Product Name: SIMATIC HMI MP 377 15 inch Touch Multi Panel
Brand Name: Siemens
Model Number: 6AV6644-0AB01-2AX0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
The Siemens 6AV6644-0AB01-2AX0 SIMATIC HMI MP 377 15 inch Touch Multi Panel is a high-performance human-machine interface (HMI) designed for advanced machine operation, process visualization, and industrial control applications. Equipped with a 15-inch TFT color touchscreen offering 1024 × 768 resolution and 65,536 colors, it delivers clear and responsive operator interaction. Running on Windows CE 5.0 and configurable with WinCC flexible 2007 or later, it supports PROFINET IO, dual Industrial Ethernet ports, serial communication, USB, and memory card expansion. Its rugged IP65 front protection, extensive alarm and recipe management, and long-life backlight make it an ideal solution for demanding industrial automation environments.
| Product Name | Siemens 6AV6644-0AB01-2AX0 SIMATIC HMI MP 377 15 inch Touch Multi Panel |
| Manufacturer | Siemens |
| Product Type | SIMATIC HMI MP 377 15 inch Touch Multi Panel |
| Part Number | 6AV6644-0AB01-2AX0 |
| Weight | 6.86kg |
| Estimated shipping dimensions | 40x11x31cm |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Display Type | 15 in TFT Color Touch Display |
| Display Resolution | 1024 × 768 pixels |
| Display Colors | 65,536 |
| Touch Technology | Analog Resistive Touchscreen |
| Backlight Lifetime | 50,000 h (MTBF @ 25°C) |
| Operating System | Windows CE 5.0 |
| Configuration Software | WinCC flexible 2007 or later |
| Configuration Memory | 12 MB Flash |
| Memory Type | Flash / RAM |
| User Data Memory | 12,288 KB |
| Supply Voltage | DC |
| Rated Current | 1.9 A |
| Typical Power Consumption | 45.6 W |
| Hardware Clock | Battery-backed, Synchronizable |
| Ethernet Interfaces | 2 × RJ45 Industrial Ethernet |
| Serial Interfaces | 1 × RS-422, 1 × RS-485 |
| USB Interfaces | 2 × USB (up to 1 GB each) |
| CF Card Slot | 1 × CompactFlash |
| MMC/SD Card Slot | 1 × Multimedia Card (up to 128 MB) |
| Supported Protocol | PROFINET IO |
| Front Protection Rating | IP65 |
| Rear Protection Rating | IP20 |
| NEMA Rating | NEMA 4, NEMA 12 (Front, Installed) |
| Operating Temperature | 0 to 50°C |
| Storage Temperature | -20 to 60°C |
| Maximum Relative Humidity | 90% |
| Runtime Languages | 16 |
| Alarm Classes | 32 |
| Bit Messages | 4,000 |
| Analog Messages | 200 |
| Entries per Data Record | 1,000 |
| Recipe Memory | 128 KB Integrated Flash (Expandable) |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
|
Sales: |
Email: |
Whatsapp: |
|
Jim Pei |
✔ Genuine Industrial Automation Products
✔ Strict Quality Inspection Before Shipment
✔ Competitive Prices & Flexible Quotations
✔ Large Inventory with Fast Global Shipping
✔ 12-Month Warranty on Eligible Products
✔ Professional Technical & After-Sales Support
✔ Inquiry Response Within 1 Hour
✔ Secure Packaging for International Shipping
✔ Trusted Supplier for PLC, DCS, HMI, and Industrial Control Systems
ABB: Industrial robot parts of DSQC series,Bailey INFI90, DCS
Honeywell: 51/MU/MC/TC/CC ...
Triconex: 3008/3511/3625/3664/3721/3700A..
Bently Nevada: 3500/3300/330180-Cable..
Foxboro: FBM203/204/217/231, FCP240/270
Woodward: SPC valve position controller, PEAK15 digital controller
Siemens: 6DD/6DP/6ES5/6DR/6GK Series
Westinghouse Series: 1C/5X ...
General electric: IC693/IC697/IC695/DS200..
Schneider: 140 Series
---Which memory cards are supported by the 6AV6644-0AB01-2AX0?
6AV6644-0AB01-2AX0 supports CompactFlash cards and Multimedia (MMC/SD) cards up to 128 MB.
---How much user memory is available in the 6AV6644-0AB01-2AX0?
6AV6644-0AB01-2AX0 provides 12,288 KB of user data memory using Flash and RAM storage.
---Does the 6AV6644-0AB01-2AX0 include a hardware clock?
6AV6644-0AB01-2AX0 includes a battery-backed hardware clock that supports synchronization with the automation system.
---What protection rating does the 6AV6644-0AB01-2AX0 provide?
6AV6644-0AB01-2AX0 offers IP65 front protection and IP20 rear protection for industrial installations.
---What operating temperature range is supported by the 6AV6644-0AB01-2AX0?
6AV6644-0AB01-2AX0 is designed to operate in ambient temperatures from 0°C to 50°C.
---How many runtime languages can the 6AV6644-0AB01-2AX0 support?
6AV6644-0AB01-2AX0 supports up to 16 runtime languages for multilingual operator interfaces.
---What alarm and message capacity does the 6AV6644-0AB01-2AX0 provide?
6AV6644-0AB01-2AX0 supports 32 alarm classes, 4,000 bit messages, 200 analog messages, and up to 1,000 entries per data record.
