Honeywell 51202324-100 DC Power Cable Original new

Honeywell 51202324-100 DC Power Cable Original new

Product Name:DC Power Cable

Brand Name:Honeywell

Model Number:51202324-100

Country of Origin:USA

Warranty: 12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

honeywell 51202324 100 dc power cable original new-1

Overview
Contact for quotation
Specifications
Description
Applications
Features
Functions
FAQ
Spares
Recommended Products

Overview

Brand Name:	Honeywell
Model Number:	51202324-100
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Item	Specification
Product Model	51202324-100
Brand	Honeywell
Product Type	DC Power Distribution Cable
Application	Series C Power Distribution Subsystem
Operating Voltage	24 Vdc
Connection Type	Power Distribution Connector
Cable Length	9 in (229 mm)
Compatible System	Honeywell Series C
Associated Components	51199406-100, 51403896-100, 51202335-300
Installation Location	Control Cabinet
Dimension	229 mm Length
Weight	Approx. 0.15 kg

Description

The 51202324-100 is a dedicated DC power distribution cable designed for Honeywell Series C control systems and cabinet-based automation architectures. This cable provides a secure connection between the power distribution subsystem and the Horizontal DC Power Bus Bar (HDPB), ensuring consistent 24 Vdc power delivery to critical control assemblies and field devices.

Engineered for industrial reliability, the 51202324-100 supports stable power transmission while simplifying cabinet wiring and power management. It is commonly deployed alongside components such as 51199406-100, 51403896-100, and 51202335-300 to create an efficient and scalable power distribution infrastructure.

Suitable for process automation, power generation, and industrial manufacturing environments, the 51202324-100 helps improve system availability, reduces installation complexity, and contributes to the long-term performance of distributed control systems.

Applications

Power Plants: Distributes 24 Vdc power to control assemblies, monitoring systems, and protection equipment.
Substations: Supports reliable power delivery for relay panels, automation systems, and communication devices.
Chemical Plants: Provides stable DC power for process control cabinets and distributed automation networks.
Steel Mills: Ensures dependable power distribution in harsh environments with high electrical interference.
Machinery Manufacturing Plants: Supplies control power to PLCs, I/O systems, and automated production equipment.

Features

Designed for Honeywell Series C platforms
Supports reliable 24 Vdc power distribution
Compact 229 mm cable length
Industrial-grade construction
Simplifies cabinet wiring architecture
Enhances power system reliability
Suitable for continuous industrial operation

Functions

Transfers 24 Vdc power from the distribution subsystem to the HDPB
Supports power delivery to multiple control cabinet assemblies
Helps maintain stable operation of automation equipment
Reduces wiring complexity within control cabinets
Enables scalable power distribution configurations
Improves overall system availability and efficiency

FAQ

Q1: What is the purpose of the 51202324-100 cable?
A1: It connects the power distribution subsystem to the Horizontal DC Power Bus Bar for 24 Vdc power distribution.

Q2: Which Honeywell systems use the 51202324-100?
A2: It is commonly used in Honeywell Series C control and automation systems.

Q3: What is the cable length of the 51202324-100?
A3: The cable length is 9 inches (229 mm).

Q4: Can the 51202324-100 be used in industrial control cabinets?
A4: Yes, it is specifically designed for installation within industrial control cabinet environments.

Q5: What benefits does the 51202324-100 provide?
A5: It delivers reliable DC power distribution, simplifies wiring, and supports long-term automation system performance.

Spares

Number	Describe
CC-SCMB01	C300 Memory Backup Assembly (MBA) – For 1 to 2 C300 Controllers
CC-SCMB02	C300 Memory Backup Assembly (MBA) – For 2 or More C300 Controllers
51199932-100	RAM Charger Assembly
51202340-100	RAM Charger Mounting Assembly, 3 in (76 mm)
51202330-100	Cable, MBA to One C300 Controller, 30 in (0.7 m) Long
51202331-100	Power Cable, MBA to Power System, 55 in (1.4 m) Long
51202330-200	Cable, MBA to One C300 Controller, 84 in (2.0 m) Long
