Siemens 6AV6643-0DD01-1AX1 SIMATIC MP 277 10-inch Key Multi Panel

Siemens 6AV6643-0DD01-1AX1 SIMATIC MP 277 10-inch Key Multi Panel

Product Name: SIMATIC MP 277 10-inch Key Multi Panel
Brand Name: Siemens
Model Number: 6AV6643-0DD01-1AX1
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]

Appurtenance:

siemens 6av6643 0dd01 1ax1 simatic mp 277 10 inch key multi panel-1

Overview
Commercial Term
Specifications
Contact info
Description
Function
About Company
Why Choose Us
Other Products
Recommended Products

SIEMENS INDUSTRIAL NETWORKING · SCALANCE XR SERIES

Siemens 6AV6643-0DD01-1AX1 SIMATIC MP 277 10-inch Key Multi Panel

Operator Interface

Siemens Integrated

Automation System

Official Siemens product data identifies 6AV6643-0DD01-1AX1 as the SIMATIC MP 277 10-inch Key Multi Panel. The information below is organized for clear industrial sourcing and technical evaluation.

Commercial Term

Supply Ability

In stock

Price

Contact for Jim

Packaging Details

Original new Factory Sealed

Delivery Time

3–7 Days

Payment Terms

T/T

Shipping Method

DHL / FedEx / UPS / TNT

Specifications

TECHNICAL PARAMETER	OFFICIAL VALUE
Screen diagonal	10.4 in
Display type	TFT, 65536 colors
Horizontal image resolution	640
Vertical image resolution	480
MTBF backlighting (at 25 °C)	about 50000 hours
Function keys, programmable	36 function keys, 28 with LEDs
Number of function keys with LEDs	28
Number of multi-key operations	2
Supply voltage	24 V DC
Usable memory for user data	6 MB usable memory for user data
Capacity of main memory, maximum	64 Mbyte
Interfaces	1 x RS422, 1 x RS485, 1 x Ethernet (RJ45)
Number of RS 485 interfaces	1
USB port	2 x USB
Multi Media Card slot	1 x Multi Media Card slot
Industrial Ethernet interface	1 x Ethernet (RJ45)
maximum permissible angle of inclination without	+/- 35 °
Operation	0 °C to +50 °C
Transport, storage	-20 °C to +60 °C
max. relative humidity	90 %
Front	IP65, NEMA 4x (when installed)
Type of protection	IP20
IP (at the front)	IP65
NEMA	NEMA 4X
Rear	IP20
Certifications	CE, FM Class I Div. 2, UL, cULus, EX Zone 22, NEMA
Configuration tool	WinCC flexible Standard Version 2005 SP1 or higher
Version	Version 2005 SP 1
Number of online/runtime languages	16
Languages per project	32
Number of Visual Basic Scripts	50
Number of characters per info text	80
Number of alarm classes	32

Contact info

CONTACT

Sales
Jim Pei

Email
[email protected]

Phone/Whatsapp
+86 18020776782

Description

PRODUCT OVERVIEW · 6AV6643-0DD01-1AX1

6AV6643-0DD01-1AX1 is an official Siemens SIMATIC MP 277 10-inch Key Multi Panel for professional industrial automation. Its verified technical characteristics are summarized from Siemens documentation. The product supports dependable integration into compatible systems. It is suitable for replacement, modernization and engineering review. This Siemens component supports structured industrial sourcing. Our team can assist with model confirmation before shipment.

Function

FUNCTION 01

Visualizes machine and process conditions for operators.

FUNCTION 02

Supports intuitive operator interaction with plant equipment.

FUNCTION 03

Displays alarms, trends and diagnostic information.

FUNCTION 04

Supports recipe handling and structured workflows.

FUNCTION 05

Provides multilingual visualization.

FUNCTION 06

Integrates with Siemens automation systems.

FUNCTION 07

Helps operators respond to process events.

FUNCTION 08

Supports commissioning and maintenance activities.
