Home > Products > EMERSON > EMERSON Delta V
Product Name: Eddy Current Sensor
Brand Name: EMERSON
Model Number: PR6423/10R-131 CON031
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Minimum Order Quantity |
1 Piece |
Price |
Contact for Jim |
Packaging Details |
Original new Factory Sealed |
Delivery Time |
3–7 Days |
Payment Terms |
T/T |
Shipping Method |
DHL / FedEx / UPS / TNT |
Supply Ability |
In stock |
|
Sales |
|
|
|
Jim Pei |
| Product Name | EMERSON PR6423/10R-131 CON031 Eddy Current Sensor |
| Manufacturer | EMERSON |
| Product Type | Eddy Current Sensor |
| Part Number | PR6423/10R-131 CON031 |
| Estimated shipping dimensions | 16x16x2cm |
| Weight | 0.24kg |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Output Signal | Linear |
| Power Supply | 220V AC |
| Operating Frequency | 30kHz |
| Linear Measurement Range | 2 mm (80 mils) |
| Initial Air Gap | 0.5 mm (20 mils) |
| Incremental Scale Factor (ISF) | ISO: 8 V/mm (203.2 mV/mil) ± 5% @ temperature range 0 to 45°C (+32 to +113°F) |
| Protection Class | IP66, IEC 60529 |
| Operating Temperature Range | Sensor incl. 1m Cable: -35 to +180°C (-31 to 356°F) Cable & Connector: -35 to +150°C (-31 to 302°F) |
| Target Material (Ferromagnetic Steel) | 42CrMo4 (AISI/SAE 4140) Standard Other (On Request) |
The EMERSON PR6423/10R-131 CON031 is a high-precision non-contact measurement device designed for accurate distance, vibration, and position monitoring in industrial machinery. It uses advanced eddy current induction technology to measure displacement without physical contact, reducing mechanical wear and improving long-term system reliability.
Built with a compact and rugged housing, the sensor is engineered for harsh industrial environments, including extreme temperatures and demanding operational conditions. It provides a linear output signal that can be easily integrated into PLC, DCS, and other industrial automation systems for real-time monitoring and control.
The sensor supports a 2 mm linear measurement range with high sensitivity and stability, making it suitable for critical applications requiring precise and continuous measurement of rotating or vibrating components.
High Measurement Accuracy
The EMERSON PR6423/10R-131 CON031 delivers precise displacement measurement with high sensitivity and stable linear output, ensuring reliable monitoring in critical applications.
Non-Contact Measurement
Eddy current technology enables measurement without physical contact, reducing mechanical wear and extending equipment lifespan.
Strong Environmental Resistance
The sensor is designed with IP66 protection and operates reliably in temperatures ranging from -35°C to +180°C, making it suitable for harsh industrial environments.
Easy System Integration
With a standard linear output signal, the sensor integrates easily into PLC, DCS, and other industrial automation systems.
High Reliability Design
Robust construction ensures stable performance under vibration, pressure variations, and long-term industrial operation.
Maintenance Efficiency
Non-contact operation reduces maintenance requirements and simplifies troubleshooting, improving overall system uptime.
The EMERSON PR6423/10R-131 CON031 provides highly stable and accurate measurement performance with a linear measurement range of 2 mm and an Incremental Scale Factor of 8 V/mm (±5%), ensuring precise detection of small displacement changes. Its 30 kHz operating frequency enables fast response and reliable tracking of dynamic vibration and position variations in rotating machinery.
Designed for demanding industrial environments, the sensor maintains stable operation across a wide temperature range from -35°C to +180°C and is protected by an IP66-rated enclosure, ensuring resistance to dust, moisture, and harsh environmental conditions. This robust design supports continuous and reliable performance even in high-stress industrial applications.
The sensor improves operational efficiency by providing a direct linear output signal compatible with automation systems, enabling real-time monitoring and faster decision-making. Its non-contact measurement principle reduces mechanical wear, minimizes maintenance needs, and enhances overall system availability and lifecycle performance.
1. What protection rating does the PR6423/10R-131 CON031 have?
The PR6423/10R-131 CON031 has an IP66 protection rating for dust and water resistance.
2. What technology does the PR6423/10R-131 CON031 use?
The PR6423/10R-131 CON031 uses eddy current induction technology for precise non-contact sensing.
3. What is the measurement range of the PR6423/10R-131 CON031?
The PR6423/10R-131 CON031 supports a 2 mm linear measurement range.
4. What is the operating temperature range of the PR6423/10R-131 CON031?
The PR6423/10R-131 CON031 operates from -35°C to +180°C, suitable for harsh environments.
5. Is the PR6423/10R-131 CON031 compatible with automation systems?
Yes. The PR6423/10R-131 CON031 provides a linear output signal that integrates easily with PLC and DCS systems.
6. What is the benefit of non-contact measurement in the PR6423/10R-131 CON031?
The PR6423/10R-131 CON031 reduces mechanical wear and extends equipment lifespan by eliminating physical contact.
