HIMA H7506 DIN Mount Bus Terminal

Product Name: DIN Mount Bus Terminal

Brand Name: HIMA

Model Number: H7506

Place of Origin: Germany

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

Overview
Specifications
Commercial Terms
Contact Us
Advantages
FAQ
Why Choose Us
Major Business
Recommended Products

Overview

The HIMA H7506 DIN Mount Bus Terminal is a reliable DIN mount bus terminal designed for the HIMA HIQUAD X System. It features 16 communication channels, HIBUS-2 (RS-485) communication, a 1 Mbps data transfer rate, 12 V DC operating voltage, and a 25-pin Mini-D connector with integrated selectable bus termination for stable network communication. Designed to simplify fieldbus connectivity and system expansion, the terminal ensures dependable signal transmission, efficient diagnostics, and straightforward installation. Its seamless compatibility with HIMA HIQUAD X safety systems makes it an ideal solution for safety automation, process control, power generation, and other mission-critical industrial applications.

Specifications

Product Name	HIMA H7506 DIN Mount Bus Terminal
Manufacturer	HIMA
Product Type	DIN Mount Bus Terminal
Part Number	H7506
Weight	0.1kg
Estimated shipping dimensions	11.2x4.1x5.5cm
Place of shipment	Xiamen, China
Country of origin	Germany
Series	HIMA HIQUAD X System
Operating Voltage	12V DC
Current Consumption	≤10mA
Data Transfer Rate	1Mbps
Communication Protocol	RS-485
Number of Channels	16
PLC Connector	25-pin Mini-D socket
Bus Connections	2 × 6-pole plug clamps
Maximum Conductor Cross-section	2.5 mm²
Operating Temperature Range	-20°C to +60°C
Installation Compatibility	Panel or DIN rail
Material	Die-cast aluminum body for durability and heat dissipation
Data Cable Compatibility	BV7040, BV7046
Bus Termination	Integrated selectable bus terminating resistors via two switches
Communication Interface	HIBUS-2 (RS-485)
Compatible Systems	Single-channel PES, Redundant PES H41q/H51q

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock
