Bently Nevada 330194-00-07-10-05 3300 XL 8 mm Extended Temperature Range (ETR) Proximity Probes Ready For Ship

Bently Nevada 330194-00-07-10-05 3300 XL 8 mm Extended Temperature Range (ETR) Proximity Probes Ready For Ship

Product Name:3300 XL 8 mm Extended Temperature Range Proximity Probes

Brand Name:Bently Nevada

Model Number:330194-00-07-10-05

Country of Origin:USA

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

bently nevada 330194 00 07 10 05 3300 xl 8 mm extended temperature range etr proximity probes ready for ship-1

Overview
Get your discount today
Specifications
Description
Applications
Environment and Certification
Features & Benefits
FAQ
Spares
Recommended Products

Overview

Brand Name:	Bently Nevada
Model Number:	330194-00-07-10-05
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Get your discount today

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Probe Type:	330194-00-07-10-05, 3300 XL 8 mm proximity probe with armored cable option for harsh industrial environments.
Thread Type:	M10 × 1 metric thread, designed for secure mounting and stable mechanical alignment in rotating equipment.
Measurement Range:	0.25–2.3 mm linear range, supports accurate vibration and shaft displacement monitoring.
Output Sensitivity:	Approximately 7.87 V/mm (200 mV/mil), ensuring high-resolution signal conversion.
Cable Type:	75 Ω triaxial cable with optional armored protection for high-temperature and oil-resistant applications.
Dimensions:	Probe length configurable (0.5 m to 9 m system options), compact M10 probe head for tight installations.
Weight:	Approx. probe weight 0.3–0.35 kg depending on configuration, lightweight for easy mounting and maintenance.
Operating Temperature:	Probe tip -51°C to +177°C, cable up to +260°C (ETR version), suitable for extreme environments.

Description

The 330194-00-07-10-05 is part of the Bently Nevada 3300 XL 8 mm proximity probe series, engineered for precise vibration and shaft position monitoring in industrial rotating machinery. Designed with an M10 × 1 threaded structure and extended temperature capability, it ensures stable signal performance in demanding environments such as turbines, compressors, and generators.

Built on the advanced 3300 XL eddy current transducer platform, the probe delivers highly linear output and strong immunity to electrical noise, supporting reliable condition monitoring and protection systems. Its interchangeable architecture allows seamless compatibility with 3300 XL extension cables and Proximitor sensors.

With rugged construction, flexible configuration options, and high thermal resistance, the 330194-00-07-10-05 provides dependable performance for critical asset protection and predictive maintenance applications across heavy industries.

Applications

Power plants: Used for turbine shaft vibration monitoring, rotor position detection, and generator protection systems.
Substations: Supports critical rotating auxiliary equipment monitoring and electrical asset condition diagnostics.
Chemical plants: Enables continuous monitoring of pumps, compressors, and process-critical rotating machinery.
Steel mills: Provides reliable performance under high heat, dust, and strong electromagnetic interference conditions.
Machinery manufacturing: Applied in automated production lines, CNC systems, and robotic assembly equipment monitoring.
Oil & gas industry: Suitable for compressors, gas turbines, and pipeline pump condition monitoring systems.

Environment and Certification

Operating Environment: Designed for harsh industrial conditions, including high vibration, oil exposure, and temperature fluctuations, ensuring stable long-term signal output.
Temperature Resistance: Standard operation from -51°C to +177°C, with extended cable options supporting up to +260°C for high-heat installations.
Electrical Protection: Strong EMI/RFI immunity enables reliable performance in electrically noisy industrial environments.
Certification Compliance: Meets API 670 mechanical monitoring standards for vibration and position measurement in rotating machinery.
Safety Approvals: Available with ATEX, IECEx, and North American hazardous area certifications for use in explosive gas environments.
Mechanical Durability: Stainless steel housing and reinforced probe structure ensure resistance to mechanical stress and industrial wear.

Features & Benefits

High-precision eddy current measurement: Delivers stable, linear output for accurate shaft vibration and displacement monitoring in rotating machinery.
3300 XL platform compatibility: Fully integrates with Bently Nevada 3300 XL extension cables and Proximitor sensors, ensuring flexible system configuration and easy replacement.
Extended temperature capability (ETR option): Supports harsh environments with probe tip operation up to 177°C and cable tolerance up to 260°C for high-heat applications.
Robust mechanical construction: Stainless steel housing and reinforced probe design improve durability against vibration, oil exposure, and industrial wear.
Excellent noise immunity: Strong resistance to EMI/RFI interference ensures reliable signal integrity in electrically noisy plant environments.
Flexible installation design: M10 × 1 threaded body and armored cable options allow secure mounting in tight or demanding industrial spaces.
Predictive maintenance support: Enables early detection of mechanical faults, reducing unplanned downtime and improving asset reliability in critical systems.

FAQ

Q1: What is the main use of the 330194-00-07-10-05 probe?
A1: It is used for vibration and shaft position monitoring in rotating machinery such as turbines, compressors, and generators.

Q2: Is the 330194 compatible with other 3300 XL components?
A2: Yes, it is fully compatible with 3300 XL extension cables and Proximitor sensors for interchangeable system integration.

Q3: Can it operate in high-temperature environments?
A3: Yes, the probe supports up to 177°C at the tip and up to 260°C for extended temperature cable versions.

Q4: What industries commonly use this probe?
A4: It is widely used in power generation, petrochemical, steel manufacturing, and machinery automation industries.

Q5: Does it meet industrial safety standards?
A5: Yes, it complies with API 670 and can be supplied with ATEX and IECEx hazardous area certifications.

Spares

Number	Description
148722-01	3300 XL Test Plug with three color-coded 1-meter leads and banana plugs for testing Proximitor Sensor performance without disconnecting field wiring.
04310310	3300 XL Proximitor Sensor panel-mount screw, 6-32 UNC thread-forming type. Four screws required per sensor installation.
03200006	Silicone self-fusing tape, 9.1 m (10 yd) roll, providing electrical insulation and environmental protection for connectors.
40113-02	Connector Protector Kit for 3300 XL 8 mm probes and extension cables, including connector protectors and installation tools.
136536-01	Connector protector adapter for compatibility with pre-1998 installation tools used with 75Ω ClickLoc connectors.
40180-02	Package containing 10 pairs of connector protectors for 3300 XL 8 mm probes and extension cables.
03839410	75Ω triaxial male connector protector for extension cable connections, providing environmental protection against moisture and contaminants.
03839420	75Ω triaxial female connector protector for probe and extension cable connections, providing environmental sealing and connector protection.
04301007	3/8-24 probe lock nut with dual safety-wire holes for secure probe mounting in vibration-prone applications.
04301008	M10 × 1 probe lock nut with dual safety-wire holes for secure installation and retention of proximity probes.
330153-01	3300 XL Connector Kit containing male and female ClickLoc connectors, color-coded sleeves, FEP tubing, and silicone tape for cable termination and maintenance.
