Product Name: CPU MODULE
Brand Name: General Electric
Model Number: IC698CPE020
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales |
||
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
| Product Name | GE IC698CPE020 CPU MODULE |
| Manufacturer | General Electric |
| Product Type | CPU MODULE |
| Part Number | IC698CPE020 |
| Weight | 0.66kg |
| Estimated shipping dimensions | 4x18.3x29.1cm |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| IO Memory | 32 Kbits Discrete I/O; 32 KWords Analog I/O |
| Microprocessor | 700 Mega-Hertz Pentium III microprocessor |
| Station Manager Port | One (1) RS232 Station Manager port |
| Built-in Ports | 2 Serial (RS-232, RS-485) 1 Ethernet (Auto 10/100, RJ45) |
| FTP / Webserver | Supported; Up to 16 connections |
| Boolean Execution Speed | 0.14 ms per 1000 Boolean contacts/coils which |
| Communication ports | Two (2) LAN Ports; Two (2) RS232 / RJ45 Serial port |
| Maximum Program block size | 128 KB |
| User Memory | 10 Megabyte |
| No. of Program blocks | 512 Program block |
| Application | Rx7i System |
| Media Redundancy | Supported via LAN 2 |
| Random Access Memory (RAM) | 10 MB |
| Operating Voltage | 5 to 12 Volts DC |
| Flash Memory: | 10 MB |
| Current Rating | 4.3 Amps |
| Ethernet data rate | 10Mb/sec and 100Mb/sec |
| CPU Memory | 10 Megabyte User Logic RAM |
| GE Automation Hardware | Factory Automation CPU |
| GE PLC CPU | PACSystem Controller Module |
| RX7i Central Processing Unit | Distributed Control CPU |
| Industrial Automation CPU | GE Intelligent Platforms CPU |
| IC698CPE020 Processor | Emerson RX7i CPU |
| GE Control System CPU | Industrial Ethernet Controller |
| Rack Mounted PLC Controller | PLC Rack CPU Module |
| Ethernet PLC CPU | High Memory PLC Controller |
| RS232 RS485 CPU Module | Mission Critical CPU Module |
| High Performance PLC Processor | Industrial Networking CPU |
The GE IC698CPE020 is a high-performance CPU module designed for the PACSystems RX7i platform. It is responsible for executing PLC control logic, managing I/O data, and handling industrial communication tasks in complex automation systems.
With a 700 MHz Pentium III microprocessor and large program memory capacity, the IC698CPE020 delivers fast processing speed and strong system integration capabilities. It is widely used in manufacturing, process control, and large-scale industrial automation applications requiring high reliability and real-time performance.
PLC Logic Execution
Executes control programs for RX7i systems with high-speed Boolean processing.
I/O Data Handling
Manages 32 Kbits of discrete I/O and 32 KWords of analog I/O for industrial control.
Program Storage Management
Supports up to 10 MB user memory and 10 MB Flash memory for application storage.
High-Speed Processing
Utilizes a 700 MHz Pentium III processor for fast and efficient control execution.
Network Communication
Provides Ethernet connectivity (10/100 Mbps) for industrial data exchange.
Serial Communication Support
Includes RS-232 and RS-485 ports for device and system integration.
Remote Access Functions
Supports FTP and web server access with up to 16 connections.
System Coordination
Handles synchronization and data exchange between multiple RX7i modules.
Media Redundancy Support
Supports LAN 2 redundancy for improved system reliability.
Program Structure Handling
Supports up to 512 program blocks with a maximum block size of 128 KB.
Compared with other RX7i CPU modules, the GE IC698CPE020 offers higher processing speed, stronger memory capacity, and improved communication performance, making it suitable for complex industrial automation systems.
High Processing Performance: 700 MHz processor enables fast execution of control logic.
Fast Boolean Execution: Achieves 0.14 ms per 1000 Boolean operations for real-time response.
Large Memory Capacity: Provides 10 MB user RAM and 10 MB Flash memory for complex applications.
Rich Communication Interfaces: Includes Ethernet, RS-232, and RS-485 for flexible connectivity.
Advanced Redundancy Support: Supports LAN 2 media redundancy for improved reliability.
High Program Capacity: Supports up to 512 program blocks with large block size capability.
Industrial-Grade Reliability: Designed for demanding RX7i automation environments.
What processor does GE IC698CPE020 use?
The GE IC698CPE020 uses a 700 MHz Pentium III microprocessor for high-speed processing.
How much memory does GE IC698CPE020 have?
The GE IC698CPE020 provides 10 MB user memory and 10 MB Flash memory.
What communication ports does GE IC698CPE020 support?
The GE IC698CPE020 supports Ethernet (10/100 Mbps), RS-232, and RS-485 communication ports.
Does GE IC698CPE020 support redundancy?
Yes, the GE IC698CPE020 supports LAN 2 media redundancy for system reliability.
What is the program capacity of GE IC698CPE020?
The GE IC698CPE020 supports up to 512 program blocks with a maximum block size of 128 KB.
Is GE IC698CPE020 suitable for large-scale automation systems?
Yes, the GE IC698CPE020 is designed for complex and large-scale industrial automation applications requiring high performance.
