Siemens 6DD1600-0AJ0 PM5 CPU Module

Product Name: PM5 CPU Module

Brand Name: Siemens

Model Number: 6DD1600-0AJ0

Place of Origin: Germany

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

Overview
Specifications
Contact Us
Overview
Functions
Why Choose Us
Major Business
After-sales Service
Recommended Products

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Specifications

Product Name	Siemens 6DD1600-0AJ0 PM5 CPU Module
Manufacturer	Siemens
Product Type	PM5 CPU Module
Part Number	6DD1600-0AJ0
Place of shipment	Xiamen, China
Country of origin	Germany
Processor	32-bit RISC Processor
Processor Frequency	32 MHz
DRAM	4 MB EDO DRAM
SRAM	64 KB Buffered SRAM
Typical Cycle Time	0.1 ms
Typical Control Loop Execution Time	Approx. 0.6 ms
Binary Inputs	Up to 8
Absolute Encoder Inputs	Up to 2
Incremental Encoder Inputs	Up to 2
Program Memory Module	MS5 (2 MB Flash-EPROM, 8 KB EEPROM)
Program Memory Module	MS51 (4 MB Flash-EPROM, 8 KB EEPROM)
Programming Software	STEP 7/HW Config, CFC
Program Loading	Offline via PCMCIA Card
Program Loading	Online via RS-232 Serial Connection
Communication Interface	RS-232 (V.24), DUST1 Service Protocol
Serial Communication Speed	19.2 kbit/s
Input Delay	Max. 20 µs
Typical Current at -15 V	35 mA
External Supply Voltage	24 VDC
External Voltage Range	20–30 VDC
Typical Current at 24 V	100 mA + Binary Output Currents
Interrupt-Capable Inputs	Max. 4
Binary Input Rated Voltage	24 VDC
Input Voltage (Logic 0)	-1 to +6 V or Open Circuit
Input Voltage (Logic 1)	+13 to +33 V
Input Current (Logic 1)	Typical 3 mA

Contact Us

Sales	Email	Phone/Whatsapp
Jim Pei	[email protected]	+86 18020776782

Overview

The Siemens 6DD1600-0AJ0 PM5 CPU Module is a high-performance PM5 CPU module designed for Siemens industrial automation and process control systems. It is equipped with a 32-bit RISC processor running at 32 MHz, 4 MB EDO DRAM, 64 KB buffered SRAM, and supports STEP 7/HW Config and CFC programming. The module delivers fast processing performance with a typical cycle time of 0.1 ms while providing flexible program loading through PCMCIA cards or an RS-232 serial connection. Designed for reliable control execution and seamless system integration, it enhances operational efficiency and long-term stability, making it an ideal solution for process automation, power generation, turbine control, manufacturing, and other demanding industrial applications.

Functions

Central Control Processing
Executes automation programs, logical operations, and real-time control tasks, serving as the primary processing unit within Siemens process automation systems.

High-Speed Data Processing
The 32-bit RISC processor provides fast instruction execution, enabling rapid response to process changes and supporting high-performance industrial control applications.

Program Execution and Memory Management
Works with MS5 and MS51 program memory modules to store, execute, and manage user applications, configuration data, and firmware efficiently.

Industrial Communication
Supports RS-232 communication using the DUST1 service protocol, enabling engineering, diagnostics, program downloading, and maintenance through Siemens engineering tools.

Field Signal Acquisition
Processes binary input signals and accepts both absolute and incremental encoder feedback, allowing direct monitoring of field devices and position control applications.

Real-Time Process Control
Provides deterministic control loop execution and interrupt handling for precise regulation of industrial processes, making it suitable for power generation, turbine control, manufacturing, and other mission-critical automation systems.
