General Electric HE693IBS100 Interbus-S Slave Module

General Electric HE693IBS100 Interbus-S Slave Module

Product Name: Interbus-S Slave Module

Brand Name: General Electric

Model Number: HE693IBS100

Place of Origin: USA

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

general electric he693ibs100 interbus s slave module-1

Overview
Specifications
Commercial Terms
Contact Us
Advantages
FAQ
Why Choose Us
Major Business
Recommended Products

Overview

The General Electric HE693IBS100 Interbus-S Slave Module is a reliable fieldbus communication module designed for GE Fanuc Series 90-30 PLC systems. It features INTERBUS-S communication, up to 32 input words and 32 output words of process data, 500 kbit/s communication speed, 1500 VAC isolation, and dual 9-pin D-sub bus connectors for efficient network connectivity. Designed to enable seamless data exchange between PLCs and INTERBUS-S networks, the module simplifies distributed automation, enhances communication reliability, and improves system integration. Its compatibility with Series 90-30 PLC platforms makes it an ideal solution for factory automation, process control, material handling, and industrial communication applications.

Specifications

Product Name	General Electric HE693IBS100 Interbus-S Slave Module
Manufacturer	General Electric
Product Type	Interbus-S Slave Module
Part Number	HE693IBS100
Place of shipment	Xiamen, China
Country of origin	USA
Communication Protocol	INTERBUS-S
Installation	Installs in any module slot of a GE Fanuc Series 90-30 PLC
Bus Interface	Two 9-pin D-sub female connectors (IN/OUT)
INTERBUS-S Interface	9-pin D-sub female
Process Data Capacity	Up to 32 input words and 32 output words (64 words total)
Data Width	Dynamically programmable (1–32 words)
Rack Supply	24 VDC
Module Consumption	120 mA
Baud Rate	500 kbit/s (fixed)
Isolation Voltage	1500 VAC
Processor	Intel 80C196KR 16-bit microcontroller, 16 MHz
Interbus Interface Controller	Phoenix Contact SμPI chip
FPGA	Provides expansion for up to 32 process data words and PLC interface logic
PLC Data Mapping	%AI/%AQ registers for process data, %I/%Q bits for status and control
Status Indicators	TR, RC, BA (Bus Active), RD (Remote Bus Disabled)
Operating Temperature	0 °C to +60 °C
Storage Temperature	–40 °C to +85 °C
Humidity	5–95% RH (non-condensing)
PLC Run Status Reporting	Supports PLC RUN/STOP status reporting via process data and/or module error
Configuration	Hand-Held Programmer or LogicMaster 90-30 software

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Contact Us

Sales	Email	Phone/Whatsapp
Jim Pei	[email protected]	+86 18020776782

Advantages

Reliable INTERBUS-S Communication
Provides stable INTERBUS-S fieldbus communication, enabling efficient data exchange between GE Fanuc Series 90-30 PLCs and distributed automation devices.

Flexible Process Data Handling
Supports dynamically configurable process data mapping, allowing flexible integration with a wide variety of industrial control applications and network architectures.

High-Speed Industrial Data Transfer
Delivers dependable communication performance with fixed high-speed data transmission, ensuring timely exchange of control and monitoring information.

Comprehensive System Diagnostics
Integrated status indicators provide clear information on communication, bus activity, and operating conditions, helping maintenance personnel quickly identify network issues.

Easy PLC System Integration
Installs directly into any compatible Series 90-30 PLC module slot and supports configuration through standard GE Fanuc programming tools, simplifying commissioning and maintenance.

Ideal for Distributed Automation
Well suited for factory automation, process control, conveyor systems, manufacturing equipment, and other industrial applications requiring reliable INTERBUS-S network connectivity.

FAQ

Q1: What is the HE693IBS100 used for?
A: The HE693IBS100 is an INTERBUS-S slave module used to connect GE Fanuc Series 90-30 PLCs to INTERBUS-S fieldbus networks for distributed industrial communication.

Q2: Which PLC systems are compatible with the HE693IBS100?
A: The HE693IBS100 is designed for installation in GE Fanuc Series 90-30 PLC systems and can be installed in any compatible module slot.

Q3: How much process data does the HE693IBS100 support?
A: The HE693IBS100 supports up to 32 input words and 32 output words of process data, providing flexible communication for distributed control applications.

Q4: Does the HE693IBS100 provide electrical isolation?
A: Yes. The HE693IBS100 provides 1500 VAC isolation to improve communication reliability and protect the PLC system from electrical interference.

Q5: How is the HE693IBS100 configured?
A: The HE693IBS100 can be configured using a Hand-Held Programmer or LogicMaster 90-30 software, allowing convenient setup and integration.

Q6: Which industrial applications are suitable for the HE693IBS100?
A: The HE693IBS100 is widely used in factory automation, process control, material handling, conveyor systems, manufacturing, and other industrial applications requiring reliable INTERBUS-S communication.
