Product Name:Dual Epoxy Relays
Brand Name:Bently Nevada
Model Number:81545-01
Country of Origin:USA
Warranty:12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
81545-01 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Item | Specification |
|---|---|
| Product Model | 81545-01: Dual epoxy relay module for Bently Nevada 3300 monitoring system alarm output switching |
| Module Type | Relay module: Provides dual-channel switching for monitoring alarm and protection signals |
| Relay Configuration | Dual epoxy relays: Sealed relay design for stable and durable switching performance |
| Compatible System | 3300 series racks: Designed for integration with Bently Nevada vibration monitoring systems |
| Function Type | Alarm output control: Supports Alert and Danger signal relay activation |
| Input Interface | Monitor-driven signal: Receives logic signals from system monitor channels |
| Output Type | Dry contact relay output: Provides switching for external control or shutdown circuits |
| Mounting Type | Rack-mounted module: Installed behind 3300 system monitor in dedicated slot |
| Operating Temperature | Industrial range: Suitable for control room and plant monitoring environments |
| Dimension | Standard 3300 rack module size, compact plug-in relay assembly design |
| Weight | Approx. 1.0 kg: Lightweight modular design for easy replacement and maintenance |
| Material | Epoxy sealed construction: Provides protection against vibration and electrical stress |
| Certification | Industrial certified: Suitable for hazardous and heavy-duty industrial monitoring systems |
The 81545-01 is a dual epoxy relay module designed for use in Bently Nevada 3300 monitoring systems, providing reliable signal switching for critical machinery protection applications. It is part of the spare relay module assembly series, ensuring stable alarm and control output functionality in industrial vibration monitoring racks.
As a key configuration within the 3300 system relay options, including 81544-01 (No Relays), 81546-01 (Dual Hermetic Relays), and 85119-01 (Quad Relay Module), the 81545-01 delivers robust dual-channel relay switching performance for Alert and Danger alarm outputs. It ensures consistent operation under continuous monitoring conditions.
Built for industrial environments, the 81545-01 supports high-reliability alarm processing in turbine, compressor, and rotating equipment protection systems. Its epoxy-sealed relay design enhances durability, making it suitable for long-term operation in vibration-intensive and electrically noisy environments.
Q1: What is the 81545-01 used for?
A1: The 81545-01 is used to provide dual relay output switching for alarm and protection signals in 3300 monitoring systems.
Q2: What type of relays does 81545-01 use?
A2: It uses dual epoxy-sealed relays designed for stable and durable industrial switching performance.
Q3: Which system is compatible with 81545-01?
A3: It is compatible with Bently Nevada 3300 series vibration monitoring racks.
Q4: What is the difference between 81545-01 and 81544-01?
A4: The 81545-01 includes dual epoxy relays, while 81544-01 is a no-relay configuration module.
Q5: Is 81545-01 suitable for harsh environments?
A5: Yes, it is designed for vibration-heavy and electrically noisy industrial environments such as turbines and compressors.
