General Electric 369-HI-R-M-0-0-0-E 369 Motor Management Relay

General Electric 369-HI-R-M-0-0-0-E 369 Motor Management Relay

Product Name: 369 Motor Management Relay

Brand Name: General Electric

Model Number: 369-HI-R-M-0-0-0-E

Place of Origin: USA

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

general electric 369 hi r m 0 0 0 e 369 motor management relay-1

Overview
Specifications
Commercial Terms
Contact Us
Advantages
FAQ
Why Choose Us
Major Business
Recommended Products

Overview

The General Electric 369-HI-R-M-0-0-0-E 369 Motor Management Relay is an advanced motor protection and management relay designed for comprehensive industrial motor monitoring and control. It features 1 A and 5 A phase current inputs, a 50–300 VDC / 40–265 VAC universal power supply, enhanced display, PROFIBUS or Modbus/TCP communication, and fiber optic communication support for flexible system integration. Designed to provide intelligent motor protection, condition monitoring, and operational diagnostics, the relay improves equipment reliability, minimizes unplanned downtime, and simplifies maintenance. Its advanced protection capabilities make it an ideal solution for process automation, power generation, mining, water treatment, and heavy industrial motor control applications.

Specifications

Product Name	General Electric 369-HI-R-M-0-0-0-E 369 Motor Management Relay
Manufacturer	General Electric
Product Type	369 Motor Management Relay
Part Number	369-HI-R-M-0-0-0-E
Weight	3.5kg
Estimated shipping dimensions	20.4x14x29.5cm
Place of shipment	Xiamen, China
Country of origin	USA
Display Version	Enhanced
Phase Current Input	1 A and 5 A secondary
Input Power	50–300 VDC / 40–265 VAC
Maximum Power Consumption	48.5 VA Max
Input Frequency	50/60 Hz DC
Pollution Degree	2
IP Rating	IP54
Insulation Voltage	2 kV
Overvoltage Category	II
Communication Interface	PROFIBUS or Modbus/TCP
Fiber Optic Ports	Supported
Digital Inputs	5 optically isolated dry-contact inputs (as labeled)
Output Relays	Trip, Alarm, Aux 1, Aux 2
Control Power Terminals	L+, L−, G, N (as labeled)
Ambient Humidity Maximum	Up to 95% non condensing

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Contact Us

Sales	Email	Phone/Whatsapp
Jim Pei	[email protected]	+86 18020776782

Advantages

Comprehensive Motor Protection
Provides advanced protection functions that help safeguard motors against abnormal operating conditions, improving equipment reliability and extending service life.

Flexible Communication Integration
Supports PROFIBUS or Modbus/TCP communication along with fiber optic connectivity, enabling seamless integration into modern industrial automation and supervisory control systems.

Advanced Monitoring and Diagnostics
Continuously monitors motor operating conditions and provides valuable diagnostic information to support predictive maintenance and reduce unexpected equipment failures.

Universal Control Power Compatibility
Accepts a wide range of AC and DC control power inputs, allowing flexible installation across diverse industrial power systems without additional power conversion equipment.

Reliable Industrial Design
Built for demanding industrial environments with a robust enclosure, high insulation capability, and optically isolated digital inputs to ensure dependable long-term operation.

Ideal for Critical Motor Applications
Well suited for pumps, compressors, conveyors, fans, crushers, mining equipment, water treatment facilities, power generation plants, and other industrial applications requiring intelligent motor protection and management.

FAQ

Q1: What is the 369-HI-R-M-0-0-0-E used for?
A: The 369-HI-R-M-0-0-0-E is a motor management relay designed to provide protection, monitoring, diagnostics, and control for industrial electric motors.

Q2: Which communication protocols does the 369-HI-R-M-0-0-0-E support?
A: The 369-HI-R-M-0-0-0-E supports PROFIBUS or Modbus/TCP communication and also provides support for fiber optic communication interfaces.

Q3: What types of current inputs are supported by the 369-HI-R-M-0-0-0-E?
A: The 369-HI-R-M-0-0-0-E supports both 1 A and 5 A secondary phase current inputs, providing compatibility with a wide range of current transformer configurations.

Q4: Does the 369-HI-R-M-0-0-0-E include digital inputs and output relays?
A: Yes. The 369-HI-R-M-0-0-0-E includes five optically isolated digital inputs along with dedicated trip, alarm, and auxiliary output relays for flexible motor control and protection.

Q5: Is the 369-HI-R-M-0-0-0-E suitable for harsh industrial environments?
A: Yes. The 369-HI-R-M-0-0-0-E is designed for industrial applications with a durable construction, high insulation performance, and reliable operation in demanding environments.

Q6: Which industrial applications are suitable for the 369-HI-R-M-0-0-0-E?
A: The 369-HI-R-M-0-0-0-E is widely used in power generation, mining, oil and gas, water treatment, manufacturing, and other industrial applications requiring comprehensive motor protection and management.
