Product Name: CPU Module
Brand Name: General Electric
Model Number: IC697CPX772
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales |
||
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
The GE IC697CPX772 is a high-performance single-slot CPU module designed for the GE Fanuc Series 90-70 PLC platform. It serves as the central processing unit of the automation system, executing control logic, managing I/O operations, and coordinating communication with expansion and intelligent modules. Built on a 96 MHz 80486DX4 32-bit processor architecture, it delivers strong processing capability for real-time industrial control applications.
This CPU module integrates both battery-backed and non-volatile memory, providing up to 1 MB of battery-backed memory and 256 KB of flash memory within a compact single-slot design. With support for floating-point calculations, multiple serial communication ports, and compatibility with both IC660/IC661 and IC697 I/O systems, the IC697CPX772 is engineered for complex and large-scale automation environments requiring high reliability and flexible system expansion.
| Product Name | GE IC697CPX772 CPU Module |
| Manufacturer | General Electric |
| Product Type | CPU Module |
| Part Number | IC697CPX772 |
| Weight | 0.52 kg |
| Estimated shipping dimensions | 4x21.7x29.2cm |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Processor | 80486DX4 microprocessor |
| Discrete I/O | 2 K, max (any combination) |
| Compatibility | GE Fanuc 90-70 PLCs |
| Product Description | Central Processing Unit (CPU) |
| Boolean execution | 0.4 microseconds per boolean function |
| Operating temperature | 0 to 60 degrees Celsius |
| Communication port | One (1) RS232; Two (2) RS485 interface |
| Processor clock speed | 96 MHz |
| Processing architecture | 32-bit |
| Memory capacity | 512 Kbyte |
High processing power: 96 MHz 80486DX4 processor delivers faster execution than earlier PLC CPU generations
Large memory capacity: 1 MB battery-backed memory plus 256 KB flash supports complex and large-scale applications
Flexible communication options: dual RS485 and RS232 ports improve integration with external systems
Strong I/O scalability: supports up to 12K I/O points and compatibility with multiple I/O families
Advanced computing capability: floating-point support enables precise process control and engineering calculations
Compared with similar products: offers higher processing speed, greater memory capacity, and more communication ports than standard Series 90-70 CPUs
Integrated system flexibility: supports multiple intelligent modules and expansion options within one architecture
Compared with similar PLC CPU modules, the IC697CPX772 provides superior processing speed, expanded memory resources, enhanced communication capabilities, and strong system scalability, making it highly suitable for complex, data-intensive industrial automation systems.
The IC697CPX772 is fully compatible with GE Fanuc Series 90-70 PLC systems and operates as a single-slot CPU within the VME C.1 backplane architecture. It integrates seamlessly with IC697 I/O modules, IC660/IC661 systems, and a wide range of smart option modules, including LAN interfaces, communication processors, and bus controllers.
The module supports interoperability with MS-DOS and Windows-based programming software, as well as external industrial networks through its RS232 and RS485 communication interfaces. Its standardized architecture ensures smooth integration into existing GE automation systems, enabling scalable deployment across machine control, process automation, and material handling applications.
