GE PACSystems RX3i

Contact Info

Sales	Email	Whatsapp
Jim Pei	[email protected]	+86 18020776782

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Product Parameters

Product Name	GE IC695ALG626 ANALOG INPUT HART MODULE
Manufacturer	General Electric
Product Type	ANALOG INPUT HART MODULE
Part Number	IC695ALG626
Weight	0.24kg
Estimated shipping dimensions	3.5x13.5x13.5cm
Place of shipment	Xiamen, China
Country of origin	USA
Product Description	Non-isolated analog input module
Module Type	Analog Input w/HART comms
HART Protocol	Supported; HART Version 5.0
Current Range	0 to 20mA, 4 to 20mA, Â±20mA
Input signals, Current	0-20 mA; 4-20 mA; +/-20 mA;
Humidity	5 to 95%, non-condensing
Internal Power	3.3V 600mA, 5V 450 mA
Overvoltage	±60 VDC continuous, maximum
Overcurrent	±28mA continuous, maximum
Open Circuit Detection time	1 second maximum
Autocalibration	Performed during power-up

Introduction

The GE IC695ALG626 is a non-isolated Analog Input HART Module designed for high-performance process monitoring and industrial automation applications. Manufactured by General Electric, this module provides accurate acquisition of analog current signals while supporting HART Version 5.0 communication, allowing users to access both process variables and device diagnostic information through a single connection. It is an ideal solution for systems requiring reliable signal measurement and advanced field device communication.

The IC695ALG626 supports multiple current input ranges, including 0–20 mA, 4–20 mA, and ±20 mA, making it suitable for a wide variety of industrial transmitters and sensors. Featuring built-in autocalibration during power-up, open-circuit detection, and robust overvoltage and overcurrent protection, the module enhances measurement accuracy and system reliability. Its compact design and compatibility with GE automation platforms make it a valuable component for process control, manufacturing, energy, and infrastructure applications.

Functions

Acquires analog current signals from field devices and sensors.
Supports HART Version 5.0 communication for device configuration and diagnostics.
Processes 0–20 mA, 4–20 mA, and ±20 mA input signals.
Provides accurate analog signal conversion for monitoring and control systems.
Enables simultaneous access to process data and HART communication data.
Detects open-circuit conditions to improve system reliability.
Performs automatic calibration during startup to maintain measurement accuracy.
Protects connected systems through built-in overvoltage and overcurrent safeguards.
Facilitates integration with GE automation and process control systems.
Supports real-time monitoring of critical industrial processes.

Features

Non-isolated analog input module
Analog input module with integrated HART communication
Supports HART Protocol Version 5.0
Compatible with 0–20 mA input signals
Compatible with 4–20 mA input signals
Compatible with ±20 mA input signals
Simultaneous analog measurement and HART communication
Automatic calibration performed during power-up
Open-circuit detection time of 1 second maximum
Continuous overvoltage protection up to ±60 VDC
Continuous overcurrent protection up to ±28 mA
Internal power consumption of 3.3V at 600 mA
Internal power consumption of 5V at 450 mA
High measurement reliability for industrial applications
Compact and lightweight design
Weight approximately 0.24 kg
Humidity tolerance from 5% to 95% non-condensing
Designed for industrial process automation environments
Manufactured in the USA

Advantage

Compared with similar analog input modules, the IC695ALG626 combines accurate analog signal acquisition with integrated HART communication, providing enhanced diagnostic capabilities, improved measurement reliability, and greater operational efficiency.

Integrated HART Communication Capability

The IC695ALG626 supports HART Version 5.0 communication, enabling users to access device diagnostics, configuration parameters, and process information without additional communication hardware. This provides greater functionality than standard analog input modules.

Flexible Current Input Support

The IC695ALG626 accommodates 0–20 mA, 4–20 mA, and ±20 mA input ranges, allowing it to work with a broad range of industrial transmitters and sensors. This flexibility simplifies system design and reduces compatibility concerns.

Enhanced System Protection

Built-in overvoltage protection up to ±60 VDC and overcurrent protection up to ±28 mA help protect the module and connected equipment from electrical faults. These safeguards contribute to improved system uptime and reduced maintenance costs.

Automatic Calibration for Improved Accuracy

The IC695ALG626 performs autocalibration during power-up, helping maintain measurement accuracy without requiring frequent manual adjustments. This feature improves long-term performance and minimizes maintenance requirements.

Reliable Fault Detection

With open-circuit detection occurring within one second, the IC695ALG626 can quickly identify wiring or device issues. This rapid fault identification helps reduce troubleshooting time and supports more reliable process operation.

FAQ

Does the IC695ALG626 support HART communication?

Yes, the IC695ALG626 supports HART Protocol Version 5.0, allowing simultaneous transmission of analog process data and digital communication information.

What current input ranges are supported by the IC695ALG626?

The IC695ALG626 supports 0–20 mA, 4–20 mA, and ±20 mA input ranges, providing compatibility with a wide variety of industrial instruments and transmitters.

Is the IC695ALG626 an isolated or non-isolated module?

The IC695ALG626 is a non-isolated analog input module designed for applications where channel isolation is not required.

How does the IC695ALG626 maintain measurement accuracy?

The IC695ALG626 performs automatic calibration during power-up, helping ensure accurate signal measurement and reducing the need for manual calibration procedures.

What protection features are included in the IC695ALG626?

The IC695ALG626 includes continuous overvoltage protection up to ±60 VDC and continuous overcurrent protection up to ±28 mA to enhance module reliability and system safety.
