HIMA F3349 8-Channel Safety Output Module

HIMA F3349 8-Channel Safety Output Module

Product Name: 8-Channel Safety Output Module

Brand Name: HIMA

Model Number: F3349

Place of Origin: Germany

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Overview
Specifications
Commercial Terms
Contact Us
Advantages
FAQ
Why Choose Us
Major Business
Recommended Products

Overview

The HIMA F3349 8-Channel Safety Output Module is a high-integrity safety output module designed for HIMA safety automation systems. It features 8 safety output channels, 24 V or 48 V DC output voltage, 500 mA maximum load current per channel, integrated safety shutdown, and supports SIL 3 functional safety in accordance with IEC 61508. Designed to provide dependable safety-related output control, the module continuously monitors output conditions while enhancing system reliability and fault detection. Its advanced diagnostic capabilities and secure switching performance make it an ideal solution for safety instrumented systems, process automation, power generation, oil and gas, and other critical industrial applications.

Specifications

Product Name	HIMA F3349 8-Channel Safety Output Module
Manufacturer	HIMA
Product Type	8-Channel Safety Output Module
Part Number	F3349
Place of shipment	Xiamen, China
Country of origin	Germany
Number of Outputs	8 channels
Safety Rating	applicable up to SIL 3 according to IEC 61508
Maximum Load Current	500 mA
Lamp Load	Up to 10 W
Nominal Output Voltage	24 V or 48 V DC
Safety Shutdown	Integrated safety shutdown
Output Signal Readback Operating Point (0-signal)	≤ 6.5 V
Nominal output voltage	24 Vor 48 V, acc. to supply of L+ via cable plug,500 mA，short-circuit-proof
Space requirement	4 SU
Operating data	5 VDC/0.15A, 24 VDC/ 200 mA(via rear bus system), 24/48 VDC/ 50 mA plus load(via cable plug)
Current input WD	1mA
Monitored switching time	max. 230 us (without extension by the function block)
Internal voltage drop	max.2V at 500 mAload
Admissible line resistance	max.11Ω
max. lamp load	10 W
max.inductivity	1H
max.capacity	100 μF
Output leakage current	max.500uA
Line short-circuit	0.7...0.8 A
Line break	2...8mA

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Contact Us

Sales	Email	Phone/Whatsapp
Jim Pei	[email protected]	+86 18020776782

Advantages

SIL 3 Functional Safety
Designed for applications requiring up to SIL 3 according to IEC 61508, providing dependable safety-related output control for critical industrial processes.

Comprehensive Output Diagnostics
Performs continuous automatic testing during operation, including output readback, line monitoring, safety shutdown verification, and cross-talk detection to improve fault detection and system availability.

Protected Output Channels
Features integrated safety shutdown, safe isolation, and short-circuit-proof outputs to enhance operational reliability and protect connected field devices under abnormal operating conditions.

Flexible Load Compatibility
Supports both resistive and inductive loads as well as lamp loads, making the module suitable for controlling a wide variety of industrial actuators and signaling devices.

Compact System Integration
Provides eight monitored safety outputs within a compact module, helping reduce cabinet space while simplifying installation and expansion of safety control systems.

Ideal for Safety-Critical Applications
Well suited for safety instrumented systems, process automation, power generation, oil and gas, chemical processing, and other industrial environments requiring reliable and certified safety output control.

FAQ

Q1: What is the F3349 used for?
A: The F3349 is an 8-channel safety output module used to safely control external field devices in industrial safety automation and process control systems.

Q2: What safety level does the F3349 support?
A: The F3349 is suitable for applications requiring up to SIL 3 functional safety in accordance with IEC 61508.

Q3: Does the F3349 include built-in diagnostic functions?
A: Yes. The F3349 continuously performs automatic diagnostics, including output monitoring, line supervision, cross-talk detection, and safety shutdown verification during operation.

Q4: What types of loads can the F3349 control?
A: The F3349 is designed to control resistive loads, inductive loads, and lamp loads while providing protected and monitored switching for each output channel.

Q5: Does the F3349 provide output protection?
A: Yes. The F3349 features integrated safety shutdown, safe isolation, and short-circuit-proof outputs to improve system reliability and operational safety.

Q6: Which industrial applications are suitable for the F3349?
A: The F3349 is widely used in safety instrumented systems, power generation, oil and gas, chemical plants, process automation, and other safety-critical industrial applications requiring dependable safety output control.
