Product Name:3300 XL Standard Extension Cable
Brand Name:Bently Nevada
Model Number:330130-070-00-CN
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330130-070-00-CN |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Specification |
|
Model |
330130-070-00-CN |
|
Product Type |
Standard Extension Cable |
|
Cable Length |
7.0 m |
|
Impedance |
75Ω triaxial |
|
Conductor Type |
FEP insulated, shielded |
|
Minimum Bend Radius |
25.4 mm |
|
Operating Temp Range |
-52°C to +177°C |
|
Capacitance |
69.9 pF/m |
|
Cable Weight |
0.24kg |
|
Total Weight (approx.) |
~0.24 kg |
|
Connector Type |
ClickLoc coaxial |
|
System Compatibility |
3300 XL 8 mm system |
|
Dimension (Length) |
19.3x18.6x2.1cm |
The330130-070-00-CNis a high-reliability standard extension cable designed for the 3300 XL 8 mm proximity transducer system, ensuring stable signal transmission between probe and Proximitor sensor. It is widely used with330105,330106, and other Bently Nevada 3300 XL series components to support precise vibration and shaft position monitoring in rotating machinery.
Built with industrial-grade 75Ω triaxial construction, the330130-070-00-CNdelivers excellent electrical stability, low noise interference, and consistent performance in harsh operating environments. Its robust design supports long-distance signal integrity, making it suitable for critical monitoring applications.
Engineered for flexibility and system compatibility, the330130-070-00-CNintegrates seamlessly into API 670-compliant monitoring systems, offering reliable operation in power plants, oil & gas facilities, and heavy industrial automation setups.
Q1: What is the main use of the 330130-070-00-CN cable?
A1: It is used to connect proximity probes to Proximitor sensors for vibration and position monitoring.
Q2: Is the 330130-070-00-CN compatible with 3300 XL systems?
A2: Yes, it is fully compatible with Bently Nevada 3300 XL 8 mm transducer systems.
Q3: What is the cable length of this model?
A3: The cable length is 7.0 meters.
Q4: Can it operate in harsh industrial environments?
A4: Yes, it is designed for high temperature, vibration, and EMI environments.
Q5: What type of connector does it use?
A5: It uses gold-plated ClickLoc coaxial connectors for secure and stable connections.
| Number | Describe |
|---|---|
| 03200006 | Silicone self-fusing tape. 9.1-meter (10-yard) roll designed for connector protection, offering excellent electrical insulation and environmental sealing. Easy to apply, but not recommended for use inside machine housings. |
| 40113-02 | Connector Protector Kit for 3300 XL 8 mm probes and extension cables, including connector protectors and required installation tools. |
| 136536-01 | Connector protector adapter enabling compatibility with pre-1998 installation tools for 75Ω ClickLoc connectors. |
| 40180-02 | Connector protectors package containing 10 pairs for 3300 XL 8 mm probes and extension cables, ensuring environmental sealing of connectors. |
| 03839410 | 75Ω triaxial male connector protector designed for installation on extension cables to provide environmental protection at connection points. |
| 03839420 | 75Ω triaxial female connector protector used on probe leads and extension cables to shield connections from environmental exposure. |
| 04301007 | 3/8-24 probe lock nut with dual safety wire holes for secure mechanical fastening of probe assemblies. |
| 04301008 | M10 x 1 probe lock nut with safety wire holes designed to ensure stable probe installation and vibration resistance. |
| 330153-01 | 3300 XL connector kit including male/female ClickLoc connectors, color-coded sleeves, FEP tubing, and silicone tape for probe and cable assembly. |
