Product Name:Accelerometer
Brand Name: BENTLY NEVADA
Model Number:200350-02-00-00-00
Country of Origin:USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
BENTLY NEVADA |
Model Number: |
200350-02-00-00-00 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
Delivery time in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Parameter |
Specification |
|
Model |
200350-02-00-00-00 |
|
Manufacturer |
Bently Nevada (Baker Hughes) |
|
Product Family |
200350 Series Accelerometers |
|
Sensor Type |
Constant-current piezoelectric accelerometer |
|
Sensing Element |
Ceramic, shear geometry |
|
Housing Material |
Stainless steel, welded hermetic seal |
|
Mounting Thread |
¼-28 female |
|
Mounting Stud |
¼-28 SS with brass tip, 0.5″ |
|
Sensitivity |
100 mV/g ±20% (10.2 mV/m/s² ±20%) |
|
Measurement Range |
±50 g peak |
|
Frequency Range (±3 dB) |
30–600,000 cpm (0.5–10,000 Hz) |
|
Transverse Sensitivity |
≤7% |
|
Amplitude Linearity |
±1% |
|
Mounted Resonant Frequency |
1,500 kcpm (25 kHz) |
|
Broadband Electrical Noise (1–10 kHz) |
350 μg (3,434 μm/s²) |
|
Output Bias Voltage |
8 to 12 VDC |
|
Excitation Voltage |
18 to 28 VDC |
|
Constant Current Excitation |
2 to 20 mA |
|
Settling Time (within 1% of bias) |
≤2.0 sec |
|
Output Impedance |
<150 ohms |
|
Discharge Time Constant |
≥0.3 sec |
|
Electrical Isolation (Case) |
>10⁸ ohms |
|
Operating Temperature Range |
–54°C to +121°C (–65°F to +250°F) |
|
Shock Survivability |
5,000 g peak |
|
Relative Humidity |
100% condensing, non-submerged |
|
Enclosure Rating |
IP68 |
|
Hex Size |
11/16″ (18 mm) |
|
Height |
1.65″ (42.4 mm) |
|
Weight |
1.8 oz (51 grams) |
|
Mounting Torque (Maximum) |
2 to 5 ft-lb (2.7 to 6.8 N·m) |
|
Electrical Connector |
2-pin MIL-C-5015, top-mounted |
|
Recommended Max Cable Length |
104 ft (31 m) |
|
Hazardous Area Approvals |
CSA, ATEX, IECEx (per option 01) |
|
Certifications |
CE, RoHS, FCC |
The 200350-02-00-00-00 is a general-purpose, case-mounted seismic accelerometer from Bently Nevada‘s 200350 series, engineered for vibration monitoring on rotating machinery and critical industrial assets. The 200350-02-00-00-00 incorporates a piezoelectric ceramic sensing element in a shear configuration, generating an electrical charge proportional to applied acceleration. Housed within a hermetically sealed stainless steel enclosure, the 200350-02-00-00-00 delivers a 100 mV/g sensitivity with ±20% tolerance and a broad frequency response from 0.5 to 10,000 Hz. The 200350-02-00-00-00 features a ¼-28 stainless steel mounting stud with brass tip and a top-mounted 2-pin MIL-C-5015 connector for straightforward installation and cable integration.
Turbomachinery Monitoring: Steam turbines, gas turbines, and hydro turbines for housing vibration tracking
Compressor Protection: Centrifugal and reciprocating compressors in oil, gas, and refinery environments
Pump Condition Monitoring: Industrial pumps, cooling tower fans, and water circulation equipment
Motor and Generator Health: Electric motors and generators for bearing housing vibration assessment
General Rotating Equipment: Fans, blowers, and other machinery requiring casing-mounted vibration sensing
Trendmaster Pro Systems: Directly interfaces with Trendmaster Pro Constant Current Direct Input Card (149811-02) and Seismic Direct Input Card (164746-01)
Hermetically Sealed Stainless Steel Housing: Welded construction provides IP68-rated protection against moisture, contaminants, and harsh industrial environments
Piezoelectric Shear Sensing Element: Ceramic sensor with shear geometry delivers stable, repeatable performance across a wide frequency range
Top-Mounted MIL-C-5015 Connector: 2-pin connector enables easy installation and removal of signal cables without special tools
Wide Operating Temperature Range: Reliable from –54°C to +121°C (–65°F to +250°F)
High Shock Survivability: Withstands 5,000 g peak shock for durability in demanding applications
Multiple Mounting Options: ¼-28 female thread accommodates various studs, adhesive mounts, and magnetic bases
Hazardous Area Ready: CSA, ATEX, and IECEx certified for installation in classified locations (with appropriate approvals option)
Vibration-to-Electrical Signal Conversion: The piezoelectric element generates an electrical charge when subjected to mechanical vibration
Charge-to-Voltage Translation: An internal electronic converter transforms the generated charge into a differential voltage signal proportional to acceleration
Directional Sensing: Measures acceleration parallel to the transducer‘s sensitive axis only
Constant-Current Operation: Powered by an external 18–28 VDC source with 2–20 mA constant current excitation
Output Signal Transmission: Delivers a voltage output (8–12 VDC bias) proportional to vibration amplitude for analysis by monitoring systems
Seismic Transduction: Detects casing or bearing housing vibration transmitted from rotor dynamic activity
|
