Siemens 39EAMCBN A5E00282025/05 EAM Enhanced Analog Module

Siemens 39EAMCBN A5E00282025/05 EAM Enhanced Analog Module

Product Name: EAM Enhanced Analog Module

Brand Name: Siemens

Model Number: 39EAMCBN A5E00282025/05

Place of Origin: Germany

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Overview
Specifications
Commercial Terms
Contact Us
Advantages
FAQ
Why Choose Us
Major Business
Recommended Products

Overview

The Siemens 39EAMCBN A5E00282025/05 EAM Enhanced Analog Module is a high-performance enhanced analog module designed for the Siemens APACS+ process automation system. It features 16 independently configurable analog channels, 24 VDC power supply, 12-bit analog conversion with advanced filtering, 500 V channel isolation, and support for 4–20 mA process signals for reliable industrial measurement and control. Designed to deliver accurate analog signal acquisition and dependable process monitoring, the module enhances control accuracy, improves system diagnostics, and supports long-term operational stability. Its compatibility with APACS+ platforms makes it an ideal solution for power generation, oil and gas, chemical processing, water treatment, and other continuous process automation applications.

Specifications

Product Name	Siemens 39EAMCBN A5E00282025/05 EAM Enhanced Analog Module
Manufacturer	Siemens
Product Type	EAM Enhanced Analog Module
Part Number	39EAMCBN A5E00282025/05
Weight	1.96kg
Estimated shipping dimensions	4x25.7x30.5cm
Place of shipment	Xiamen, China
Country of origin	Germany
ROM Version	3.01
Supply Voltage	24 VDC
Maximum Input Current	0.90 A Max
I/O Signal	24 VDC; 4–20 mA
Hazardous Location Rating	Class I, Division 2, Groups A, B, C & D
Temperature Classification	T4A
Maximum Ambient Temperature	70°C
Certifications	CSA, CE, FM Approved, UL Listed
Marine Certification	ABS Type Approved
Number of Channels	16 Channels (Independently Configurable)
Backplane Operating Voltage	+5 VDC (±5%) via IOBUS Backplane Connector
Field-Side Power Supply	24 VDC Nominal (20 to 30 VDC Range) required for loop transmitter power
Current Consumption	Max 450 mA @ 5 VDC (Backplane); Max 1.2 A @ 24 VDC (Field-side under full load)
A/D & D/A Resolution	12-Bit Standard, with advanced filtering options
Channel Isolation	500 V AC RMS channel-to-channel and channel-to-chassis ground

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Contact Us

Sales	Email	Phone/Whatsapp
Jim Pei	[email protected]	+86 18020776782

Advantages

Flexible Multi-Channel Configuration
Provides 16 independently configurable analog channels, enabling efficient monitoring and control of multiple process variables within a single automation module.

Accurate Analog Signal Processing
Utilizes high-quality analog conversion with advanced filtering to ensure stable signal acquisition and improve overall process control performance.

High Electrical Isolation
Offers robust channel-to-channel and channel-to-ground isolation, reducing electrical interference and protecting connected equipment in demanding industrial environments.

Reliable APACS+ System Integration
Designed for seamless compatibility with Siemens APACS+ automation platforms, simplifying installation and ensuring dependable communication with process control systems.

Industrial-Grade Reliability
Certified for hazardous industrial locations and marine applications, delivering dependable long-term operation in mission-critical automation environments.

Ideal for Process Automation
Well suited for power generation, oil and gas, chemical processing, water treatment, marine systems, and other industrial applications requiring precise analog measurement and reliable process control.

FAQ

Q1: What is the 39EAMCBN A5E00282025/05 used for?
A: The 39EAMCBN A5E00282025/05 is an enhanced analog module used for analog signal acquisition, monitoring, and process control within Siemens APACS+ automation systems.

Q2: How many channels does the 39EAMCBN A5E00282025/05 provide?
A: The 39EAMCBN A5E00282025/05 provides 16 independently configurable analog channels for flexible industrial process applications.

Q3: Which automation platform is the 39EAMCBN A5E00282025/05 compatible with?
A: The 39EAMCBN A5E00282025/05 is specifically designed for integration with the Siemens APACS+ process automation platform.

Q4: Does the 39EAMCBN A5E00282025/05 provide electrical isolation?
A: Yes. The 39EAMCBN A5E00282025/05 provides 500 V channel-to-channel and channel-to-ground isolation to improve signal integrity and system reliability.

Q5: Is the 39EAMCBN A5E00282025/05 suitable for hazardous environments?
A: Yes. The 39EAMCBN A5E00282025/05 is certified for Class I, Division 2 hazardous locations and is also ABS Type Approved for marine applications.

Q6: Which industrial applications are suitable for the 39EAMCBN A5E00282025/05?
A: The 39EAMCBN A5E00282025/05 is widely used in power generation, chemical processing, oil and gas, water treatment, marine systems, and other industrial applications requiring reliable analog signal processing and process automation.
