maintenance.
