Product Name: PACK POWER DIN RAIL MODULE
Brand Name: GE
Model Number:IS410JPDHG1A/IS400JPDHG1ABB
Country of Origin:USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
General Electric |
Model Number: |
IS410JPDHG1A/IS400JPDHG1ABB |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
Delivery time in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
The GE IS410JPDHG1A (and its variant IS400JPDHG1ABB) is a high-density power distribution module engineered for the Mark VIe Speedtronic™ turbine control system. The GE IS410JPDHG1A distributes stable 28 V DC control power to up to 24 I/O packs and three Ethernet switches, ensuring reliable operation of critical control and I/O components. Part of the JPDH family, the GE IS410JPDHG1A supports TMR redundancy and features PTC fuse protection for each output. Designed for DIN rail mounting, the GE IS410JPDHG1A provides a space-saving, modular solution for high-density power distribution in gas and steam turbine control cabinets.
Gas and steam turbine control – power distribution for I/O packs and Ethernet switches in Speedtronic™ systems
Power generation – substation automation, combined-cycle plants, and generator control cabinets
Industrial automation – high-density power distribution in manufacturing and process control environments
Energy management systems – reliable power for monitoring and control in power plants and substations
Oil & gas – pipeline control systems and offshore platform automation
Water and wastewater treatment – DCS power distribution for large-scale treatment facilities
High-density power distribution – supplies 28 V DC to up to 24 I/O packs and 3 Ethernet switches in a compact form factor
TMR-ready redundancy – supports Simplex, Dual, and Triple Modular Redundancy configurations for fault-tolerant operation
PTC fuse protection per output – Positive Temperature Coefficient fuses protect each I/O pack connector from overcurrent faults
Daisy-chain capability – multiple JPDH modules can be connected in series to expand power distribution capacity
DIN rail or panel mounting – versatile installation options for space-constrained control cabinets
Wide operating temperature range – –40°C to +70°C for harsh industrial environments
Hazardous location certified – Class I Division 2, Zone 2, and ATEX approved
Power isolation – separates control electronics from field-side wetting voltages to prevent electrical noise from compromising the control bus
Conformal coating – standard protective coating for moisture and dust resistance
Distributes 28 V DC control power – routes power from redundant R, S, and T sources to I/O packs and Ethernet switches
Provides fault-tolerant power delivery – supports TMR configurations with three independent power inputs for continuous operation during power supply failures
Protects downstream components – PTC fuses on each output isolate faults and prevent a single module short from taking down upstream supplies
Enables system expansion – daisy-chain capability allows additional JPDH modules to power more I/O packs as system requirements grow
Monitors and reports power health – integrated diagnostics provide feedback to the controller for proactive maintenance
Supports hot-swappable I/O packs – enables online replacement of I/O modules without system shutdown
Q1: What is the difference between IS410JPDHG1A and IS400JPDHG1ABB?
A1: The IS410JPDHG1A and IS400JPDHG1ABB are functionally identical JPDH modules. The IS410JPDHG1A is the primary part number, while IS400JPDHG1ABB is a variant used in some configurations. Both provide high-density 28 V DC power distribution for Mark VIe systems.
Q2: How many I/O packs can the IS410JPDHG1A power?
A2: The IS410JPDHG1A can supply power to up to 24 Mark VIe I/O packs and 3 Ethernet switches simultaneously.
Q3: Does the IS410JPDHG1A support redundant power configurations?
A3: Yes. The IS410JPDHG1A supports Simplex, Dual, and Triple Modular Redundancy (TMR) configurations with three independent 28 V DC power inputs (R, S, T).
Q4: What type of protection does the IS410JPDHG1A provide for its outputs?
A4: Each I/O pack connector on the IS410JPDHG1A is protected by a Positive Temperature Coefficient (PTC) fuse, which limits overcurrent and isolates faults.
Q5: What is the operating temperature range of the IS410JPDHG1A?
A5: The IS410JPDHG1A operates reliably from –40°C to +70°C, making it suitable for harsh industrial and power generation environments.
