Product Name: Discrete Input Module
Brand Name: General Electric
Model Number: IC697MDL653
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales |
||
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
| Product Name | GE IC697MDL653 Discrete Input Module |
| Manufacturer | General Electric |
| Product Type | Discrete Input Module |
| Part Number | IC697MDL653 |
| Weight | 0.6kg |
| Estimated shipping dimensions | 4x21.8x29.2cm |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Input current | 10 mA at rated voltage |
| No. of groups | Eight (8) channels per group |
| OFF-state voltage | 0 to 5 Volts |
| Input current | 10 mA per channel |
| Input voltage range | -3 to +30 VDC |
| On–state Current | 6 mA to 15 mA VDC |
| Isolation | 1500 V any input to backplane; 500 V between input groups |
| Input Points | 32 points |
| Input Voltage | 24 VDC |
| Input Current | 10 mA |
| GE PLC Input Module | High Isolation Input Module |
| Series 90-70 PLC Module | Factory Automation I/O Module |
| 32 Point Input Module | GE Series 90-70 Accessories |
| GE Industrial Automation | PLC Data Acquisition Module |
| IC697MDL653 I/O Module | Industrial Control Input Device |
| Digital Input Card GE | Signal Conditioning Module |
| PLC Signal Input Module | GE Input Terminal Module |
| GE Control System I/O | Robust Industrial I/O Module |
| Industrial Input Interface | Control Cabinet Input Hardware |
| GE Automation Hardware | Distributed Control Input System |
| 24VDC Input Module | GE Discrete Signal Module |
The GE IC697MDL653 is a 32-point discrete input module designed for the GE Series 90-70 PLC platform. It is used to receive and process digital input signals from field devices such as sensors, switches, and relays in industrial automation systems.
With a 24 VDC input voltage range and strong electrical isolation, the IC697MDL653 ensures reliable signal acquisition even in electrically noisy industrial environments. It is widely used in manufacturing systems, process control, and machine automation applications requiring accurate and stable digital input processing.
Compared with other discrete input modules, the GE IC697MDL653 provides higher channel density, strong electrical isolation, and reliable signal processing, making it well-suited for demanding industrial control applications.
High-Density Input Capability: Supports 32 input points, enabling efficient use of PLC rack space.
Strong Electrical Isolation: Provides up to 1500 V isolation for enhanced system protection and safety.
Reliable Signal Detection: Accurately processes 24 VDC input signals across a wide voltage range.
Industrial-Grade Stability: Designed to operate reliably in harsh industrial environments with electrical noise.
Flexible Grouping Structure: Organized into 8-channel groups for easier wiring and system management.
What types of field devices can be connected to GE IC697MDL653?
The GE IC697MDL653 can be connected to sensors, limit switches, push buttons, and relay contacts that output 24 VDC digital signals.
Does GE IC697MDL653 require external power supply?
The GE IC697MDL653 is powered through the PLC backplane and does not require an external power supply for operation.
How does GE IC697MDL653 handle electrical noise?
The GE IC697MDL653 uses high-level isolation (1500 V) to protect against electrical noise and interference in industrial environments.
Can GE IC697MDL653 be used in high-density control systems?
Yes, the GE IC697MDL653 supports 32 input points, making it suitable for high-density PLC applications.
What is the grouping structure of GE IC697MDL653 inputs?
The GE IC697MDL653 organizes inputs into eight groups, improving wiring clarity and system management.
Is GE IC697MDL653 suitable for harsh environments?
Yes, the GE IC697MDL653 is designed for stable operation in industrial environments with electrical noise and vibration.
