Product Name: 3300 XL Extension Cable
Brand Name: Bently Nevada
Model Number: 330130-075-00-05
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Tag
| 7.5m Extension Cable | Triple Coaxial Shielded Cable |
| Proximity Probe Cable | FEP Insulated Industrial Cable |
| Proximitor Sensor Cable | High Temperature Extension Cable |
| Vibration Monitoring Cable | ATEX Certified Cable |
| Condition Monitoring System Cable | IECEx Approved Cable |
| Industrial Sensor Cable | CSA Certified Industrial Cable |
| Machinery Protection System Component | CableLoc Connector Cable |
| 3300 XL System Accessory | ClickLoc Connector Technology Cable |
| 8mm Proximity System Cable | Oil Resistant Industrial Cable |
| RF Signal Transmission Cable |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
|
Sales |
|
|
|
Jim Pei |
| Product Name | Bently Nevada 330130-075-00-05 3300 XL Extension Cable |
| Manufacturer | Bently Nevada |
| Product Type | 3300 XL Extension Cable |
| Part Number | 330130-075-00-05 |
| Estimated shipping dimensions | 22x22x2cm |
| Weight | 0.24kg |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Cable Length Option | 7.5 meters (24.6 feet) |
| Connector Protector and Cable Option | Standard cable |
| Agency Approval Option | CSA, ATEX, IECEx Approvals |
| Nominal Extension Cable DC Resistance | 1.65 ± 0.25 Ω |
| Resistance (RJACKET ) from Outer Conductor to Outer Conductor | 0.49 ± 0.10 Ω |
| Operating and Storage Temperature | -52°C to +177°C (-62°F to +350°F) |
The Bently Nevada 330130-075-00-05 is a 7.5-meter 3300 XL standard extension cable designed for use in proximity measurement and machinery condition monitoring systems. It provides a reliable electrical interface between the 3300 XL 8 mm proximity probe and the Proximitor® sensor, ensuring accurate transmission of modulated RF signals within industrial vibration monitoring applications. The cable is fully compatible with the 3300 XL transducer system and integrates seamlessly into 3500 monitoring architectures.
Engineered for harsh industrial environments, the cable features FEP-insulated conductors, triple-coaxial shielding, and a durable protective jacket to maintain signal integrity while resisting oil, moisture, and electromagnetic interference. With CSA, ATEX, and IECEx certifications, it is suitable for use in hazardous locations and high-demand industrial installations.
In addition to its robust construction, the 330130-075-00-05 incorporates patented CableLoc™ and ClickLoc™ connector technologies to enhance mechanical strength and electrical reliability. It plays a critical role in the overall measurement chain, supporting vibration, position, and Keyphasor monitoring with stable performance across extreme temperature conditions.
Hardware-only passive component
The 330130-075-00-05 extension cable is a passive hardware element and does not require any embedded software, firmware setup, or electronic configuration. It functions purely as a signal transmission medium within the 3300 XL proximity measurement chain.
Physical system installation
The cable is installed between the 3300 XL 8 mm proximity probe and the Proximitor® sensor. Proper routing and secure connector engagement using CableLoc™ and ClickLoc™ systems are essential to ensure stable mechanical and electrical performance.
Channel-based deployment
Each vibration monitoring channel requires one dedicated extension cable depending on the physical distance between the probe and the monitoring equipment. The system layout determines cable quantity and routing requirements.
Automatic system compatibility
Once installed, the cable operates transparently within the 3300 XL or compatible 3500 monitoring system. No manual configuration or parameter tuning is required, as the system automatically interprets the signal path characteristics.
Built-in diagnostic recognition
The monitoring system continuously evaluates electrical properties such as resistance and capacitance. Any deviation beyond specified tolerances is automatically detected as a fault condition, indicating potential cable damage or connection issues.
No calibration requirement
The extension cable does not require calibration during installation or maintenance. It is factory-standardized and fully interchangeable within approved Bently Nevada transducer system configurations.
