Product Name:Aeroderivitive GT Vibration Monitor
Brand Name:Bently Nevada
Model Number:3500/44M 176449-99
Country of Origin:USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
3500/44M 176449-99 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Item | Specification |
|---|---|
| Model | 3500/44M 176449-99 |
| Channels | 4-channel vibration monitoring |
| Power Consumption | 7.7 W (typical) |
| Input Types | Accelerometer, Velomitor, Prox/Velom interface |
| Input Impedance | >95 kΩ (Aero GT I/O) |
| Output Signal | 4–20 mA recorder output per channel |
| Buffered Output | Coaxial per channel, short-circuit protected |
| Output Impedance | 550 Ω |
| Dimensions (Main Module) | 241.3 × 24.4 × 241.8 mm |
| Dimensions (I/O Module) | 241.3 × 24.4 × 99.1 mm |
| Weight (Main Module) | 0.91 kg |
| Weight (I/O Module) | 0.45 kg |
| Communication | 3500 rack backplane system |
| Mounting | Full-height rack slot |
| Compliance | CE, EMC, RoHS, IEC 61000 series |
The 3500/44M 176449-99 Aeroderivative GT Vibration Monitor is a four-channel condition monitoring module designed for advanced gas turbine protection and performance diagnostics. It continuously evaluates vibration signals from aeroderivative machinery, comparing real-time data against configured alarm thresholds to ensure early fault detection and reliable operational safety.
The system supports multiple input types through dedicated Aero GT I/O interfaces, enabling compatibility with accelerometers and Velomitor sensors. It provides flexible signal conditioning, including band-pass filtering, signal integration, and 1X vibration tracking for precise machine behavior analysis across different operating modes.
With dual Keyphasor input capability and configurable alarm logic, the 3500/44M enhances turbine protection strategies and supports maintenance decision-making. It integrates seamlessly within the Bently Nevada 3500 platform, delivering stable communication, fast response, and high diagnostic accuracy for critical rotating equipment.
Q1: What is the function of the 3500/44M module?
A1: It monitors turbine vibration signals and triggers alarms based on predefined safety thresholds.
Q2: How many channels does the 3500/44M support?
A2: It supports four independent vibration monitoring channels.
Q3: Which sensors are compatible with this module?
A3: It works with accelerometers, Velomitor sensors, and Prox/Velom interface modules.
Q4: Can it operate in different machine modes?
A4: Yes, it supports multimode configuration with adjustable filtering and alarm sets.
Q5: Is the module suitable for industrial turbine applications?
A5: Yes, it is designed specifically for aeroderivative gas turbines and critical rotating machinery.
