Product Name:Terminal module
Brand Name:Siemens
Model Number:3RK1903-0AA00
Country of Origin:Germany
Warranty:12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Siemens |
Model Number: |
3RK1903-0AA00 |
Country of Origin: |
Germany |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Parameter | Specification |
|---|---|
| Product Model: | 3RK1903-0AA00, Siemens terminal module for PM-D power module applications. |
| Manufacturer: | Siemens, designed for SIMATIC ET 200S distributed automation systems. |
| Product Type: | Terminal module (TM-P15 S27-01) with integrated end cover for PM-D power modules. |
| Application: | Power infeed terminal module for U1/U2 potential group distribution and field wiring. |
| Operating Voltage: | 24 V DC rated operating voltage for industrial control systems. |
| Rated Current: | 10 A continuous operating current for reliable power distribution. |
| Protection Class: | IP20 enclosure suitable for installation inside industrial control cabinets. |
| Insulation Voltage: | 500 V rated insulation voltage for dependable electrical isolation. |
| Connection Type: | Screw terminal connections supporting solid and stranded conductors according to IEC 60947. |
| Dimensions: | 117.5 × 15 × 102 mm (H × W × D) compact DIN rail installation design. |
| Weight: | Approximately 80 g (typical terminal module weight). |
3RK1903-0AA00 is a Siemens SIMATIC ET 200S terminal module designed for use with the PM-D power module, providing a reliable power infeed solution for U1/U2 potential groups in distributed automation systems. Its compact construction helps optimize cabinet space while ensuring secure electrical connections and simplified module installation.
Designed for 24 V DC applications, 3RK1903-0AA00 supports a rated operating current of 10 A and features screw-type terminals compatible with a wide range of conductor sizes. The IP20-rated housing, 500 V insulation voltage, and durable industrial design ensure dependable operation in demanding control panel environments while facilitating efficient wiring and maintenance.
As part of the Siemens ET 200S accessory range, 3RK1903-0AA00 works seamlessly with related products such as 3RK1903-0AB00, 3RK1903-0AC00, and 3RK1308-0BB00, offering a practical solution for power distribution, modular expansion, and long-term industrial automation reliability.
Q1: What is 3RK1903-0AA00 used for?
A1: It is a Siemens terminal module designed for PM-D power modules, providing power infeed and terminal connections for U1/U2 potential groups.
Q2: Which systems are compatible with 3RK1903-0AA00?
A2: It is designed for Siemens SIMATIC ET 200S distributed automation systems using PM-D power modules.
Q3: What is the rated operating voltage of 3RK1903-0AA00?
A3: The terminal module operates with a rated voltage of 24 V DC and supports a continuous current of up to 10 A.
Q4: What protection level does 3RK1903-0AA00 provide?
A4: It features an IP20 protection rating and a 500 V insulation voltage for safe installation inside industrial control panels.
Q5: What are the main advantages of 3RK1903-0AA00?
A5: Its compact design, reliable screw-terminal connections, industrial durability, and seamless compatibility with Siemens PM-D modules make it ideal for distributed automation power distribution.
|
