General Electric IS200TRLYH1BGG Coil Sensing Terminal Board

General Electric IS200TRLYH1BGG Coil Sensing Terminal Board

Product Name: Coil Sensing Terminal Board

Brand Name: General Electric

Model Number: IS200TRLYH1BGG

Place of Origin: USA

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Overview
Product Parameters
Commercial Terms
Contact Us
Why Choose US
Major Business
Product Feature
FAQ
Recommended Products

Overview

The General Electric IS200TRLYH1BGG Coil Sensing Terminal Board is a relay terminal board designed for reliable coil sensing and signal switching in General Electric industrial control and turbine automation systems. Featuring 12 plug-in magnetic relay channels, including six configurable relay outputs, five dry Form-C relays, and one high-current 7 A relay, it provides flexible interface capabilities for a variety of control applications. Supporting 125 VDC or 115/230 VAC (50/60 Hz) power supplies, the board offers 1,500 Vrms channel-to-channel isolation, fast 25 ms typical response times, and robust industrial performance. Its versatile relay configuration and dependable electrical isolation make it an ideal solution for critical automation and protection systems.

Product Parameters

Product Name	General Electric IS200TRLYH1BGG Coil Sensing Terminal Board
Manufacturer	General Electric
Product Type	Coil Sensing Terminal Board
Part Number	IS200TRLYH1BGG
Weight	1.16kg
Estimated shipping dimensions	33x17.7x5.5cm
Place of shipment	Xiamen, China
Country of origin	USA
Relay Channels	12 (plug-in magnetic relays)
Relay Configuration	6 configurable (jumper) + 5 dry Form-C + 1 special (7A)
Response Time (On/Off)	25 ms typical
Power Supply Options	125 VDC or 115/230 VAC (50/60 Hz)
Load Current (24 VDC)	3.0 A continuous / 10 A resistive
Max Inrush Current	10 A
Isolation Voltage	1500 Vrms (channel to channel)
Operating Temperature	-30°C to +65°C / -40°C to +70°C
Storage Temperature	-40°C to +85°C

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Contact Us

Sales:	Email:	Whatsapp:
Jim Pei	[email protected]	+86 18020776782

Why Choose US

✔ Genuine Industrial Automation Products
✔ Strict Quality Inspection Before Shipment
✔ Competitive Prices & Flexible Quotations
✔ Large Inventory with Fast Global Shipping
✔ 12-Month Warranty on Eligible Products
✔ Professional Technical & After-Sales Support
✔ Inquiry Response Within 1 Hour
✔ Secure Packaging for International Shipping
✔ Trusted Supplier for PLC, DCS, HMI, and Industrial Control Systems

Major Business

ABB: Industrial robot parts of DSQC series,Bailey INFI90, DCS
Honeywell: 51/MU/MC/TC/CC ...
Triconex: 3008/3511/3625/3664/3721/3700A..
Bently Nevada: 3500/3300/330180-Cable..
Foxboro: FBM203/204/217/231, FCP240/270
Woodward: SPC valve position controller, PEAK15 digital controller
Siemens: 6DD/6DP/6ES5/6DR/6GK Series
Westinghouse Series: 1C/5X ...
General electric: IC693/IC697/IC695/DS200..
Schneider: 140 Series

Product Feature

12 Relay Channel Design
Incorporates twelve plug-in magnetic relay channels for flexible signal switching and control.
Multiple Relay Configurations
Includes six jumper-configurable relays, five dry Form-C relays, and one dedicated 7 A relay for specialized applications.
Dual Power Supply Compatibility
Supports operation from either 125 VDC or 115/230 VAC (50/60 Hz) power sources.
High Load Handling Capability
Supports continuous loads up to 3.0 A at 24 VDC and resistive inrush currents up to 10 A.
Fast Relay Operation
Provides typical relay response times of approximately 25 ms for both energizing and de-energizing operations.
Excellent Electrical Isolation
Delivers 1,500 Vrms channel-to-channel isolation to improve system protection and signal integrity.
Wide Industrial Temperature Range
Designed for reliable operation across a broad operating and storage temperature range.
Reliable Plug-In Relay Design
Uses replaceable magnetic relays to simplify maintenance and reduce equipment downtime.

FAQ

---What is the IS200TRLYH1BGG used for?
IS200TRLYH1BGG is used for coil sensing, relay switching, and signal interfacing in General Electric industrial control and turbine automation systems.

---How many relay channels does the IS200TRLYH1BGG provide?
IS200TRLYH1BGG provides 12 plug-in magnetic relay channels.

---What relay configurations are available on the IS200TRLYH1BGG?
IS200TRLYH1BGG includes six jumper-configurable relays, five dry Form-C relays, and one special 7 A relay.

---What is the continuous load current of the IS200TRLYH1BGG?
IS200TRLYH1BGG supports continuous loads up to 3.0 A at 24 VDC.

---Is the IS200TRLYH1BGG suitable for continuous industrial operation?
IS200TRLYH1BGG is engineered for reliable continuous service in demanding industrial and power generation environments.

---Can the IS200TRLYH1BGG be used as a replacement terminal board?
IS200TRLYH1BGG is commonly used as a replacement module in compatible General Electric control systems to maintain operational reliability.
