Product Name:Power Distribution Cable
Brand Name:Honeywell
Model Number:FS-PDC-FTA24P
Country of Origin:USA
Warranty:12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Honeywell |
Model Number: |
FS-PDC-FTA24P |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Parameter | Specification |
|---|---|
| Product Model | FS-PDC-FTA24P |
| Product Type | 24Vdc Power Distribution Cable |
| Application | Power transfer from PDB-0824/PDB-0824P to FTAs, fan units, and cabinet devices |
| Voltage Rating | 24Vdc |
| Cable Type | 2 × 1.31 mm² (AWG 16) tri-rated industrial cable |
| Cable Length | 2 m (78.74 in) |
| Connector Housing | Weidmuller BLZ 5.08/2F 2-pole socket block |
| Crimp Pin Type | Weidmuller DFFC 1.5-2.5 SN E |
| Conductor Identification | Red wire (+24Vdc), Black wire (0Vdc) |
| Dimension | Approx. 2000 mm cable length with compact connector assembly |
| Weight | Approx. 0.15 kg (estimated, depending on cable configuration) |
| Compliance | UL, CSA approved; FM pending |
The FS-PDC-FTA24P is a dedicated 24Vdc power distribution cable designed to provide reliable power delivery between the PDB-0824P power distribution board and field devices installed within industrial control cabinets. Engineered for Safety Manager power infrastructures, it ensures efficient power transfer to equipment such as fan assemblies, field termination assemblies (FTAs), and auxiliary control devices.
Unlike the legacy PDC-FTA24, the FS-PDC-FTA24P incorporates screw-based connections, simplifying installation and improving wiring security. The cable is fully interchangeable with earlier versions while maintaining compatibility with both PDB-0824 and PDB-0824P distribution boards.
Featuring industrial-grade AWG16 tri-rated conductors and a robust Weidmuller connector assembly, the FS-PDC-FTA24P offers dependable performance, flexible field termination, and long-term reliability in demanding automation and process control environments.
Q1: What is the primary purpose of the FS-PDC-FTA24P?
A1: It distributes 24Vdc power from a PDB-0824 or PDB-0824P board to cabinet-mounted devices.
Q2: Is FS-PDC-FTA24P compatible with older PDC-FTA24 installations?
A2: Yes, it is fully interchangeable and can replace the obsolete PDC-FTA24 cable.
Q3: What devices can be connected using FS-PDC-FTA24P?
A3: It is commonly used with FTAs, fan units, and other 24Vdc control cabinet equipment.
Q4: What type of connector is used on the distribution board side?
A4: The cable uses a Weidmuller BLZ 5.08/2F two-pole socket connector.
Q5: Can the cable length be customized during installation?
A5: Yes, the device-side conductors can be cut and terminated with suitable connectors as required.
