Product Name: Transformer Protection Relay
Brand Name: GE
Model Number:T35E00HCHF8HH6UMXXPXXUXXWXX
Country of Origin:USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
General Electric |
Model Number: |
T35E00HCHF8HH6UMXXPXXUXXWXX |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
Delivery time in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Manufacturer |
GE Grid Solutions (GE Multilin) |
|
Part Number |
T35E00HCHF8HH6UMXXPXXUXXWXX |
|
Product Series |
Multilin UR (Universal Relay) Family |
|
Product Type |
Transformer Protection Relay / Digital Relay |
|
Differential Zones |
Up to 6 windings (6 sets of CT inputs) |
|
Protection Functions |
Percent differential, unrestrained differential, phase/ground overcurrent, thermal overload, underfrequency |
|
Inrush Inhibit |
2nd harmonic (traditional or adaptive) |
|
Overexcitation Inhibit |
5th harmonic |
|
Flexible Protection |
16 user-definable FlexElements |
|
Sampling Rate |
Up to 64 samples per cycle |
|
Event Recorder |
1024 time-stamped events |
|
Oscillography |
128 digital & 56 analog channels; up to 45s length; COMTRADE format |
|
Communications |
3 independent Ethernet ports; IEC 61850 Ed.1/2, DNP 3.0, Modbus RTU/TCP, IEC 60870-5-103/104, EGD |
|
Process Bus Support |
IEC 61850-9-2LE, IEC 61869, IEC 61850-9-2 HardFiber |
|
LAN Redundancy |
PRP (IEC 62439-3) – zero failover time |
|
Time Synchronization |
IEEE 1588, redundant SNTP |
|
Display |
Optional 7″ colour graphic HMI with bay mimic |
|
Cyber Security |
CyberSentry™ (RBAC, AAA/Radius, Syslog) |
|
Operating Temperature |
–40°C to +85°C |
|
Standards |
IEEE C37.91, C37.111-2013, IEC 60255-24 Ed 2.0 |
|
Dimensions |
48.2x23x18cm |
|
Weight |
5.86kg |
The GE Multilin T35E00HCHF8HH6UMXXPXXUXXWXX is a microprocessor-based relay from the UR family, designed for comprehensive transformer protection with up to six windings. It features percent differential protection with dual‑slope characteristic, adaptive 2nd‑harmonic inrush blocking, and 5th‑harmonic overexcitation inhibit. With up to six CT inputs, modular I/O, and advanced IEC 61850 communications, the T35E00HCHF8HH6UMXXPXXUXXWXX delivers secure, high‑speed protection for critical power transformers.
Primary and backup protection for power transformers, autotransformers, reactors, and split‑phase/angle‑regulating transformers
Combined transformer and bus zone protection (including breaker‑and‑a‑half and ring bus)
Multi‑winding transformers with up to six independent windings
Stand‑alone or integrated substation automation
Wide‑area protection and control (WAPC) via Routable GOOSE
Multi‑CT support – up to 6 sets of current inputs for complex differential zones
Dual‑slope percent differential – flexible dual‑breakpoint characteristic
Adaptive 2nd‑harmonic inrush inhibit – secure and dependable transformer energization
Unrestrained differential – fast tripping on heavy internal faults
16 FlexElements – user‑programmable protection for any measured quantity
IEC 61850 Ed.1/2 – full SCL file support, R‑GOOSE, and process bus (9‑2LE, 61869, HardFiber)
PRP redundancy – zero failover time per IEC 62439‑3
CyberSentry™ – RBAC, AAA/Radius, Syslog for SEM
Optional 7″ HMI – colour display with bay mimic and annunciator
High‑density modular I/O – scalable hardware for demanding applications
Percent differential protection with dual‑slope restraint and harmonic blocking
Unrestrained instantaneous differential for severe internal faults
Overcurrent protection (phase, neutral, ground, thermal overload)
2nd‑harmonic inrush and 5th‑harmonic overexcitation inhibition
Fault recording – 1024 events, oscillography (up to 45s, COMTRADE), data logger
FlexLogic™ for custom protection/control logic
Communication via IEC 61850, DNP 3.0, Modbus, IEC 60870‑5‑103/104, and process bus
Q1: How many CT inputs does the T35E00HCHF8HH6UMXXPXXUXXWXX support?
A1: It supports up to 6 sets of CT inputs, accommodating transformers with up to six windings or dual‑breaker configurations.
Q2: What communication protocols are available?
A2: It supports IEC 61850 Ed.1/2, DNP 3.0, Modbus RTU/TCP, IEC 60870‑5‑103/104, and EGD.
Q3: Does it support process bus communication?
A3: Yes, it supports IEC 61850‑9‑2LE, IEC 61869, and IEC 61850‑9‑2 HardFiber with IEEE 1588 time synchronization.
Q4: What cyber security features does it have?
A4: It includes CyberSentry™ with Role‑Based Access Control, AAA/Radius, and Syslog for security event monitoring.
Q5: What is the operating temperature range?
A5: The relay operates reliably from –40°C to +85°C.
