Product Name: Watchdog Repeater Module
Brand Name: Honeywell
Model Number: 10302/2/1
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Minimum Order Quantity |
1 Piece |
Price |
Contact for Jim |
Packaging Details |
Original new Factory Sealed |
Delivery Time |
3–7 Days |
Payment Terms |
T/T |
Shipping Method |
DHL / FedEx / UPS / TNT |
Supply Ability |
In stock |
| Product Name | Honeywell 10302/2/1 Watchdog Repeater Module |
| Manufacturer | Honeywell |
| Product Type | Watchdog Repeater Module |
| Part Number | 10302/2/1 |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Software Version | ≥ 3.00 |
| Space Requirement | 4 TE, 3 HE (4 HP, 3U) |
| Supply Voltage | 5 VDC, 24 VDC |
| 5 VDC Power Consumption | 35 mA (Without WDROUT Output Current) |
| 24 VDC Power Consumption | 25 mA |
| WDG1 + WDG2 Input Current | 0.1 mA |
| Monitored Voltages | 5 VDC, 24 VDC |
| Watchdog Output | Yes |
| Application | Multiple-PSU Configurations |
| Maximum Permitted 24 VDC Supply Output Voltage | Less than 37 VDC Under Any Single or Double Fault Condition |
| Maximum Supported Watchdog Current | Up to 900 mA (Higher Currents Require Additional Watchdog Repeater) |
| Application | Mixed Redundant and Non-Redundant I/O Configurations |
| Application | Redundant Central Parts with Non-Redundant I/O Configurations |
| Module Key Code | Holes A5, A9 |
| Rack Key Code | Large Pins A5, A9 |
| Approvals | CE, TÜV, UL |
|
Sales |
|
Phone/Whatsapp |
|
Jim Pei |
The Honeywell 10302/2/1 Watchdog Repeater Module is a dependable watchdog repeater module designed to extend watchdog monitoring and power supervision in Honeywell industrial control systems. It features 5 VDC and 24 VDC supply voltages, watchdog signal output, support for multiple power supply configurations, and compatibility with redundant and non-redundant I/O architectures. The module ensures reliable distribution of watchdog signals between system components, helping maintain continuous system supervision and operational integrity. It improves fault tolerance, simplifies redundant system implementation, and enhances controller availability, making it an ideal solution for process automation, safety systems, power generation, and other mission-critical industrial applications.
Watchdog Signal Distribution
Receives and distributes watchdog signals between system components, ensuring reliable supervision of connected controllers and I/O modules.
Power Supply Monitoring
Monitors both 5 VDC and 24 VDC power rails to support stable operation and detect abnormal power conditions within the control system.
Supports Multiple Power Supplies
Enables watchdog supervision in systems using multiple power supply units, improving operational continuity and system reliability.
Redundant System Integration
Supports mixed redundant and non-redundant I/O configurations as well as redundant central processing architectures, providing flexible system design options.
Watchdog Current Expansion
Supports watchdog output currents up to the specified capacity and allows additional watchdog repeater modules to be added when higher current requirements are needed.
Improves System Availability
Maintains dependable watchdog communication and fault supervision across industrial automation systems, helping increase system uptime in process automation, power generation, oil and gas, and other critical industrial applications.
