Product Name:60M100 Condition Monitoring System
Brand Name:Bently Nevada
Model Number:60M100 MONITOR 60M100-00
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
60M100 MONITOR 60M100-00 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Item | Details |
|---|---|
| Product Model | 60M100 MONITOR (60M100-00) |
| System Type | Wind turbine condition monitoring system |
| Power Supply | 18–36 VDC |
| Power Consumption | Max 1.7 A |
| Input Channels | Up to 12 dynamic + 2 Keyphasor |
| Sampling Resolution | 24-bit Sigma-Delta ADC |
| Bandwidth | 0 – 40 kHz |
| Communication | Ethernet TCP/IP (Modbus/TCP supported) |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -45°C to +85°C |
| Humidity | 0–95% non-condensing |
| Dimension | 225 × 150 × 55 mm |
| Weight | 1.4 kg |
| Mounting Type | DIN rail mounting |
The 60M100 MONITOR (60M100-00) is an advanced wind turbine condition monitoring system designed for continuous machine health assessment. It applies high-performance digital signal processing and state-based analytics to detect early-stage faults in critical turbine components, helping operators improve reliability and reduce unexpected downtime.
The 60M100 MONITOR 60M100-00 supports predictive maintenance strategies by identifying mechanical anomalies months before failure occurs. Integrated with accelerometers, Keyphasor inputs, and Ethernet communication, it enables real-time vibration analysis, waveform tracking, and alarm management across complex wind farm installations.
Engineered for industrial-grade performance, the 60M100 MONITOR delivers high-resolution data acquisition with robust 24-bit processing and configurable monitoring channels. Its modular architecture ensures flexible deployment in standalone, networked, or OEM-integrated systems, making it suitable for large-scale renewable energy infrastructure.
Q1: What is the main function of the 60M100 MONITOR?
A1: It provides continuous condition monitoring and early fault detection for wind turbine machinery.
Q2: How many input channels does 60M100-00 support?
A2: It supports up to 12 dynamic channels and 2 Keyphasor inputs.
Q3: Can the system be used in a network configuration?
A3: Yes, it supports standalone, distributed, and networked monitoring setups.
Q4: Does 60M100 MONITOR support remote communication?
A4: Yes, it uses Ethernet TCP/IP with Modbus/TCP for system integration.
Q5: What industries commonly use this system?
A5: It is widely used in wind energy, power plants, substations, and heavy industrial environments.
| Number | Description |
|---|---|
| 323394 | Turningpoint TP100 Accelerometer, 100 mV/g, 0.5–14,000 Hz |
| 200355 | Low Frequency Accelerometer, 100 mV/g, 0.2–10,000 Hz |
| 287844 | Accelerometer Mounting Stud, 1/4-28 to M8x1.25 SST |
| 284613-050 | Accelerometer Cable, 15.2 m (50 ft), straight connector |
| 284613-030 | Accelerometer Cable, 9.1 m (30 ft), straight connector |
| 284622-050 | Accelerometer Cable, 15.2 m (50 ft), right-angle connector |
| 284622-030 | Accelerometer Cable, 9.1 m (30 ft), right-angle connector |
| 138131 | CAT5 Cable for industrial communication (3–320 ft length options) |
| 323314-01 | Buffered Output Cable, 15-pin DSUB to 7 SMA connectors |
| 323314-02 | Buffered Output Cable, 15-pin DSUB to 7 BNC connectors |
| 122M4926 | Right-angle mounted accelerometer, 1200 mV/g, 1.0–10,000 Hz |
| 151M9812 | Surge Protector for industrial electrical protection |
| 284005 | Surge Protector Cover |
| 104M4408-01 | 3701/60A to 60M100 Retrofit Mounting Kit |
| 122M3999 | Power Supply, 110/220 Vac to 24 Vdc, 2.1 A DIN Rail Mount |
| 04425545 | Grounding Wrist Strap, single use anti-static protection |
| 122M3999 | Power Supply Module, AC to 24 Vdc DIN rail type |
